EN 62689-1:2016
(Main)Current and voltage sensors or detectors, to be used for fault passage indication purposes - Part 1: General principles and requirements
Current and voltage sensors or detectors, to be used for fault passage indication purposes - Part 1: General principles and requirements
IEC 62689-1:2016 defines the minimum requirements (therefore performances) and consequent classification and tests (with the exception of functional and communication ones) for fault passage indicators (FPIs) and distribution substation units (DSUs) (including their current and/or voltage sensors), which are, respectively, a device or a device/combination of devices and/or functions able to detect faults and provide indications about their localization.
Strom- und Spannungs-Sensoren oder Anzeigegeräte zur Erkennung von Kurz- und Erdschlüssen - Teil 1: Allgemeine Grundsätze und Anforderungen
Capteurs ou détecteurs de courant et de tension, à utiliser pour indiquer le passage d'un courant de défaut - Partie 1: Exigences et principes généraux
L'IEC 62689-1:2016 définit les exigences (et donc les performances) minimales, ainsi que les classifications des essais qui en découlent (à l'exception des essais fonctionnels et de communications) pour les indicateurs de passage de courant de défaut (FPI) et les unités de poste de distribution (DSU) (y compris pour leurs capteurs de courant et/ou de tension) qui sont respectivement matérialisés par un dispositif ou un dispositif/une combinaison de dispositifs et/ou de fonctions pouvant détecter des défauts et les localiser.
Tokovna in napetostna zaznavala ali detektorji, ki se uporabljajo za javljanje mesta okvare - 1. del: Sistemski vidiki (IEC 62689-1:2016)
Ta del standarda IEC 62689 določa minimalne zahteve (in s tem zmogljivosti) in posledično razvrstitev ter preskuse (z izjemo funkcionalnih in komunikacijskih preskusov) za javljalnike mesta okvare (FPI) in distribucijske postaje (DSU) (vključno z njihovimi zaznavali za tok in/ali napetost), ki so naprava ali naprava/skupek naprav in/ali funkcij, ki lahko zaznajo okvare in podajo indikacije glede njihove lokalizacije.
Lokalizacija okvare pomeni mesto okvare glede na mesto namestitve javljalnika mesta okvare/distribucijske postaje v omrežju (na visoko- ali nizkonapetostni strani glede na javljalnik mesta okvare/distribucijsko postajo) ali smer okvarnega toka, ki teče skozi javljalnik mesta okvare/distribucijsko postajo. Lokalizacija okvare se lahko pridobi
• neposredno od javljalnika mesta okvare/distribucijske postaje ali
• pri centralnem sistemu z uporabo informacij več javljalnikov mesta okvare ali distribucijskih postaj,
ob upoštevanju lastnosti in obratovalnih pogojev električnega sistema, v katerem so nameščeni javljalniki mesta okvare/distribucijske postaje.
V tem delu standarda IEC 62689 je podrobno določena razvrstitev javljalnikov mesta okvare/distribucijskih postaj v skladu s prvo »osnovno« razvrstitvijo, opredeljeno v standardu IEC 62689-2, ki se izrecno osredotoča na opis električnih pojavov in odziv električnega sistema v času okvar, ob upoštevanju najbolj razpršene arhitekture distribucijskega omrežja in tipologij okvar.
Zato je standard IEC 62689-2 osredotočen predvsem na pomoč uporabnikom pri pravilni izbiri javljalnikov mesta okvare/distribucijskih postaj, medtem ko so standardi IEC 62689-1, IEC 62689-3 in IEC 62689-4 osredotočeni predvsem na zahteve, komunikacijo in preskusne postopke za javljalnike mesta okvare/distribucijske postaje.
