INTERNATIONAL STANDARD                        ISO 10303-34:2001(E)
Industrial automation systems and integration –
Product data representation and exchange –
Part 34:
Conformance testing methodology and framework: Abstract
test methods for application protocol implementations
1 Scope
This part of ISO 10303 specifies the abstract test methods for conformance testing of an implementation
of an ISO 10303 Application Protocol (AP). The scope is limited to the following implementation
methods:
— preprocessors that claim to generate 10303 schema instances represented as exchange structures as
defined by ISO 10303-21;
— postprocessors that claim to accept and process 10303 schema instances represented as exchange
structures as defined by ISO 10303-21;
— preprocessors that claim to generate 10303 schema instances and use the SDAI interface as
defined in ISO 10303-22 to populate an SDAI implementation with these schema instances;
— postprocessors that claim to accept 10303 schema instances and use the SDAI interface as defined
in ISO 10303-22 to extract schema instances from an SDAI implementation.
The following are within the scope of this part of ISO 10303:
— the conformance assessment process undertaken to evaluate the conformity of an implementation
of an ISO 10303 application protocol. The abstract test methods are independently applicable to
implementation methods based on ISO 10303-21 and ISO 10303-22;
— the methods to be followed by the testing laboratory using executable test cases (ETC). The
methods presented are abstract, that is, they are independent of the implementation under test (IUT).
The method descriptions cover the different steps from abstract test case (ATC) selection to test case
report production.
The following is outside the scope of this part of ISO 10303:
— the generation of executable test cases from abstract test cases. This part of ISO 10303 does not
include abstract test methods for conformance testing of application protocol independent
implementations of the Standard Data Access Interface (SDAI) -- ISO 10303-22.
2 Normative references
The following normative documents contain provisions which, through reference in this text, constitute
provisions of this part of ISO 10303. For dated references, subsequent amendments to, or revision of, any
of these publications do not apply. However, parties to agreements based on this part of ISO 10303 are
encouraged to investigate the possibility of applying the most recent editions of the normative documents
indicated below. For undated references, the latest edition of the normative document referred to applies.
Members of ISO and IEC maintain registers of currently valid International Standards.
ISO 10303-1:1994, Industrial automation systems and integration - Product data representation and
exchange - Part 1: Overview and fundamental principles.
ISO 10303-11:1994, Industrial automation systems and integration - Product data representation and
exchange - Part 11: The EXPRESS language reference manual.
ISO 10303-21:1994, Industrial automation systems and integration - Product data representation and
exchange - Part 21: Implementation methods: Clear text encoding of the exchange structure.
ISO 10303-22:1998, Industrial automation systems and integration - Product data representation and
exchange - Part 22: Implementation methods: Standard data access interface.
ISO 10303-31:1994, Industrial automation systems and integration - Product data representation and
exchange - Part 31: Conformance testing methodology and framework: General concepts.
ISO 10303-32:1998, Industrial automation systems and integration - Product data representation and
exchange - Part 32: Conformance testing methodology and framework: Requirements on testing
laboratories and clients.
3 Terms, definitions and abbreviations
3.1 Terms defined in ISO 10303-1
For the purposes of this part of ISO 10303, the following terms defined in ISO 10303-1 apply.
—    abstract test suite (ATS);
—    application interpreted model;
—    application protocol (AP);
—    application reference model;
—    conformance class;
—    exchange structure;
—    implementation method;
—    Protocol Implementation Conformance Statement (PICS);
—    PICS proforma.
3.2 Terms defined in ISO 10303-11
For the purposes of this part of ISO 10303, the following terms defined in ISO 10303-11 apply.
—   entity;
—   entity instance.
3.3 Terms defined in ISO 10303-22
For the purposes of this part of ISO 10303, the following terms defined in ISO 10303-22 apply.
—   schema instance;
—   SDAI model.
3.4 Terms defined in ISO
...
