EN 13927:2003

Overview

EN 13927:2003 is a European Standard developed by CEN that establishes general requirements for equipment used in non-destructive visual testing. Visual testing is a key method in non-destructive testing (NDT) applied to assess the condition of materials, components, or structures without causing damage. This standard primarily addresses the selection, application, and verification of equipment that enhances the visual accessibility, sensitivity, and imaging record capabilities necessary for thorough inspection.

The standard is relevant when direct visual inspection is not possible due to object accessibility or environmental conditions, or when enhanced test sensitivity or documentation through imaging is required. It provides a comprehensive framework for ensuring equipment reliability, safety, and suitability in various testing conditions including underwater and ionizing radiation environments.

Key Topics

Equipment Classification and Use

• Differentiates between direct and remote visual testing methods.
• Includes equipment such as lighting sources, lenses, mirrors, endoscopes, video cameras, and image recording devices.
• Covers essential accessories like resolution targets and graticules for accurate measurement and calibration.

Verification Procedures

• Emphasizes regular verification of equipment to ensure operational performance throughout testing.
• Verification includes checking optical, mechanical, and electronic capabilities versus test documentation specifications.
• Recommends initial and final verification for each test session, with periodic checks during extended testing periods.
• Details parameters to document during verification such as illumination, target characteristics, distance, and magnification.

Equipment Selection Criteria

• Lighting: Intensity, beam geometry, spectral range, and light frequency must be matched to inspection needs.
• Resolution Targets: Selected based on size, contrast, viewing method, and magnification relevant to the test environment.
• Mirrors and Lenses: Consider flatness, reflectivity, resolution, chromatic aberration, and distortion to optimize image quality.
• Endoscopes and Videoscopes: Selected according to direction of view, field of view, flexibility, and diameter.
• Cameras and Monitors: Requirements include resolution, sensitivity, shutter speed, color capability, and image refresh rate.
• Remote Systems: Must provide adequate range of motion, control precision, and reliable image data transmission.

Environmental Considerations

• Underwater use demands corrosion resistance, water tightness, and gas bubble control.
• Exposure to ionizing radiation requires equipment resistant to radiation damage and designed for quick, safe handling and decontamination.

Applications

EN 13927:2003 is applied across industries where non-destructive visual testing is essential:

• Manufacturing and Quality Control: Inspecting components for surface defects when direct visibility is obstructed.
• Aerospace and Automotive: Ensuring integrity of critical parts using remotely operated scopes and cameras.
• Infrastructure and Construction: Assessing bridges, pipelines, and access-restricted structures.
• Energy Sector: Visual inspection in radiation environments such as nuclear plants.
• Underwater Inspection: Corrosion monitoring and structural assessment of submerged assets.

By standardizing equipment requirements and verification processes, EN 13927 enhances the reliability and accuracy of visual testing, helping organizations meet safety regulations and quality standards efficiently.

Related Standards

• EN 1330-10:2003 – Terminology for Non-Destructive Testing, specifically terms used in visual testing.
• EN 13018:2001 – General Principles for Visual Testing methods.
• ISO 3057 – Metallographic replica techniques which may be used as aids in surface examinations.
• ISO 3058 – Guidelines for selecting low-power magnifiers assisting visual inspection.

These standards complement EN 13927 by providing detailed definitions, principles, and auxiliary methods crucial for comprehensive non-destructive visual inspections.
