ISO 10362-1:2019

SLOVENSKI STANDARD
01-julij-2020
Nadomešča:
SIST ISO 10362-1:2000
Cigarete - Določevanje vode v celotnih delcih iz glavnega dima
Cigarettes - Determination of water in total particulate matter from the mainstream
smoke
Cigarettes - Dosage de l'eau dans la matière particulaire totale du courant principal de
fumée
Ta slovenski standard je istoveten z: ISO 10362-1:2019
ICS:
65.160 Tobak, tobačni izdelki in Tobacco, tobacco products
oprema and related equipment
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

INTERNATIONAL ISO
STANDARD 10362-1
Third edition
2019-07
Cigarettes — Determination of water
in total particulate matter from the
mainstream smoke —
Part 1:
Gas-chromatographic method
Cigarettes — Dosage de l'eau dans la matière particulaire totale du
courant principal de fumée —
Partie 1: Méthode par chromatographie en phase gazeuse
Reference number
©
ISO 2019
© ISO 2019
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting
on the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address
below or ISO’s member body in the country of the requester.
ISO copyright office
CP 401 • Ch. de Blandonnet 8
CH-1214 Vernier, Geneva
Phone: +41 22 749 01 11
Fax: +41 22 749 09 47
Email: copyright@iso.org
Website: www.iso.org
Published in Switzerland
ii © ISO 2019 – All rights reserved

Contents Page
Foreword .iv
Introduction .v
1 Scope . 1
2 Normative reference . 1
3 Terms and definitions . 1
4 Principle . 1
5 Reagents . 1
6 Apparatus . 2
7 Procedure. 3
7.1 Test portion . 3
7.2 Setting up the apparatus. 3
7.3 Calibration of the gas chromatograph . 3
7.4 Blank test . 3
7.5 Determination . 4
8 Alternative gas chromatographic procedures . 4
8.1 General . 4
8.2 Packed columns . 4
8.3 Capillary columns . 4
8.4 Gas chromatographic conditions . 4
9 Expression of results . 5
10 Repeatability and reproducibility . 6
11 Test report . 7
Annex A (informative) Use of this method in conjunction with the method of nicotine
determination . 8
Bibliography . 9
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www .iso .org/directives).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of
any patent rights identified during the development of the document will be in the Introduction and/or
on the ISO list of patent declarations received (see www .iso .org/patents).
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation on the voluntary nature of standards, the meaning of ISO specific terms and
expressions related to conformity assessment, as well as information about ISO's adherence to the
World Trade Organization (WTO) principles in the Technical Barriers to Trade (TBT) see the following
URL: www .iso .org/iso/foreword .html.
This document was prepared by Technical Committee ISO/TC 126, Tobacco and tobacco products.
This third edition cancels and replaces the second edition (ISO 10362-1:1999), which has been
technically revised. It also incorporates the Amendment ISO 10362-1:1999/AMD 1:2011. The main
changes compared to the previous edition are as follows:
— capillary column procedure as an alternative gas chromatographic procedure has been added;
— the estimates for the repeatability limits (r) and the reproducibility limits (R) has been updated.
A list of all parts in the ISO 10362 series can be found on the ISO website.
Any feedback or questions on this document should be directed to the user’s national standards body. A
complete listing of these bodies can be found at www .iso .org/members .html.
iv © ISO 2019 – All rights reserved

Introduction
This document may be considered as part of a set of standards which describes the determination of
total and nicotine-free dry particulate matter (NFDPM) in total particulate matter from the mainstream
smoke. The set comprises ISO 3308, ISO 3402, ISO 4387, ISO 8243, ISO 10315 and this document.
Annex A provides information about the use of this method in conjunction or simultaneously with the
gas-chromatographic method of nicotine determination described in ISO 10315.
A bibliography is provided.
No machine smoking regime can represent all human smoking behaviour:
— it is recommended that cigarettes also be tested under conditions of a different intensity of machine
smoking than those specified in this document;
— machine smoking testing is useful to characterize cigarette emissions for design and regulatory
purposes, but communication of machine measurements to smokers can result in misunderstandings
about differences in exposure and risk across brands;
— smoke emission data from machine measurements may be used as inputs for product hazard
assessment, but they are not intended to be nor are they valid as measures of human exposure or
risks. Communicating differences between products in machine measurements as differences in
exposure or risk is a misuse of testing using ISO standards.
INTERNATIONAL STANDARD ISO 10362-1:2019(E)
Cigarettes — Determination of water in total particulate
matter from the mainstream smoke —
Part 1:
Gas-chromatographic method
1 Scope
This document specifies a method for the gas-chromatographic determination of water in total
particulate matter from the mainstream smoke. The smoking of cigarettes and collection of mainstream
smoke are normally carried out in accordance with ISO 4387. However, the method of this document is
also applicable to the determination of water in total particulate matter from the mainstream smoke
obtained by non-standard smoking.
NOTE In countries not in a position to use the gas-chromatographic method, the determination of water
in total particulate matter from the mainstream smoke is performed using the Karl Fischer method (see
ISO 10362-2). In such cases, values obtained for water in total particulate matter from the mainstream smoke are
used with the addition of a note made in the expression of the results.
2 Normative reference
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 3696:1987, Water for analytical laboratory use — Specification and test methods
ISO 4387, Cigarettes — Determination of total and nicotine-free dry particulate matter using a routine
analytical smoking machine
3 Terms and definitions
No terms and definitions are listed in this document.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https: //www .iso .org/obp
— IEC Electropedia: available at http: //www .electropedia .org/
4 Principle
The total particulate matter from the mainstream smoke is dissolved in a solvent containing an internal
standard. The water content of an aliquot of the solution is determined by gas chromatography, and the
water content of the whole of the total particulate matter from the mainstream smoke is calculated.
5 Reagents
Use only reagents of recognized analytical reagent grade.
5.1 Carrier gas, helium or nitrogen (see note in 7.2) or hydrogen (see note in 8.4).
5.2 Propan-2-ol, with maximum water content of 1,0 mg/ml.
5.3 Internal standard, ethanol or methanol (of purity at least 99 %).
5.4 Extraction solution, propan-2-ol (5.2) containing an appropriate concentration of internal
standard (5.3), normally in the range of 1 ml/l to 5 ml/l.
Extraction solution not stored in a temperature-controlled laboratory shall be allowed to equilibrate to
(22 ± 2) °C before use.
To prevent water being absorbed, the bulk extraction solution container shall be fitted with a water
trap and shall be kept sealed. The extraction solution shall be stirred continuously to ensure the
homogeneity of the water concentration.
5.5 Reference substance, complying with grade 2 of ISO 3696:1987, or better.
5.6 C
...
