IEC 60384-4-1:2000

INTERNATIONAL IEC
STANDARD
60384-4-1
QC 300301
Second edition
2000-05
Fixed capacitors for use in electronic equipment –
Part 4:
Blank detail specification –
Aluminium electrolytic capacitors
with non-solid electrolyte –
Assessment level E
Condensateurs fixes utilisés dans les équipements
électroniques –
Partie 4:
Spécification particulière-cadre –
Condensateurs électrolytiques à l'aluminium
à électrolyte non solide –
Niveau d'assurance E
Reference number
Numbering
As from 1 January 1997 all IEC publications are issued with a designation in the
60000 series.
Consolidated publications
Consolidated versions of some IEC publications including amendments are

available. For example, edition numbers 1.0, 1.1 and 1.2 refer, respectively, to the
base publication, the base publication incorporating amendment 1 and the base

publication incorporating amendments 1 and 2.

Validity of this publication
The technical content of IEC publications is kept under constant review by the IEC,
thus ensuring that the content reflects current technology.
Information relating to the date of the reconfirmation of the publication is available
in the IEC catalogue.
Information on the subjects under consideration and work in progress undertaken
by the technical committee which has prepared this publication, as well as the list
of publications issued, is to be found at the following IEC sources:
• IEC web site*
•
Catalogue of IEC publications
Published yearly with regular updates
(On-line catalogue)*
• IEC Bulletin
Available both at the IEC web site* and as a printed periodical
Terminology, graphical and letter symbols
For general terminology, readers are referred to IEC 60050: International
Electrotechnical Vocabulary (IEV).
For graphical symbols, and letter symbols and signs approved by the IEC for
general use, readers are referred to publications IEC 60027: Letter symbols to be
used in electrical technology, IEC 60417: Graphical symbols for use on equipment.
Index, survey and compilation of the single sheets and IEC 60617: Graphical symbols
for diagrams.
* See web site address on title page.

INTERNATIONAL IEC
STANDARD
60384-4-1
QC 300301
Second edition
2000-05
Fixed capacitors for use in electronic equipment –
Part 4:
Blank detail specification –
Aluminium electrolytic capacitors
with non-solid electrolyte –
Assessment level E
Condensateurs fixes utilisés dans les équipements
électroniques –
Partie 4:
Spécification particulière-cadre –
Condensateurs électrolytiques à l'aluminium
à électrolyte non solide –
Niveau d'assurance E
 IEC 2000  Copyright - all rights reserved
No part of this publication may be reproduced or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without permission in writing from the publisher.
International Electrotechnical Commission 3, rue de Varembé Geneva, Switzerland
Telefax: +41 22 919 0300 e-mail: inmail@iec.ch IEC web site http://www.iec.ch
Commission Electrotechnique Internationale
PRICE CODE
P
International Electrotechnical Commission
For price, see current catalogue

– 2 – 60384-4-1  IEC:2000(E)
INTERNATIONAL ELECTROTECHNICAL COMMISSION

____________
FIXED CAPACITORS FOR USE IN ELECTRONIC EQUIPMENT –

Part 4: Blank detail specification –

Aluminium electrolytic capacitors with non-solid electrolyte –

Assessment level E
FOREWORD
1) The IEC (International Electrotechnical Commission) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of the IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, the IEC publishes International Standards. Their preparation is
entrusted to technical committees; any IEC National Committee interested in the subject dealt with may
participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. The IEC collaborates closely with the International
Organization for Standardization (ISO) in accordance with conditions determined by agreement between the
two organizations.
2) The formal decisions or agreements of the IEC on technical matters express, as nearly as possible, an
international consensus of opinion on the relevant subjects since each technical committee has representation
from all interested National Committees.
3) The documents produced have the form of recommendations for international use and are published in the form
of standards, technical specifications, technical reports or guides and they are accepted by the National
Committees in that sense.
4) In order to promote international unification, IEC National Committees undertake to apply IEC International
Standards transparently to the maximum extent possible in their national and regional standards. Any
divergence between the IEC Standard and the corresponding national or regional standard shall be clearly
indicated in the latter.
5) The IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with one of its standards.
6) Attention is drawn to the possibility that some of the elements of this International Standard may be the subject
of patent rights. The IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 60384-4-1 has been prepared by IEC technical committee 40:
Capacitors and resistors for electronic equipment.
This second edition cancels and replaces the first edition published in 1985, amendment 1
(1992) and amendment 2 (1996). This second edition constitutes a technical revision.
The text of this standard is based on the first edition, amendment 1, amendment 2 and the

following documents:
FDIS Report on voting
40/1123/FDIS 40/1169/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 3.
The QC number that appears on the front cover of this publication is the specification number
of the IEC Quality Assessment System for Electronic Components (IECQ).

60384-4-1  IEC:2000(E) – 3 –
The committee has decided that the contents of this publication will remain unchanged until
2003. At this date, the publication will be

• reconfirmed;
• withdrawn;
• replaced by a revised edition; or

• amended.
A bilingual version of this standard may be issued at a later date.

– 4 – 60384-4-1  IEC:2000(E)
FIXED CAPACITORS FOR USE IN ELECTRONIC EQUIPMENT –

Part 4: Blank detail specification –

Aluminium electrolytic capacitors with non-solid electrolyte –

Assessment level E
Blank detail specification
A blank detail specification is a supplementary document to the sectional specification and
contains requirements for style and layout and minimum content of detail specifications. Detail
specifications not complying with these requirements may not be considered as being in
accordance with IEC specifications nor shall they be so described.
In the preparation of detail specifications, the contents of 1.4 of the sectional specification
shall be taken into account.
The numbers between brackets on the first page correspond to the following information
which shall be inserted in the position indicated.
Identification of the detail specification
[1] The International Electrotechnical Commission or the National Standards Organization
under whose authority the detail specification is drafted.
[2] The IEC or National Standards number of the detail specification, data of issue and any
further information required by the national system.
[3] The number and issue number of the IEC or national generic specification.
[4] The IEC number of the blank detail specification.
Identification of the capacitor
[5] A short description of the type of capacitor.
[6] Information on typical construction (when applicable).
NOTE When the capacitor is not designed for use in printed board applications, this is clearly stated in the
detail specification in this position.

[7] Outline drawing with main dimensions which are of importance for interchangeability
and/or reference to the national or international documents for outlines. Alternatively, this
drawing may be given in an annex to the detail specification.
[8] Application or group of applications covered and/or assessment level.
NOTE The assessment level(s) to be used in a detail specification are selected from 3.5.4 of the sectional
specification. This implies that one blank detail specification may be used in combination with several
assessment levels, provided the grouping of the tests does not change.
[9] Reference data on the most important properties, to allow comparison between the
various capacitor types.
60384-4-1  IEC:2000(E) – 5 –
[1] IEC 60384-4-1-XXX [2]
QC 300301-XXX
ELECTRONIC COMPONENTS OF ASSESSED IEC 60384-4-1 [4]

QUALITY IN ACCORDANCE WITH:
QC 300301
ALUMINIUM ELECTROLYTIC [5]
[3]
CAPACITORS WITH
NON-SOLID ELECTROLYTE
Outline drawing: (see table 1)

(. angle projection)
[7]
[6]
(Other shapes are permitted within Assessment level(s): E [8]
the dimensions given.)
Performance grade:
Information on the availability of components qualified to this
detail specification is given in the Qualified Products List.
[9]
– 6 – 60384-4-1  IEC:2000(E)
1 General data
1.1 Recommended method(s) of mounting (to be inserted)

(See 1.4.2 of IEC 60384-4.)
1.2 Dimensions
Table 1
Dimensions
mm or in and mm
Case size reference
LH d .
∅
NOTE 1 When there is no case size reference, table 1 may be omitted and the dimensions given in table 2a,
which then becomes table 1.
NOTE 2 The dimensions are given as maximum dimensions or as nominal dimensions with a tolerance.
1.3 Ratings and characteristics
Capacitance range (see table 2a)
Tolerance on rated capacitance
Rated voltage (see table 2a)
Category voltage (if applicable) (see table 2a)
Climatic category
Rated temperature
Rated ripple current (see table 2b)
Tangent of loss angle (see table 2b)
NOTE Instead of the tangent of loss angle (tan δ), the equivalent series resistance ESR may be specified in
accordance with 4.3.3.2 d) of IEC 60384-4.
Leakage current
Impedance (if applicable) (see table 2b)

Reverse voltage (if required)
Insulation resistance (if applicable)
Table 2a – Values of capacitance and of voltage related to case sizes
Rated voltage
Category voltage*
Case size Case size Case size Case size
Rated capacitance
μF
* If different from the rated voltage.

60384-4-1  IEC:2000(E) – 7 –
Table 2b – Tangent of loss angle, impedance and rated ripple current

U C Tangent of loss angle Impedance at . °C, Rated ripple current
R R
at . °C, . Hz . Hz (if applicable) at . °C, . Hz
V μF Ω
A
1.4 Rated documents
Generic specification: IEC 60384-1
Sectional specification: IEC 60384-4
1.5 Marking
The marking of the capacitor and the package shall be in accordance with the requirements of
1.6 of IEC 60384-4.
NOTE The details of the marking of the component and package are given in full in the detail specification.
1.6 Ordering information
Orders for capacitors covered by this specification shall contain, in clear or in coded form, the
following minimum information:
a) Rated capacitance.
b) Tolerance on rated capacitance.
c) Rated d.c. voltage.
d) Number and issue reference of the detail specification and style reference.
1.7 Certified records of released lots
Required/not required.
1.8 Additional information (not for inspection purposes)
1.9 Additional or increased severities or requirements to those specified in the
generic and/or sectional specification
NOTE Additions or increased requirements should be specified only when essential.
Table 3 – Other characteristics
This table is to be used for defining characteristics
which are additional to, or more severe than, those
given in the sectional specification.

– 8 – 60384-4-1  IEC:2000(E)
2 Inspection requirements
2.1 Procedures
2.1.1 For Qualification Approval, the procedures shall be in accordance with 3.4 of the

sectional specification, IEC 60384-4.

2.1.2 For Quality Conformance Inspection, the test schedule (table 4) includes sampling,

periodicity, severities and requirements. The formation of inspection lots is covered by 3.5.1

of the sectional specification.

Table 4 – Test schedule
Subclause number D or Conditions IL AQL Performance
and test ND of test requirements
(see Note 1) (see Note 1) (see Note 2) (see Note 1)
Group A inspection
(lot-by-lot)
Subgroup A1 ND S-4 2,5 %
4.2 Visual examination As in 4.2
Legible marking and as specified in
1.5 of this specification
4.2 Dimensions As specified in table 1 of this
(gauging) specification
Subgroup A2 ND II 1,0 %
4.3.1 Leakage As in 4.3.1.2
Protective resistance: . Ω
4.3.2 Capacitance Frequency: . Hz Within specified tolerance
4.3.3 Tangent of Frequency: . Hz As in 4.3.3.2
loss angle
4.3.4 Impedance Frequency: . Hz Within limit specified
(if applicable) in the detail specification

60384-4-1  IEC:2000(E) – 9 –
Subclause number D Conditions Performance

IL AQL
and test or of test requirements

ND
(see Note 1) (see Note 1) (see Note 2) (see Notes 1 and 5)

Group B inspection
(lot-by-lot)
Subgroup B1 ND S-3 2,5 %
4.6 Solderability* Method: . Good tinning as evidenced by

free flowing of the solder with

wetting of the terminations or

solder shall flow within . s,
as applicable
4.17.1 Initial measurement Capacitance
4.17 Storage at Temperature:
high temperature Upper category temperature
(if required)
Duration: 96 h ± 4 h
Recovery: 16 h min.
4.17.3 Final measurements Visual examination No visible damage and no
leakage of electrolyte
Leakage current
≤2 times the limits in 4.3.1
Capacitance
ΔC/C ≤ 10 % of value measured
in 4.17.1
Tangent of loss angle
≤1,2 times the limit in 4.3.3
Subgroup B2 ND S-3 2,5 %
4.19 Characteristics The capacitors shall be
at high and low measu
...
