IEC 62541-4:2020 defines the OPC Unified Architecture (OPC UA) Services. The Services defined are the collection of abstract Remote Procedure Calls (RPC) that are implemented by OPC UA Servers and called by OPC UA Clients. All interactions between OPC UA Clients and Servers occur via these Services. The defined Services are considered abstract because no particular RPC mechanism for implementation is defined in this document. IEC 62541-6 specifies one or more concrete mappings supported for implementation. For example, one mapping in IEC 62541-6 is to XML Web Services. In that case the Services described in this document appear as the Web service methods in the WSDL contract. Not all OPC UA Servers will need to implement all of the defined Services. IEC 62541-7 defines the Profiles that dictate which Services need to be implemented in order to be compliant with a particular Profile This third edition cancels and replaces the second edition published in 2015. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
a) Added ability to resend all data of monitored items in a Subscription using the ResendData Method.
b) Added support for durable Subscriptions (lifetime of hours or days).
c) Added Register2 and FindServersOnNetwork Services to support network-wide discovery using capability filters.
d) Removed definition of software certificates. Will be defined in a future edition.
e) Extended and partially revised the redundancy definition. Added sub-range definitions for ServiceLevel and added more terms for redundancy.
f) Added a section on how to use Authorization Services to request user access tokens.
g) Added JSON Web Tokens (JWTs) as a new user token.
h) Added the concept of session-less service invocation.
i) Added a generic structure that allows passing any number of attributes to the AddNodes Service.
j) Added requirement to protect against user identity token attacks.
k) Added new EncryptedSecret format for user identity tokens.
Architecture Unifiée OPC - Partie 4: Services
L'IEC 62541-4:2020 définit le modèle de communication Services de l'architecture unifiée OPC (OPC UA). Les Services définis sont le recueil d'appels de procédures abstraites distantes (RPC, Remote Procedure Call) qui sont mises en œuvre par les Serveurs OPC UA et qui sont appelées par les Clients OPC UA. Toutes les interactions entre Clients et Serveurs OPC UA ont lieu via ces Services. Les Services définis sont dits abstraits, car aucun mécanisme RPC particulier n'est spécifié dans le présent document pour leur mise en œuvre. L'IEC 62541-6 spécifie un ou plusieurs mécanismes concrets de mapping pour la mise en œuvre. Par exemple, dans l'IEC 62541-6, l'un des mécanismes de mapping repose sur l'utilisation des Services Web XML. Dans ce cas, les Services décrits dans le présent document apparaissent comme les méthodes de services Web dans le contrat WSDL. Il n'est pas nécessaire que l'ensemble des Serveurs OPC UA mettent en œuvre toutes les correspondances avec les messages et les protocoles de transport. L'IEC 62541-7 définit les Profils qui dictent les Services qu'il est nécessaire de mettre en œuvre afin d'être conforme à un Profil particulier. Cette troisième édition annule et remplace la deuxième édition parue en 2015. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a) ajout de la capacité à renvoyer toutes les données des éléments surveillés dans un abonnement à l'aide de la méthode ResendData;
b) ajout de la prise en charge pour les abonnements durables (durée de vie en heures ou en jours);
c) ajout des services Register2 et FindServersOnNetwork pour prendre en charge le mécanisme de découverte sur l'ensemble du réseau à l'aide de filtres de capacités;
d) suppression de la définition des certificats de logiciel (seront définis dans une édition ultérieure);
e) enrichissement et révision partielle de la définition de la redondance; ajout de définitions des sous plages pour ServiceLevel et ajout de termes supplémentaires pour la redondance;
f) ajout d'un paragraphe expliquant comment utiliser les Services d'autorisation pour demander des jetons d'accès utilisateur;
g) ajout des jetons JSON Web (JWT) comme nouveau jeton d'utilisateur;
h) ajout du concept d'invocation de service sans session;
i) ajout d'une structure générique permettant de transmettre n'importe quel nombre d'attributs dans le service AddNotes;
j) ajout d'une exigence relative à la protection contre les attaques de jeton d'identité utilisateur;
k) ajout du nouveau format EncryptedSecret pour les jetons d'identité utilisateur.
