Biotechnology — Gene Delivery Systems — delivery systems —
Part 1:
Vocabulary
FDIS stage
ISO/FDIS 16921-1:2025(en)
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication
may be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying,
or posting on the internet or an intranet, without prior written permission. Permission can be requested from either ISO
at the address below or ISO’s member body in the country of the requester.
ISO copyright office
CP 401 • Ch. de Blandonnet 8
CH-1214 Vernier, Geneva
Phone: + 41 22 749 01 11
EmailE-mail: copyright@iso.org
Website: www.iso.orgwww.iso.org
Published in Switzerland
ii
ISO/DISFDIS 16921-1:20242025(en)
Contents
Foreword . iv
Introduction . v
1 Scope . 1
2 Normative references . 1
3 Terms and definitions . 1
Bibliography . 13

Foreword . iv
Introduction . v
1 Scope . 1
2 Normative references . 1
3 Terms and definitions . 1
3.1 General terms . 1
3.2 Gene delivery system attributes and function . 5
3.3 General terms for viral vectors . 6
3.4 General terms for lipid nanoparticles . 8
3.5 Analytical methods . 9
Bibliography . 13

iii
ISO/FDIS 16921-1:2025(en)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out through
ISO technical committees. Each member body interested in a subject for which a technical committee has been
established has the right to be represented on that committee. International organizations, governmental and
non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely with the
International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are described
in the ISO/IEC Directives, Part 1. In particular, the different approval criteria needed for the different types of
ISO documents should be noted. This document was drafted in accordance with the editorial rules of the
ISO/IEC Directives, Part 2 (see www.iso.org/directives).
Field Code Changed
ISO draws attention to the possibility that the implementation of this document may involve the use of (a)
patent(s). ISO takes no position concerning the evidence, validity or applicability of any claimed patent rights
in respect thereof. As of the date of publication of this document, ISO had not received notice of (a) patent(s)
which may be required to implement this document. However, implementers are cautioned that this may not
represent the latest information, which may be obtained from the patent database available at
www.iso.org/patents.www.iso.org/patents. ISO shall not be held responsible for identifying any or all such
patent rights.
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation of the voluntary nature of standards, the meaning of ISO specific terms and expressions
related to conformity assessment, as well as information about ISO's adherence to the World Trade
Organization (WTO) principles in the Technical Barriers to Trade (TBT), see www.iso.org/iso/foreword.html.
Field Code Changed
This document was prepared by Technical Committee ISO/TC 276, Biotechnology, Subcommittee SC 1,
Analytical methods.
Any feedback or questions on this document should be directed to the user’s national standards body. A
complete listing of these bodies can be found at www.iso.org/members.htmlwww.iso.org/members.html.
iv
ISO/DISFDIS 16921-1:20242025(en)
Introduction
Modern and emerging biotechnology is underpinned by the ability to manipulate the genes and genomes of
living systems. Gene delivery systems are foundational to genome engineering. Gene delivery technology is
evolving rapidly with numerous types of gene delivery systems providing a comprehensive set of tools and
capabilities for in vitro or in vivo targeted delivery.
The ISO I6921 series consists of multiple parts to provide common understanding, guides, and analytical
methods for characterizing these emerging biotechnology tools. This document provides terms and
definitions to enable common understanding. Other parts of the ISO I6921 series will focus on measurements
for various gene delivery systems.
v
DRAFT International Standard ISO/DIS 16921-1:2024(en)

Biotechnology — Gene Delivery Systems — delivery systems —
Part 1:
Vocabulary
1 Scope
This document defines terms related to gene transfer for mammalian systems, including the use of viral and
non-viral gene delivery systems and via mechanical mechanisms.
This document is applicable to the development, measurement, and use of gene delivery systems for all
applications.
2 Normative references
There are no normative references in this document.
3 Terms and definitions
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— — ISO Online browsing platform: available at https://www.iso.org/obphttps://www.iso.org/obp
— — IEC Electropedia: available at https://www.electropedia.org/
3.1 General terms
3.1.1 3.1.1
electroporation
action or process of introducing nucleic acids into cells using a pulse of electricity to briefly open pores in the
cell membrane
3.1.2 3.1.2
exosome
a subtype of extracellular vesicles (3.1.3)(3.1.3) of endosomal origin generated by cells that can carry nucleic
acids, proteins, lipids, and metabolites
Note 1 to entry: Usage of this term is discouraged unless subcellular origin can be demonstrated. See Reference [1] [0]
for additional information.
3.1.3
3.1.3
extracellular vesicles
particles that are released from cells, are delimited by a lipid bilayer (3.4.3),(3.4.3), and cannot replicate on
their own
Note 1 to entry: See Reference [1] [0] for additional information.
[1] [ ]
[SOURCE: Minimal information for studies of extracellular vesicles (MISEV2023) ]) 0 ]
ISO/FDIS 16921-1:2025(en)
3.1.4 3.1.4
gene amplification
process whereby a defined DNA sequence in the genome is increased exponentially in number of copies using
methods such as PCR or bacterial amplification
3.1.5 3.1.5
gene cloning
technique of identifying a gene of interest (3.1.10),(3.1.10), isolating the gene, and amplifying a gene that can
be incorporated into a gene delivery system (3.1.6)(3.1.6)
3.1.6 3.1.6
gene delivery systems
systems to introduce foreign nucleic acid into target or host cells
Note 1 to entry: Foreign nucleic acid to be delivered are commonly known as transgenes (3.1.27).(3.1.27).
3.1.7 3.1.7
gene editing
techniques for genome engineering (3.1.13)(3.1.13) that involve nucleic acid damage, repair mechanisms,
replication and/or recombination for incorporating site-specific modification(s) into genomic DNA
Note 1 to entry: Gene editing is a subclass of genome editing (3.1.12).(3.1.12).
[SOURCE: ISO 5058-1:2021, 3.1.1, modified — changed “into a gene or genes” to “into genomic DNA” and
removed Note 2 to entry.]
3.1.8 3.1.8
gene expression
process of gene transcription and translation, in which the product is RNA or protein
[SOURCE: ISO/TS 16843-6:2022, 3,27, modified — Example removed.]
3.1.9 3.1.9
gene gun
mechanical gene transfer (3.1.11)(3.1.11) method for transfecting cells with foreign nucleic acid or other
biological molecules where a payload is coated on to high-density microcarriers, accelerated to high velocity
by a gas pulse, and driven through cell walls and membranes to enter a target cell.
3.1.10
3.1.10
gene of interest
GOI
nucleic acid sequence that encodes for the protein of interest
3.1.11 3.1.11
gene transfer
gene delivery
process by which foreign nucleic acid is introduced to target or host cells through mechanical, chemical, or
biological approaches
Note 1 to entry: There are various gene transfer methods (see Figure 1).Figure 1).

ISO/DISFDIS 16921-1:20242025(en)

Key
a
Viral vectors can include, but are not limited to, lentivirus, adenovirus, adeno-associated virus, and
retrovirus.
NOTE This figure of gene transfer methods is not exhaustive as methods are under development.

ISO/FDIS 16921-1:2025(en)
a
Viral vectors can include, but are not limited to, lentivirus, adenovirus, adeno-associated virus, and retrovirus.
NOTE This figure of gene transfer methods is not exhaustive as methods are under development.
Figure 1 — General classification for gene transfer
3.1.12 3.1.12
genome editing
techniques for genome engineering (3.1.13)(3.1.13) that involve nucleic acid damage, repair mechanisms,
replication and/or recombination for incorporating site-specific modification(s) into a genomic DNA
Note 1 to entry: Gene editing (3.1.7)(3.1.7) is a subclass of genome editing.
[SOURCE: ISO 5058-1:2021, 3.12, modified — deleted Note 2 to entry and the associated Figure 1.]Figure 1.]
3.1.13 3.1.13
genome engineering
process of introducing intentional changes to genomic nucleic acid
[SOURCE: ISO 5058-1:2021, 3.1.3, modified — deleted Note 1 to entry.]
3.1.14 3.3.14
integrating gene transfer
nucleic acid payload integration into the target host genome

Note 1 to entry: Integrating gene transfer (3.1.11)(3.1.11) methods include retrovirus transduction and CRISPR/Cas9-
mediated gene editing.
3.1.15 3.1.15
lipofection
delivery of nucleic acids to target cells by lipid transfer
3.1.16 3.1.16
mechanical gene transfer
transfer of nucleic acid to target cells by physical mechanisms
Note 1 to entry: Microinjection, electroporation, gene gun, ultrasound-mediated methods and hydrodynamic systems
are examples of mechanical methods used for gene delivery (3.1.11).(3.1.11).
3.1.17 3.1.17
microbial vector
microbial system engineered for delivering payload to cells
3.1.18
3.1.18
microinjection
method for injecting nucleic acid directly into a specific, individual cell using a micropipette
3.1.19 3.3.19
non-integrating gene transfer
transient gene transfer
nucleic acid payload transfer that does not integrate into the target host genome, but allows the gene to be
expressed for a limited period of time
ISO/DISFDIS 16921-1:20242025(en)
3.1.20
3.1.20
nucleic acid nanostructure
gene delivery (3.1.11)(3.1.11) method based on encapsulation of payload using nucleic acids to form
complexes or structures that can deliver genetic material into cells
Note 1 to entry: Examples of nucleic acid nanostructures include tetrahedral framework nucleic acid (3.1.24),(3.1.24),
DNA nanostructures, and RNA nanoparticles.
Note 2 to entry: Nucleic acid nanostructures can conjugate with other materials, such as polymers, resulting in a hybrid
gene delivery system (3.1.6).(3.1.6).
3.1.21 3.1.21
plasmid
extrachromosomal DNA molecule in cells physically separated from the chromosome and capable of
autonomous replication
[SOURCE: ISO 16577:2022, 3.4.37, modified — deleted NoteNotes 1 and 2 to entry.]
3.1.22 3.1.22
polymeric nanoparticles
gene delivery (3.1.11)(3.1.11) method based on encapsulation of payload using polymers
Note 1 to entry: Examples of synthetic polymer gene delivery systems (3.1.6)(3.1.6) include poly-L-lysine,
polyethyleneimine, or hydrogels.
Note 2 to entry: Examples of natural polymer gene delivery systems (3.1.6)(3.1.6) include polysaccharides, such chitosan,
dextran, and hyaluronic acid.
3.1.23 3.1.23
protein nanocarriers
gene delivery (3.1.11)(3.1.11) method based on encapsulation of payload using proteins
Note 1 to entry: Examples of protein nanocarriers include albumin nanoparticles and virus-like particles.
3.1.24 3.1.24
tetrahedral framework nucleic acid
tFNA
a nucleic acid nanostructure with a tetrahedral framework structure developed through DNA origami
technology, formed from four single-stranded DNA molecules through denaturation and renaturation, relying
on inter-strand complementary base pairing
3.1.25 3.1.25
transduction
process whereby genetic material is introduced into a host cell by a replication incompetent (3.3.12) viral
vector (3.1.28)(3.3.12) viral vector (3.1.28)
3.1.26 3.1.26
transfection
introduction of nucleic acids, exogenous DNA, or RNA into a eukaryotic cell by non-viral methods
3.1.27 3.1.27
transgene
gene from one organism or synthetically generated that can include promoter, gene of interest
(3.1.10),(3.1.10), and stop sequence that is inserted into another cell or organism
Note 1 to entry: The terms payload and cargo are sometimes used to describe a transgene.
ISO/FDIS 16921-1:2025(en)
3.1.28 3.1.28
viral vector
recombinant viral system engineered to be replication incompetent (3.3.12)(3.3.12) for delivering payload to
cells
3.2 Gene delivery system attributes and function
3.2.1 3.2.1
activity
measure of a specific cellular functional outcome associated with gene transfer (3.1.11)(3.1.11) which can
include transgene (3.1.27)(3.1.27) insertion, integration, and expression
Note 1 to entry: Potency assays are a type of activity assay that are often associated with a product’s specific
mechanisms of action.
3.2.2 3.2.2
aggregate
two or more particles clustered together (tightly or loosely) and detected as a larger object
[SOURCE: ISO 20391-1:2018, 3.3, modified — used "particles" instead of "cells" and deleted Note 1 to entry.]
3.2.3 3.2.3
cellular uptake
absorption of biological or manufactured entity into a cell through its plasma membrane
3.2.4 3.2.4
concentration
...
