EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 13605
June 2013 ICS 77.150.30 Supersedes EN 13605:2002English Version
Copper and copper alloys - Copper profiles and profiled wire for electrical purposes
Cuivre et alliages de cuivre - Profilés et fils profilés en cuivre pour usages électriques
Kupfer und Kupferlegierungen - Profile und profilierte Drähte aus Kupfer für die Anwendung in der ElektrotechnikThis European Standard was approved by CEN on 25 April 2013.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2013 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 13605:2013: ESIST EN 13605:2013

Characteristics of coppers for electrical purposes . 25 Bibliography . 27
Figures Figure 1 — Profile within a circumscribing circle . 11 Figure 2 — Cross-sectional dimensions . 11 Figure 3 — Twist of a profile . 12 Figure 4 — Indication of flatness on a U-Profile . 13 Figure 5 — Indication of flatness on a H-Profile . 13 Figure 6 — Indication of angularity . 13 Figure 7 — Indication of perpendicularity . 13 Figure 8 — Indication of straightness tolerances . 14 SIST EN 13605:2013

Tables Table 1 — Composition of unalloyed copper grades . 18 Table 2 — Composition of copper grades . 19 Table 3 — Mechanical properties . 20 Table 4 — Electrical properties (at 20 °C) . 21 Table 5 — Tolerances for dimensions b and h, ratio bmax. or hmax. to smin. < 20 : 1 . 21 Table 6 — Tolerances for dimensions b and h, ratio bmax. or hmax. to smin. ≥ 20 : 1 . 22 Table 7 — Thickness tolerances . 22 Table 8 — Radius tolerances . 22 Table 9 — Maximum radii of sharp corners . 22 Table 10 — Twist tolerances — coefficient f . 23 Table 11 — Straightness tolerances for profiles . 23 Table 12 — Tolerances on "as manufactured" lengths . 23 Table 13 — Tolerances on "fixed" lengths . 24 Table 14 — Sampling rate . 24 Table A.1 — Particular characteristics of coppers for electrical purposes . 26
 if hollow, the external contour and/or the internal contour of its cross-section is (are) complex. 3.2 profiled wire particular type of wire, i.e. a wrought product of uniform cross-section along its whole length, supplied in coiled form Note 1 to entry: It may be solid or hollow:  if solid, the contour of its cross-section is complex;
 if hollow the external contour and/or the internal contour of its cross-section is (are) complex. SIST EN 13605:2013

Profile — EN 13605 — Cu-ETP — H080 — XY000 — 3000ML
or
Profile — EN 13605 — CW004A — H080 — XY000 — 3000ML Denomination Number of this European Standard Material designation Material condition designation Drawing number Length in millimetres EXAMPLE 2 Profiled wire for electrical purposes conforming to this standard, in material designated either CuAg0,10 or CW013A in material condition H035, drawing number BC000, in coils, will be designated as follows:
Profiled wire EN 13605 — CuAg0,10 — H035 — BC000 — Y
or
Profiled wire EN 13605 — CW013A — H035 — BC000 — Y 5 Ordering information In order to facilitate the enquiry, order and confirmation of order procedures between the purchaser and the supplier, the purchaser shall state on his enquiry and order the following information: a) quantity of product required (mass, number of profiles or number of coils or spools); b) denomination (profile or profiled wire); c) number of this European Standard (EN 13605); d) material designation (see Table 1 and Table 2); e) material condition designation (see 4.2 and Table 3); SIST EN 13605:2013

1 000 pieces Profile EN 13605 — Cu-ETP — H080 — XY123 — 3 000ML
or
1 000 pieces Profile EN 13605 — CW004A — H080 — XY123 — 3 000ML EXAMPLE 2 Ordering details for 2 000 kg of profiled wire for electrical purposes conforming to EN 13605, in material designated either CuAg0,10 or CW013A, in material condition H035, drawing number BC123, in 250 kg coils:
2 000 kg Profiled wire EN 13605 — CuAg0,10 — H035 — BC123 — Y—250
or
2 000 kg Profiled wire EN 13605 — CW013A — H035 — BC123 — Y—250 SIST EN 13605:2013

Figure 1 — Profile within a circumscribing circle The tolerances specified on drawings shall conform to the requirements of this standard. If no tolerances are specified on the drawings of profiles, the specifications in this standard apply. It is advisable to make a suitable reference to this standard on the drawings. If required, tighter tolerances than those specified shall be agreed between the purchaser and the supplier. NOTE Dimensional tolerances are influenced by
...
