HD 120 S1:1977
(Main)Characteristic impedances and dimensions of radio-frequency coaxial cables
Characteristic impedances and dimensions of radio-frequency coaxial cables
Gives rated characteristic impedances of coaxial, twin conductor and dual coaxial cables. Specifies standard diameters over dielectric for coaxial and flexible twin cables.
Wellenwiderstand und Abmessungen von HF-Koaxialkabel
Impédances caractéristiques et dimensions des câbles coaxiaux pour fréquences radioélectriques
Donne les impédances caractéristiques nominales des câbles coaxiaux simples ou jumelés, ainsi que des câbles en paires. Spécifie les diamètres normaux sur le diélectrique des câbles coaxiaux et bifilaires souples.
Characteristic impedance and dimesions of radi-frquency coaxial cables
General Information
- Status
- Withdrawn
- Publication Date
- 14-May-1977
- Withdrawal Date
- 28-Feb-2006
- Technical Committee
- CLC/TC 46X - Communication cables
- Drafting Committee
- CLC/SC 46XA - Coaxial cables
- Parallel Committee
- IEC/SC 46A - IEC_SC_46A
- Current Stage
- 9960 - Withdrawal effective - Withdrawal
- Start Date
- 01-Mar-2006
- Completion Date
- 01-Mar-2006
Frequently Asked Questions
HD 120 S1:1977 is a standardization document published by CLC. Its full title is "Characteristic impedances and dimensions of radio-frequency coaxial cables". This standard covers: Gives rated characteristic impedances of coaxial, twin conductor and dual coaxial cables. Specifies standard diameters over dielectric for coaxial and flexible twin cables.
Gives rated characteristic impedances of coaxial, twin conductor and dual coaxial cables. Specifies standard diameters over dielectric for coaxial and flexible twin cables.
HD 120 S1:1977 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
