EN 61029-2-12:2011

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Sicherheit transportabler motorbetriebener Elektrowerkzeuge - Teil 2-12: Besondere Anforderungen für GewindeschneidmaschinenSécurité des machines-outils électriques semi-fixes - Partie 2-12: Exigences particulières pour les machines à fileterSafety of transportable motor-operated electric tools -- Part 2-12: Particular requirements for threading machines59.120.01Tekstilni stroji na splošnoTextile machinery in general25.140.20Electric toolsICS:Ta slovenski standard je istoveten z:EN 61029-2-12:2011SIST EN 61029-2-12:2011en,fr,de01-junij-2011SIST EN 61029-2-12:2011SLOVENSKI
STANDARD
EUROPEAN STANDARD EN 61029-2-12 NORME EUROPÉENNE
EUROPÄISCHE NORM April 2011
CENELEC European Committee for Electrotechnical Standardization Comité Européen de Normalisation Electrotechnique Europäisches Komitee für Elektrotechnische Normung
Management Centre: Avenue Marnix 17, B - 1000 Brussels
© 2011 CENELEC -
All rights of exploitation in any form and by any means reserved worldwide for CENELEC members.
Ref. No. EN 61029-2-12:2011 E
ICS 25.080.99; 25.100.50
English version
Safety of transportable motor-operated electric tools -
Part 2-12: Particular requirements for threading machines
(IEC 61029-2-12:2010, modified)
Sécurité des machines-outils électriques semi-fixes -
Partie 2-12: Exigences particulières pour les machines à fileter (CEI 61029-2-12:2010, modifiée)
Sicherheit transportabler motorbetriebener Elektrowerkzeuge -
Teil 2-12: Besondere Anforderungen für Gewindeschneidmaschinen (IEC 61029-2-12:2010, modifiziert)
This European Standard was approved by CENELEC on 2011-01-02. CENELEC members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the Central Secretariat or to any CENELEC member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CENELEC member into its own language and notified to the Central Secretariat has the same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and the United Kingdom.
(dop)
2012-01-02 – latest date by which the national standards conflicting with the amendment have to be withdrawn
(dow)
2014-01-02 This European Standard is divided into two parts: Part 1 General requirements, which are common to most transportable motor, operated tools (for the purpose of this European Standard referred to simply as tools) which could come within the scope of this European Standard. Part 2 Requirements for particular types of tool which either supplement or modify the requirements given in Part 1 to account for the particular hazards and characteristics of these specific tools. This European Standard has been prepared under Mandate M/396 given to CENELEC by the European Commission and the European Free Trade Association and covers essential requirements of EU Directive 2006/42/EC. See Annex ZZ. Compliance with the relevant clauses of Part 1 together with a relevant Part 2 of this European Standard provides one means of confirming with the specified essential requirements of the Directive. For noise and vibration this European Standard covers the requirements for their measurement, the provisions of information arising from these measurements and the provision of information about the Personal Protective Equipment required. Specific requirements for the reduction of the risk arising from noise and vibration through the design of the tool are not given as this reflects the current state of art. Warning: Other requirements arising from other European Directives can be applicable to the products falling within the scope of this European Standard. CEN have prepared standards for industrial machines, which may extend transportable machines. Although CEN and CENELEC have where appropriate used common solutions to provide uniform levels of protection, person using this European Standard should check the scope of both this and CEN standards to ensure that a correct standard is used.
This Part 2-12 is to be used in conjunction with EN 61029-1:2009. This Part 2-12 supplements or modifies the corresponding clauses of EN 61029-1, so as to convert it into the European Standard: “Particular requirements for threading machines”. SIST EN 61029-2-12:2011

- 3 - EN 61029-2-12:2011 Where a particular subclause of Part 1 is not mentioned in this Part 2-12, that subclause applies as far as reasonable. Where this Part 2-12 states "addition" "modification" or "replacement", the relevant text of Part 1 is to be adapted accordingly. NOTE In this European Standard the following print types are used: - requirements proper: in roman type; - test specifications: in italic type;
- explanatory matter: in smaller roman type. The terms defined in Clause 2 are printed in bold typeface. Clauses, subclauses, notes, tables and figures which are additional to those in Part 1 are numbered starting from 101. Clauses, subclauses, notes, tables and figures which are additional to those in IEC 61029-2-12:2010 are prefixed "Z". The common modifications towards IEC 61029-2-12:2010 are identified by a vertical line in the left margin. SIST EN 61029-2-12:2011

- 5 - EN 61029-2-12:2011 1 Scope This clause of Part 1 is applicable except as follows: 1.1 Addition: This European Standard applies to pipe threading tools that create external threads by rotating either the workpiece or the cutting head. 2 Definitions This clause of Part 1 is applicable except as follows: 2.21 Replacement: normal load load to obtain rated input 2.101 threading machine tool that is capable of creating an external thread through a mechanical process such as cutting or forming 2.102 BSPT style threads British Standard Pipe Taper style threads: 55 degree pressure-tight taper pipe threads (R) per ISO 7-1 2.103 NPT style threads National Pipe Taper style threads: 60 degree pressure-tight taper pipe threads (NPT) per ANSI/ASME B1.20.2M 3 General requirement This clause of Part 1 is applicable. 4 General notes on tests This clause of Part 1 is applicable. 5 Rating This clause of Part 1 is applicable. 6 Classification This clause of Part 1 is applicable. SIST EN 61029-2-12:2011

tool is to be used, a translation into that/those language(s) shall be provided by the manufacturer or his authorised representative or by the person bringing the tool into the language area in question. The translations shall bear the words ‘Translation of the original instructions’ and they shall be accompanied by a copy of the ‘Original instructions’. 7.13.101 Safety warnings The safety warnings specified in 7.13.101.1 and 7.13.101.2, if in English, shall be verbatim and in the exact order as given and in any other official language to be equivalent. Format of all safety instructions must differentiate, by font highlighting or similar means, the context of the clauses as illustrated below. All notes in the safety warnings are not to be printed, they are information for the designer of the manual. 7.13.101.1 General power tool safety warnings
WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. 1)
Work area safety a)
Keep work area clean and well lit. Cluttered or dark areas invite accidents. b)
Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. c)
Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. SIST EN 61029-2-12:2011

- 7 - EN 61029-2-12:2011 2)
Electrical safety a)
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. b)
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock
...
