INTERNATIONAL STANDARD ISO 13784-2:2020(E)
Reaction-to-fire tests for sandwich panel building
systems —
Part 2:
Test method for large rooms
SAFETY PRECAUTIONS — In order that suitable precautions can be taken to safeguard health,
the attention of all concerned in fire tests is drawn to the possibility that toxic or harmful gases
can evolve during combustion of test specimens.
The test procedures concerned involve high temperatures and combustion processes, from
ignition to a fully developed room fire. Therefore, hazards can exist for burns, ignition of
extraneous objects or clothing. Operators should use protective clothing, helmet, face-shield
and equipment for avoiding exposure to toxic gases.
Laboratory safety procedures shall be set up which ensure the safe termination of tests on
sandwich panel products. Specimens with combustible content burning inside metallic facings
can be difficult to extinguish with standard laboratory fire fighting equipment. Adequate means
of extinguishing such a fire shall be provided.
When tests are conducted using freestanding or frame-supported constructions, specimens
could emit combustion products from their external faces, especially if joints open up. Specimen
collapse can also occur. Laboratory safety procedures shall be set up to ensure the safety of
personnel with due consideration to such situations.
For construction of the test enclosure using a freestanding structure without structural
framework, because of the size and weight of the individual panels it is strongly recommended
that construction be accomplished within an additional external support framework (e.g.
scaffolding). If the test enclosure is erected in an outside environment, it is further recommended
that the external framework remain in place during the test. The purpose of this framework is
only to avoid collapse of the test room caused by wind action. This additional framework shall
not be used to fix and support the sandwich panels.
1 Scope
This document specifies a test method for evaluating the reaction-to-fire performance of thermal
insulating sandwich panel building systems for large rooms and the resulting flame spread on or
within the thermal insulating sandwich panel building construction when it is exposed to heat from
a simulated internal fire with flames impinging directly on its internal corner. The test method is not
intended for evaluating a product's fire resistance.
This document is applicable to both freestanding and self-supporting and frame-supported thermal
insulating sandwich panel systems, but only to wall and ceiling or roof constructions.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 13943, Fire safety — Vocabulary
IEC 60584-1, Thermocouples — Part 1: EMF specifications and tolerances
© ISO 2020 – All rights reserved 1

---------------------- Page: 6 ----------------------
ISO 13784-2:2020(E)

3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 13943 and the following apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at http:// www .electropedia .org/
3.1
composite
combination of materials generally recognized in building construction as discrete entities
EXAMPLE Coated or laminated materials.
3.2
exposed surface
surface of the product (3.2) subjected to the heating conditions of the test
3.3
product
material, composite (3.1) or assembly
3.4
surface product
any part of a building constituting an exposed surface on the walls or ceiling/roof, or on both
EXAMPLE Panel or board.
3.5
thermal insulating sandwich panel
sandwich panel
building product (3.2) consisting of two metal faces positioned on either side of a core that is a thermally
insulating material, which is firmly bonded to both faces so that the three components act compositely
when under load
Note 1 to entry: One layer is an insulating material, such as mineral or glass wool, cellular plastics or a natural
material (e.g. corkboard), protected by facings on both sides. Facings can be selected from a variety of materials
and can be either flat or profiled. The most widely used facing is coated steel. The composite varies from a
simple construction to a complex composite system with specific fixing joints and supports, depending on the
application and on the performance requirements.
3.6
specimen
assembly representing the end-use construction
4 Principle
The reaction to fire performance of a sandwic
...
