– 2 – IEC 61587-6:2021 © IEC 2021
CONTENTS
FOREWORD . 3
INTRODUCTION . 5
1 Scope . 6
2 Normative references . 6
3 Terms and definitions . 6
4 Security aspects for indoor cabinets . 8
4.1 General . 8
4.2 Access security level of the cabinet . 9
5 Security performance levels of cabinets . 10
5.1 General . 10
5.2 Security performance levels of cabinet – Mechanical . 10
5.2.1 General . 10
5.2.2 Tests for strength of mechanical locks and hinges . 11
5.2.3 Tests for operation of handle and mechanical lock . 12
5.2.4 Tests for panel strength . 12
5.3 Key . 13
5.4 Cabinet floor anchoring . 14
Annex A (normative) Mechanical performance and test methods for handles –
Mechanical strengths of levers of handles . 15
A.1 General . 15
A.2 Static loading test, push/pull performance . 15
A.3 Static loading test, turn performance . 16
Bibliography . 18

Figure 1 – Typical mechanical components for security provision of the cabinet . 8
Figure 2 – Concept of access protection within buildings or premises . 9
Figure 3 – Static loading test for mechanical lock and hinges . 11
Figure 4 – Static loading test for panel strength . 13
Figure A.1 – Lever handles' push/pull performance . 16
Figure A.2 – Lever handles' turn performance . 17

Table 1 – Access security levels of indoor cabinet installation sites . 9
Table 2 – Security performance levels of cabinets . 10
Table 3 – Security performance levels of cabinet – Mechanical . 10
Table 4 – Test procedures for operation of handle and mechanical lock . 12
Table 5 – Security performance levels of key . 14
Table 6 – Security performance level of cabinet floor anchoring . 14

INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
MECHANICAL STRUCTURES FOR
ELECTRICAL AND ELECTRONIC EQUIPMENT –
TESTS FOR IEC 60917 AND IEC 60297 SERIES –

Part 6: Security aspects for indoor cabinets

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 61587-6 has been prepared by subcommittee 48D: Mechanical
structures for electrical and electronic equipment, of IEC technical committee 48: Electrical
connectors and mechanical structures for electrical and electronic equipment.
This second edition cancels and replaces the first edition published in 2017. This edition
constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous
edition:
a) Revised and expanded terms and definitions.
b) Additional information in 4.2 Access security level of the cabinet.
c) Revised requirements for Security performance levels of cabinets and added additional
levels in Table 2 – Security performance levels of cabinets.

– 4 – IEC 61587-6:2021 © IEC 2021
d) Added a column for panel strength in Table 3 – Security performance levels of cabinet –
mechanical.
e) Revised test for mechanical lock (and hinges added) in 5.2.2 Tests for strength of
mechanical locks and hinges.
f) Added 5.2.4 Tests for panel strength.
g) Added additional description of Key function in Table 5 – Security performance levels of
key.
h) Revised test method for handles in Annex A.
The text of this International Standard is based on the following documents:
FDIS Report on voting
48D/736/FDIS 48D/737/RVD
Full information on the voting for the approval of this International Standard can be found in
the report on voting indicated in the above table.
This document has been drafted in accordance with the ISO/IEC Directives, Part 2.
A list of all parts in the IEC 61587 series, published under the general title Mechanical
structures for electrical and electronic equipment – Tests for IEC 60917 and IEC 60297
series, can be found on the IEC website.
The committee has decided that the contents of this document will remain unchanged until the
stability date indicated on the IEC website under "http://webstore.iec.ch" in the data related to
the specific document. At this date, the document will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
IMPORTANT – The "colour inside" logo on the cover page of this document indicates
that it contains colours which are considered to be useful for the correct
understanding of its contents. Users should therefore print this document using a
colour printer.
INTRODUCTION
The security of electrical and electronic equipment or systems currently applied in the fields of
ICT (information and communication technology) and of industrial/infrastructure control
systems, is of critical importance. The advent of 5G telecommunication service and edge
computing/edge servers/edge switches places ICT equipment in industrial environments. This
document defines performance levels for cabinets not only for ICT data centre and office
locations but for any combination of equipment, purpose, and location.
In general, security is achieved by restrictions and protections against improper or
unauthorized access from both the hardware and software sides of the systems.
The security of the hardware of electrical and electronic equipment or systems, which are
housed in mechanical structures such as cabinets based on IEC 60297 series and IEC 60917
series, depends:
– on conditions of their installation sites,
– on the system hardware which provides access protection at the installation sites, and
– on the robustness of the mechanical structures and of their mechanical locks both at the
access gates/doors of the installation sites and of the mechanical structures.
Therefore, a classification of the installation conditions and of the levels of security measures
for the hardware is very important for design and practices of various electronic equipment or
systems, which are used in the field of ICT, industrial control, transportation and others.
From this point of view, this document intends to clarify the relationship between the
installation conditions and the security requirements for indoor cabinets, and to provide the
required performance and test methods on mechanical components related with security
provisions for indoor cabinets which are in accordance with the IEC 60297 series and
IEC 60917 series.
Vandalism protection is typically controlled by user-specific requirements. Therefore, this
document does not address vandalism.

– 6 – IEC 61587-6:2021 © IEC 2021
MECHANICAL STRUCTURES FOR
ELECTRICAL AND ELECTRONIC EQUIPMENT –
TESTS FOR IEC 60917 AND IEC 60297 SERIES –

Part 6: Security aspects for indoor cabinets

1 Scope
This part of IEC 61587 specifies security aspects and security performance levels of the
mechanical construction of indoor cabinets in accordance with IEC 60917 (all parts) and
IEC 60297 (all parts). This document does not address vandalism.
NOTE Protection against vandalism is typically controlled by user-specific requirements.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their
content constitutes requirements of this document. For dated references, only the edition
cited applies. For undated references, the latest edition of the referenced document (including
any amendments) applies.
IEC 60297 (all parts), Mechanical structures for electrical and electronic equipment –
Dimensions of mechanical structures of the 482,6 mm (19 in) series
IEC 60529, Degrees of protection provided by enclosures (IP Code)
IEC 60917 (all parts), Modular order for the development of mechanical structures for
electronic equipment practices
IEC 61587-1, Mechanical structures for electronic equipment – Tests for IEC 60917 and
IEC 60297 series – Part 1: Environmental requirements, test set-up and safety aspects for
cabinets, racks, subracks and chassis under indoor condition use and transportation
IEC 61587-2, Mechanical structures for electronic equipment – Tests for IEC 60917 and
IEC 60297 – Part 2: Seismic tests for cabinets and racks
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following
addresses:
• IEC Electropedia: available at http://www.electropedia.org/
• ISO Online browsing platform: available at http://www.iso.org/obp
3.1
handle
mechanical component to open or close the door of a cabinet, equipped on the
door of the cabinet
3.2
key
device to allow only authorized access to a cabinet, assembled into the handle of
the cabinet or on the door of the cabinet
3.3
mechanical lock
mechanical component assembled in the door of a cabinet that secures the door to
the frame or other structural member of the cabinet and is operated by the handle
3.4
multipoint mechanical lock
system of more than one mechanical lock operated by a single handle
3.5
access security level
level of security against unauthorized access, determined by the security measures
needed to obtain access to the cabinet
Note 1 to entry: The access security level of an indoor cabinet depends on the type of installation site (building)
and on the cabinet's location in the building.
3.6
access protection
protection against unauthorized access to a cabinet
3.7
security performance
performance of the mechanical components of a cabinet to achieve the intended
protection against unauthorized access
Note 1 to entry: The mechanical components of the cabinet are shown in Figure 1.

– 8 – IEC 61587-6:2021 © IEC 2021
Multipoint
connection
parts to
handle
Figure 1 – Typical mechanical components for security provision of the cabinet
4 Security aspects for indoor cabinets
4.1 General
Security for electronic equipment should be designed from the point of view of both hardware
and software. With respect to the security of hardware installed in a cabinet, the security
aspects of the cabinet depend on the following factors:
a) access security level of the cabinet installation site (access security within the building);
b) security performance of the cabinet.
The access security within the building, as part of the physical security, is primarily aimed to
be effective against unauthorized forced entry. In this regard, many international or regional
regulations and specifications for building doors, gates, building door handles and key-locking
systems and other building physical security facilities are defined.

The security performance of the cabinet is determined by the choice of specific handle, key,
mechanical lock and other components, which are different from the hardware for buildings
and are mostly dedicated to cabinets for electrical and electronic systems.
Designers and users should consider those points properly to establish security aspects for
the intended use of the relevant indoor cabinet.
4.2 Access security level of the cabinet
In the case of the indoor cabinet, the access security level depends on building level
restrictions to reach the cabinet installation sites. Figure 2 and Table 1 show typical access
security levels in buildings or premises.
Security performance for the intended use cabinet should be appropriate for the access
security levels shown in Table 1. End users should use Table 1 to describe their installation
location to cabinet providers.

Figure 2 – Concept of access protection within buildings or premises
Table 1 – Access security levels of indoor cabinet installation sites
Access security Example – office Example – data Example –
level Access protection or laboratory centre factory
Public areas in Public areas in
Public areas in
No restriction to
AS0 building or building or building or
enter the site
premises premises premises
Restricted area to Reception Reception rooms
Reception rooms or
enter or access rooms or lobby or lobby areas of
lobby areas of
monitored and areas of data factory, inside
AS1 offices or
controlled by a centre gate/fence
laboratories within
person or video
buildings
surveillance
Severe restricted Offices or Server and Factory floor
AS2
area to enter laboratories networking area
Very severe Specific office or Servers and Server and
AS3 restriction to enter laboratories, or network in networking closets
the specific area. control rooms caged area in factory

– 10 – IEC 61587-6:2021 © IEC 2021
5 Security performance levels of cabinets
5.1 General
Table 2 shows security performance levels of cabinets and related security performance
levels of mechanical components.
Application of security performance levels of cabinets should be defined by the required
security measures of the cabinet-mounted electronic system and the access security levels of
the installation sites. Nevertheless, whatever the access security level of the installation site,
the security level of the cabinet may be chosen independently with reference to requirements
arising from the intended electronic system. Designers and users should study and clarify the
actual conditions of the installation site and the required security measures of the intended
electronic system, and apply the optimum security performance levels for cabinets.
Table 2 – Security performance levels of cabinets
Security performance levels of mechanical components
Security
Security Key Typical access security level
performance performance
Floor anchoring
(See Table 5)
levels of
level of cabinet –
cabinets
Mechanical
(See Table 6)
(See Table 3)
CS0 SK0/SK1 AS2, AS3
CS1 SK2 AS1
SH1
CS2 SK3 AS1, AS2
CS3 SK4 AS2, AS3
SA0/SA1/SA2
CS4 SK0/SK1 AS2
CS5 SK2 AS2
SH2
CS6 SK3 AS0, AS1
CS7 SK4 AS0, AS1
5.2 Security performance levels of cabinet – Mechanical
5.2.1 General
Table 3 shows security performance levels and required mechanical performances of the
cabinet.
Table 3 – Security performance levels of cabinet – Mechanical
Strength of Panel Environmental performances level
mechanical Strength
Operation
locks and
of handle
Security
hinges
and
performance
Climate Industrial
mechanical
Static
level of
Impact IP
conditions atmosphere
lock
loading
cabinet –
(IEC 61587-1) (IEC 60529)
test at
Mechanical
(IEC 61587-1) (IEC 61587-1)
Open/close
door
cycles
closed
position
SH1 200 N 100 N C1 A1 K1 IP20
200 N IP20;
> 10 000
IP30;
SH2 400 N C1/C2/C3 A1/A2/A3 K2/K3
IP42; IP54
5.2.2 Tests for strength of mechanical locks and hinges
Figure 3 shows the test method for assessing the strength of the mechanical locks and of the
door hinges. Loads are applied from the inside of the cabinet door in the direction indicated.
For further details on testing the strength of the handle as a stand-alone component see
Annex A (normative).
a) Handle, flat lever type b) Handle, lever type c) Handle, T-bar type

Figure 3 – Static loading test for mechanical lock and hinges
Criteria: After applying the static load (200 N or 400 N) 3 times, there shall be no deformation
of any of the components of the handle, mechanical lock, hinges, door, or cabinet that affect
form, fit, or function.
For multipoint mechanical locks each mechanical lock in the system is tested independently.

– 12 – IEC 61587-6:2021 © IEC 2021
Figure 3 shows the tests for typical handles and mechanical locks. When using different type
handles and mechanical locks designers and users should modify the test method above
according to the function of the specific handle or mechanical lock design.
5.2.3 Tests for operation of handle and mechanical lock
Table 4 indicates procedures for the tests of operation of handle and mechanical lock.
Table 4 – Test procedures for operation of handle and mechanical lock
Open/close cycles test procedures
Handle, lever type, with key
Handle, flat lever type, with key
Handle, T-bar type, with key
One test cycle includes operations 1 through 6. One test cycle includes operations 1 through 5.
The test cycle shall be repeated 10 000 times. The test cycle shall be repeated 10 000 times.
1) Start with the door closed and handle locked 1) Start with the door closed and handle locked
2) Unlock the handle 2) Unlock the handle
3) Pull-up the handle lever 3) Turn the handle lever or T-bar to the position that
allows the door to be opened
4) Turn the handle lever to the position that allows
the door to be opened 4) Return the handle lever or T-bar to the initial
position
5) Return the handle lever to the initial position
5) Lock the handle
6) Lock the handle
Criteria: After the test, there shall be no deformation of any of the components of the handle,
mechanical lock, or key that affect form, fit, or function.
Table 4 indicates the test procedures for typical handles. Different types of handles may
require a different procedure for unlock, door open, door close, and/or lock operation. In such
cases, the cycle test procedures should be modified according to the specific door operation.
5.2.4 Tests for panel strength
Loads are intended to be applied from inside the cabinet in the direction indicated in Figure 4.
If this is not practical then the panels may be modified to provide means to apply the loads
from the outside of the cabinet. The modification could be carried out by welding a pull tab or
stud to the panel or by drilling a hole and pulling on a bolt, tab, or stud positioned through the
hole. In any case the area loaded by the pulling device shall not exceed 100 mm . The
method of loading the panels shall be reported.

Figure 4 – Static loading test for panel strength
Criteria: After applying the static load (100 N or 200 N) 3 times, there shall be no deformation
of the panels or cabinet that affect form, fit, or function.
5.3 Key
Table 5 shows security performance levels for keys.
The "key codes" shown in Table 5 are key security numbers or key security values typically
used for cabinet doors according to IEC 60917 (all parts) and IEC 60297 (all parts), and
represent the number of key codes that are distinct enough to prevent closely matched key
codes from operating the same lock. Key pad entry is considered limited security as access
can be compromised by observation of the person gaining access to the cabinet. RFID or
magnetic card entry is considered medium security as cards can be compromised by the
possession of a stolen or copied card. Any form of biometric reader is considered high
security as it requires the presence of an authorized person for entry.

– 14 – IEC 61587-6:2021 © IEC 2021
Table 5 – Security performance levels of key
Security Key function Mechanical Application
performance key codes
Lever handle with Cabinet
level of key (minimum
key/mechanical door
number of
lock, or function
codes)
key/mechanical
lock only
SK0 No key --- No lock or No key No security
Uncontrolled key Basic commercial
SK1 --- Low security
distribution key mechanism
Controlled
mechanical key
Industrial key Limited
SK2 distribution, or 100
mechanism security
electronic/mechanical
key pad entry
Controlled security
mechanical key Medium
SK3 1 000 Security key
distribution, magnetic security
or RFID card entry
Controlled high
security mechanical
key distribution,
Precision security High
SK4 biometric reader 10 000
key security
entry, or entry
allowed by remote
authorization
According to user requests and intended applications, different types of keys, such as dial
key, registered number key and other precision key systems for the door entry control, may
be applied.
5.4 Cabinet floor anchoring
To secure the functionality of a cabinet, cabinet floor anchoring is considered a security
aspect as cabinet mobility may have to be restricted or even made impossible to protect from
external environmental occurrences or unwanted human interference.
Table 6 – Security performance level of cabinet floor anchoring
Security performance level Test method
of cabinet floor anchoring
SA0 No test
SA1 Tested in accordance with IEC 61587-1
SA2 Tested in accordance with IEC 61587-2

Annex A
(normative)
Mechanical performance and test methods for handles –
Mechanical strengths of levers of handles
A.1 General
The following mechanical strengths of levers of handles are common requirements, and they
should be applied for maintaining security performance levels of mechanical components.
A.2 Static loading test, push/pull performance
Lever handles shall perform according to the push/pull forces defined in Figure A.1.

– 16 – IEC 61587-6:2021 © IEC 2021

a) Handle, flat lever type b) Handle, lever type

c) Handle, T-bar type
Key
F force
L distance
Figure A.1 – Lever handles' push/pull performance
Test procedure: The testing of the handle shall be performed with a stable fixed apparatus.
The push/pull test shall be performed 3 times.
Criteria: No functional damage shall occur.
A.3 Static loading test, turn performance
Lever handle turn shall perform as defined in Figure A.2.

a) Handle, flat lever type b) Handle, lever type

c) Handle, T-bar type
Key
F force
L distance
Figure A.2 – Lever handles' turn performance
Test procedure: The testing of the handle shall be performed with a stable fixed apparatus.
The turn performance test shall be performed 3 times.
Criteria: No functional damage shall occur.

– 18 – IEC 61587-6:2021 © IEC 2021
Bibliography
ISO/IEC 27001, Information technology – Security techniques – Information security
management systems – Requirements

_____________
– 20 – IEC 61587-6:2021 © IEC:2021
SOMMAIRE
AVANT-PROPOS . 21
INTRODUCTION . 23
1 Domaine d'application . 24
2 Références normatives . 24
3 Termes et définitions . 24
4 Aspects liés à la sécurité des baies intérieures . 26
4.1 Généralités . 26
4.2 Niveau de sécurité d'accès de la baie . 27
5 Niveaux de performance de la sécurité des baies . 28
5.1 Généralités . 28
5.2 Niveaux de performance de la sécurité d'une baie – Mécanique . 29
5.2.1 Généralités . 29
5.2.2 Essai de force sur les charnières et les verrous mécaniques . 29
5.2.3 Essais de fonctionnement de la poignée et du verrou mécanique . 31
5.2.4 Essais de force sur les panneaux . 31
5.3 Clé . 32
5.4 Ancrage au sol d'une baie . 33
Annexe A (normative)  Performances mécaniques et méthodes d'essai pour les
poignées – Forces mécaniques des leviers de poignées . 34
A.1 Généralités . 34
A.2 Essai de charge statique, performance en pression/traction . 34
A.3 Essai de charge statique, performance en rotation . 36
Bibliographie . 37

Figure 1 – Composants mécaniques typiques destinés à la sécurité de la baie . 26
Figure 2 – Concept de protection d'accès à l'intérieur de bâtiments ou de locaux . 27
Figure 3 – Essai de charge statique pour charnières et verrous mécaniques . 30
Figure 4 – Essai de charge statique pour la force sur les panneaux . 32
Figure A.1 – Performance en pression/traction de levier de poignées . 35
Figure A.2 – Performance en rotation de levier de poignées . 36

Tableau 1 – Niveaux de sécurité d'accès de sites d'installation de baies intérieures . 28
Tableau 2 – Niveaux de performance de la sécurité des baies . 28
Tableau 3 – Niveaux de performance de la sécurité d'une baie – Mécanique . 29
Tableau 4 – Procédures d'essais de fonctionnement de la poignée et du verrou
mécanique . 31
Tableau 5 – Niveaux de performance de la sécurité des clés . 33
Tableau 6 – Niveau de performance de la sécurité de l'ancrage au sol d'une baie . 33

COMMISSION ÉLECTROTECHNIQUE INTERNATIONALE
____________
STRUCTURES MÉCANIQUES POUR
ÉQUIPEMENTS ÉLECTRIQUES ET ÉLECTRONIQUES – ESSAIS POUR LES
SÉRIES IEC 60917 ET IEC 60297 –

Partie 6: Aspects liés à la sécurité des baies intérieures

AVANT-PROPOS
1) La Commission Electrotechnique Internationale (IEC) est une organisation mondiale de normalisation composée
de l'ensemble des comités électrotechniques nationaux (Comités nationaux de l'IEC). L’IEC a pour objet de
favoriser la coopération internationale pour toutes les questions de normalisation dans les domaines de
l'électricité et de l'électronique. A cet effet, l'IEC – entre autres activités – publie des Normes internationales,
des Spécifications techniques, des Rapports techniques, des Spécifications accessibles au public (PAS) et des
Guides (ci-après dénommés "Publication(s) de l'IEC"). Leur élaboration est confiée à des comités d'études, aux
travaux desquels tout Comité national intéressé par le sujet traité peut participer. Les organisations
internationales, gouvernementales et non gouvernementales, en liaison avec l'IEC, participent également aux
travaux. L’IEC collabore étroitement avec l'Organisation Internationale de Normalisation (ISO), selon des
conditions fixées par accord entre les deux organisations.
2) Les décisions ou accords officiels de l'IEC concernant les questions techniques représentent, dans la mesure du
possible, un accord international sur les sujets étudiés, étant donné que les Comités nationaux de l'IEC intéressés
sont représentés dans chaque comité d’études.
3) Les Publications de l'IEC se présentent sous la forme de recommandations internationales et sont agréées
comme telles par les Comités nationaux de l'IEC. Tous les efforts raisonnables sont entrepris afin que l'IEC
s'assure de l'exactitude du contenu technique de ses publications; l'IEC ne peut pas être tenue responsable de
l'éventuelle mauvaise utilisation ou interprétation qui en est faite par un quelconque utilisateur final.
4) Dans le but d'encourager l'uniformité internationale, les Comités nationaux de l'IEC s'engagent, dans toute la
mesure possible, à appliquer de façon transparente les Publications de l'IEC dans leurs publications nationales
et régionales. Toutes divergences entre toutes Publications de l'IEC et toutes publications nationales ou
régionales correspondantes doivent être indiquées en termes clairs dans ces dernières.
5) L'IEC elle-même ne fournit aucune attestation de conformité. Des organismes de certification indépendants
fournissent des services d'évaluation de conformité et, dans certains secteurs, accèdent aux marques de
conformité de l’IEC. L'IEC n'est responsable d'aucun des services effectués par les organismes de certification
indépendants.
6) Tous les utilisateurs doivent s'assurer qu'ils sont en possession de la dernière édition de cette publication.
7) Aucune responsabilité ne doit être imputée à l'IEC, à ses administrateurs, employés, auxiliaires ou mandataires,
y compris ses experts particuliers et les membres de ses comités d'études et des Comités nationaux de l'IEC,
pour tout préjudice causé en cas de dommages corporels et matériels, ou de tout autre dommage de quelque
nature que ce soit, directe ou indirecte, ou pour supporter les coûts (y compris les frais de justice) et les dépenses
découlant de la publication ou de l'utilisation de cette Publication de l'IEC ou de toute autre Publication de l'IEC,
ou au crédit qui lui est accordé.
8) L'attention est attirée sur les références normatives citées dans cette publication. L'utilisation de publications
référencées est obligatoire pour une application correcte de la présente publication.
9) L'attention est attirée sur le fait que certains des éléments de la présente publication de l'IEC peuvent faire l'objet
de droits de brevet. L'IEC ne saurait être tenue pour responsable de ne pas avoir identifié de tels droits de brevets
et averti de leur existence.
La Norme internationale IEC 61587-6 a été établie par le sous-comité 48D: Structures
mécaniques pour les équipements électriques et électroniques, du comité d'études 48 de l'IEC:
Connecteurs électriques et structures mécaniques pour les équipements électriques et
électroniques.
Cette deuxième édition annule et remplace la première édition parue en 2017, dont elle
constitue une révision technique.
La présente édition inclut les modifications techniques majeures suivantes par rapport à
l'édition précédente:
a) Révision et ajout de termes et définitions.

– 22 – IEC 61587-6:2021 © IEC:2021
b) Ajout d'informations en 4.2, Niveau de sécurité d'accès de la baie.
c) Révision des exigences des niveaux de performance de la sécurité des baies et ajout de
niveaux supplémentaires dans le Tableau 2 – Niveaux de performance de la sécurité des
baies.
d) Ajout d'une colonne pour la force sur les panneaux dans le Tableau 3 – Niveaux de
performance de la sécurité des baies – mécanique.
e) Révision des essais sur les verrous mécaniques (et les charnières ajoutées) en 5.2.2
Essais de force sur les verrous mécaniques et les charnières.
f) Ajout de 5.2.4 Essais de force sur les panneaux.
g) Ajout d'une description supplémentaire de la fonction des clés dans le Tableau 5 –
Niveaux de performance de la sécurité des clés.
h) Révision de la méthode d'essai pour les poignées à l'Annexe A.
Le texte de cette Norme internationale est issu des documents suivants:
FDIS Rapport de vote
48D/736/FDIS 48D/737/RVD
Le rapport de vote indiqué dans le tableau ci-dessus donne toute information sur le vote ayant
abouti à l'approbation de cette Norme internationale.
Ce document a été rédigé selon les Directives ISO/IEC, Partie 2.
Une liste de toutes les parties de la série IEC 61587, publiées sous le titre général Stru
...
