INTERNATIONAL STANDARD ISO 6722-1:2011
TECHNICAL CORRIGENDUM 1
Published 2012-09-15
INTERNATIONAL ORGANIZATION FOR STANDARDIZATION МЕЖДУНАРОДНАЯ ОРГАНИЗАЦИЯ ПО СТАНДАРТИЗАЦИИ ORGANISATION INTERNATIONALE DE NORMALISATION
Road vehicles — 60 V and 600 V single-core cables —
Part 1:
Dimensions, test methods and requirements for copper
conductor cables
TECHNICAL CORRIGENDUM 1
Véhicules routiers — Câbles monoconducteurs de 60 V et 600 V —
Partie 1: Dimensions, méthodes d'essai et exigences pour les câbles conducteurs en cuivre
RECTIFICATIF TECHNIQUE 1
Technical Corrigendum 1 to ISO 6722-1:2011 was prepared by Technical Committee ISO/TC 22, Road
vehicles, Subcommittee SC 3, Electrical and electronic equipment.
Page 7, Table 4
Replace Table 4 with the following table in which some of the dimensions in the "ISO conductor diameter"
column have been corrected:
ICS 43.040.10 Ref. No. ISO 6722-1:2011/Cor.1:2012(E)
© ISO 2012 – All rights reserved
Published in Switzerland
ISO 6722-1:2011/Cor.1:2012(E)
Table 4 — Dimensions
ISO conductor Thick wall Thin wall Ultra-thin wall
Size Diameter Insulation Outside Insulation Outside Insulation Outside
thickness cable thickness cable thickness cable
diameter diameter diameter
mm mm mm mm mm mm mm mm
max. nominal min. max. nominal min. max. nominal min. max.
0,13 0,55 1,05 0,95
0,22 0,70 0,25 0,20 1,20 1,05
a
0,35 0,90 1,40 1,20
0,50 1,10 2,30 0,28 0,22 1,60 1,40
0,20 0,16
0,75 1,30 2,50 1,90 1,60
1 1,50 2,70 2,10 1,75
0,60 0,48 0,30 0,24
1,25 1,70 2,95 2,30 2,00
1,5 1,80 3,00 2,40 2,10
2 2,00 3,30 2,80 2,40
0,35 0,28 0,25 0,20
2,5 2,20 3,60 3,00 2,70
0,70 0,56
3 2,40 4,10 3,40
4 2,80 4,40 3,70
5 3,10 4,90 0,40 0,32 4,20
0,80 0,64
6 3,40 5,00 4,30
8 4,30 5,90 5,00
10 4,50 6,50 6,00
0,60 0,48
12 5,40 1,00 0,80 7,40 6,50
16 6,30 8,30 7,20
20 6,90 1,10 0,88 9,10 0,65 0,52 7,80
25 7,80 10,40 8,70
30 8,30 1,30 1,04 10,90 9,60
0,80 0,64
35 9,00 11,60 10,40
40 9,60 1,40 1,12 12,40 11,10
0,90 0,71
50 10,50 13,50 12,20
60 11,60 1,50 1,20 14,60 13,30
1,00 0,80
70 12
...
