SIST EN ISO 8041-2:2021

SLOVENSKI STANDARD
oSIST prEN ISO 8041-2:2020
01-junij-2020
Odzivanje človeka na vibracije - Merilni instrumentarij - 2. del: Osebni merilnik
izpostavljenosti vibracijam (ISO/DIS 8041-2:2020)
Human response to vibration - Measuring instrumentation - Part 2: Part 2: Personal
vibration exposure meters (ISO/DIS 8041-2:2020)
Schwingungseinwirkung auf den Menschen - Messeinrichtung - Teil 2: Messgeräte für
die personenbezogene Schwingungseinwirkung (ISO/DIS 8041-2:2020)
Réponse des individus aux vibrations - Appareillage de mesure - Partie 2: Instrument de
mesure de l'exposition des personnes aux vibrations (ISO/DIS 8041-2:2020)
Ta slovenski standard je istoveten z: prEN ISO 8041-2
ICS:
13.160 Vpliv vibracij in udarcev na Vibration and shock with
ljudi respect to human beings
oSIST prEN ISO 8041-2:2020 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------
oSIST prEN ISO 8041-2:2020

---------------------- Page: 2 ----------------------
oSIST prEN ISO 8041-2:2020
DRAFT INTERNATIONAL STANDARD
ISO/DIS 8041-2
ISO/TC 108 Secretariat: ANSI
Voting begins on: Voting terminates on:
2020-03-10 2020-06-02
Human response to vibration — Measuring
instrumentation —
Part 2:
Personal vibration exposure meters
Réponse des individus aux vibrations — Appareillage de mesure —
Partie 2: Instrument de mesure de l'exposition des personnes aux vibrations
ICS: 13.160
THIS DOCUMENT IS A DRAFT CIRCULATED
This document is circulated as received from the committee secretariat.
FOR COMMENT AND APPROVAL. IT IS
THEREFORE SUBJECT TO CHANGE AND MAY
NOT BE REFERRED TO AS AN INTERNATIONAL
STANDARD UNTIL PUBLISHED AS SUCH.
IN ADDITION TO THEIR EVALUATION AS
ISO/CEN PARALLEL PROCESSING
BEING ACCEPTABLE FOR INDUSTRIAL,
TECHNOLOGICAL, COMMERCIAL AND
USER PURPOSES, DRAFT INTERNATIONAL
STANDARDS MAY ON OCCASION HAVE TO
BE CONSIDERED IN THE LIGHT OF THEIR
POTENTIAL TO BECOME STANDARDS TO
WHICH REFERENCE MAY BE MADE IN
Reference number
NATIONAL REGULATIONS.
ISO/DIS 8041-2:2020(E)
RECIPIENTS OF THIS DRAFT ARE INVITED
TO SUBMIT, WITH THEIR COMMENTS,
NOTIFICATION OF ANY RELEVANT PATENT
RIGHTS OF WHICH THEY ARE AWARE AND TO
©
PROVIDE SUPPORTING DOCUMENTATION. ISO 2020

---------------------- Page: 3 ----------------------
oSIST prEN ISO 8041-2:2020
ISO/DIS 8041-2:2020(E)

COPYRIGHT PROTECTED DOCUMENT
© ISO 2020
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting
on the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address
below or ISO’s member body in the country of the requester.
ISO copyright office
CP 401 • Ch. de Blandonnet 8
CH-1214 Vernier, Geneva
Phone: +41 22 749 01 11
Fax: +41 22 749 09 47
Email: copyright@iso.org
Website: www.iso.org
Published in Switzerland
ii © ISO 2020 – All rights reserved

---------------------- Page: 4 ----------------------
oSIST prEN ISO 8041-2:2020
ISO/DIS 8041-2:2020(E)

Contents Page
Foreword .vi
Introduction .vii
1 Scope . 1
2 Normative references . 1
3 Terms and definitions . 2
4 Reference environmental conditions . 4
5 Performance specifications . 4
5.1 General characteristics . 4
5.1.1 Common characteristics . 4
5.1.2 Special characteristics for whole-body vibration measurement. 5
5.1.3 Special characteristics for hand-arm vibration measurement. 6
5.2 Display . 6
5.3 Electrical output . 7
5.4 Vibration sensitivity . 7
5.5 Accuracy of indication at reference frequency under reference conditions . 7
5.6 Frequency weightings and frequency responses . 8
5.6.1 Parameters . 8
5.6.2 Band-limiting filter . 8
5.6.3 a-v transition filter . 9
5.6.4 Upward-step filter . 9
5.6.5 Overall frequency weighting . 9
5.6.6 Tolerances . 9
5.7 Amplitude linearity .10
5.8 Instrument noise .11
5.9 Signal-burst response .11
5.10 Overload indication .14
5.11 Under-range indication .14
5.12 Time averaging .14
5.13 Running RMS acceleration .14
5.14 Clearance of data and instrument state (named reset) .15
5.15 Timing facilities .15
5.16 Electrical cross-talk .15
5.17 Vibration transducer characteristics .15
5.18 Power supply .15
5.19 Operator detection system .16
5.20 Detection of transient acceleration artefacts .16
5.21 Logging capabilities .16
5.22 Contact force measurement .16
5.23 Warning indication .17
5.23.1 General.17
5.23.2 Mandatory warning indications .17
5.23.3 Optional warning indications .17
5.24 Human interface and ergonomic aspects .18
6 Mounting .18
7 Environmental and electromagnetic criteria .18
7.1 General .18
7.2 Air temperature .19
7.3 Surface temperature .19
7.4 Electrostatic discharge .19
7.5 Radio-frequency emissions and public-power-supply disturbances .19
7.6 Immunity to AC power-frequency fields and radio-frequency fields .20
7.7 Ingress of water and dust .21
© ISO 2020 – All rights reserved iii

---------------------- Page: 5 ----------------------
oSIST prEN ISO 8041-2:2020
ISO/DIS 8041-2:2020(E)

8 Provision for use with auxiliary devices.21
9 Instrument marking .21
10 Instrument documentation .21
11 Performance testing.22
12 Pattern evaluation .23
12.1 General .23
12.2 Testing requirements .23
12.3 Submission for testing .24
12.4 Marking of the instrument and information in the instrument documentation .24
12.5 Mandatory facilities and general requirements .24
12.6 Initial instrument preparation .24
12.7 Indication at the reference frequency under reference conditions .25
12.8 Electrical cross-talk .25
12.9 Vibration transducer .26
12.10 Amplitude linearity .26
12.10.1 Electrical tests of amplitude linearity . .26
12.10.2 Mechanical tests of amplitude linearity .27
12.11 Frequency weightings and frequency responses .28
12.11.1 General.28
12.11.2 Mechanical tests of frequency response .28
12.11.3 Electrical tests of frequency response .29
12.11.4 Conformance .30
12.12 Instrument noise .30
12.13 Signal-burst response .31
12.14 Overload indication .31
12.15 Reset .31
12.16 Combined axis outputs .31
12.17 AC electrical output .32
12.18 Timing facilities .32
12.19 Power supply .32
12.20 Environmental, electrostatic and radio-frequency tests .32
12.20.1 General.32
12.20.2 Expanded uncertainties for measurements of environmental conditions .33
12.20.3 Acclimatization requirements for tests of the influence of air temperature
and relative humidity .33
12.20.4 Test of the influence of air temperature and relative humidity combined .33
12.20.5 Influence of surface temperature .33
12.20.6 Influence of electrostatic discharges .34
12.20.7 Radio-frequency emissions and public-power-supply disturbances .34
12.20.8 Immunity to AC power-frequency fields and radio-frequency fields .35
12.21 Operator detection system .36
12.22 Logging capabilities .36
12.23 Warning indication (mandatory warnings) .36
12.24 Test report .36
13 Periodic verification .37
13.1 General .37
13.2 Testing requirements .37
13.3 Test object .37
13.4 Submission for testing .37
13.5 Preliminary inspection .38
13.6 Marking of the instrument and information in the instrument documentation .38
13.7 Test procedure .38
13.8 Test parameters .39
13.8.1 Vibration measurement chain for hand-arm vibration .39
13.8.2 Vibration measurement chain for whole-body vibration .39
13.8.3 Vibration measurement chain low-frequency whole-body vibration.39
iv © ISO 2020 – All rights reserved

---------------------- Page: 6 ----------------------
oSIST prEN ISO 8041-2:2020
ISO/DIS 8041-2:2020(E)

13.9 Conducting the test .40
13.10 Test report .40
14 In-situ check .40
14.1 General .40
14.2 Preliminary inspection .41
14.3 Vibration sensitivity (field calibration) .41
Annex A (informative) Treatment of transient acceleration artefacts .42
Annex B (informative) Influence of coupling force on hand-arm vibration evaluation .47
Annex C (informative) Human Interface .51
Bibliography .52
© ISO 2020 – All rights reserved v

---------------------- Page: 7 ----------------------
oSIST prEN ISO 8041-2:2020
ISO/DIS 8041-2:2020(E)

Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular, the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www .iso .org/ directives).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of
any patent rights identified during the development of the document will be in the Introduction and/or
on the ISO list of patent declarations received (see www .iso .org/ patents).
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation of the voluntary nature of standards, the meaning of ISO specific terms and
expressions related to conformity assessment, as well as information about ISO's adherence to the
World Trade Organization (WTO) principles in the Technical Barriers to Trade (TBT), see www .iso .org/
iso/ foreword .html.
This document was prepared by Technical Committee [or Project Committee] ISO/TC 108, Mechanical
vibration, shock and condition monitoring.
A list of all parts in the ISO 8041 series can be found on the ISO website.
Any feedback or questions on this document should be directed to the user’s national standards body. A
complete listing of these bodies can be found at www .iso .org/ members .html.
vi © ISO 2020 – All rights reserved

---------------------- Page: 8 ----------------------
oSIST prEN ISO 8041-2:2020
ISO/DIS 8041-2:2020(E)

Introduction
ISO 8041-1 specifies instruments for the measurement of vibration to which human beings are exposed.
These instruments are used for temporary, short-time measurements or controlled measurements.
The present document specifies personal vibration exposure meters, shortly PVEM, to measure human
exposure to vibration over long time periods, e.g. a whole working shift.
PVEM need not to fulfil all the specifications given in ISO 8041-1. On the other hand, they need to fulfil
other requirements to allow none-controlled measurements or stand-alone measurements over longer
time periods. In combination with alarm functions, they can be capable to inform the user before the
vibration exposure reaches certain values (action value, limit value). This fact makes it necessary to
distinguish PVEM from the instrumentation specified in ISO 8041-1.
Annexes B and C describe possible extension features with additional information for the measurement
procedure.
© ISO 2020 – All rights reserved vii

---------------------- Page: 9 ----------------------
oSIST prEN ISO 8041-2:2020

---------------------- Page: 10 ----------------------
oSIST prEN ISO 8041-2:2020
DRAFT INTERNATIONAL STANDARD ISO/DIS 8041-2:2020(E)
Human response to vibration — Measuring
instrumentation —
Part 2:
Personal vibration exposure meters
1 Scope
This document specifies minimum requirements for personal vibration exposure meters (PVEM).
This document is applicable to instruments designed for measurements of whole-body vibration in the
context of industrial hygiene applications (in accordance with ISO 2631-1, ISO 2631-2 and ISO 2631-4)
and/or hand-arm vibration (in accordance with ISO 5349-1) together with the associated exposure times.
This document provides specified design goals and permitted tolerances that define the minimum
performance capabilities and functional requirements of instruments designed to measure personal
daily vibration exposure.
Instruments meeting the requirements of this document are required to have logging capabilities.
Additional information is provided on how instruments might use the logged data for post-processing,
e.g. to identify transient acceleration artefacts in the measurement so that they can be excluded from
vibration exposure values and the evaluation of accurate vibration exposure times.
NOTE This document is not intended to apply to instruments designed to measure or log exposure times
without also performing vibration measurement. Instrumentation of this type is described in ISO/TR 19664.
2 Normative references
The following documents are referred to in the text
...
