INTERNATIONAL ISO
STANDARD 10434
Second edition
2004-07-15
Bolted bonnet steel gate valves for the
petroleum, petrochemical and allied
industries
Robinets-vannes en acier à chapeau boulonné pour les industries du
pétrole, de la pétrochimie et les industries connexes

Reference number
ISO 10434:2004(E)
©
ISO 2004
ISO 10434:2004(E)
PDF disclaimer
This PDF file may contain embedded typefaces. In accordance with Adobe's licensing policy, this file may be printed or viewed but
shall not be edited unless the typefaces which are embedded are licensed to and installed on the computer performing the editing. In
downloading this file, parties accept therein the responsibility of not infringing Adobe's licensing policy. The ISO Central Secretariat
accepts no liability in this area.
Adobe is a trademark of Adobe Systems Incorporated.
Details of the software products used to create this PDF file can be found in the General Info relative to the file; the PDF-creation
parameters were optimized for printing. Every care has been taken to ensure that the file is suitable for use by ISO member bodies. In
the unlikely event that a problem relating to it is found, please inform the Central Secretariat at the address given below.

©  ISO 2004
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means,
electronic or mechanical, including photocopying and microfilm, without permission in writing from either ISO at the address below or
ISO's member body in the country of the requester.
ISO copyright office
Case postale 56 • CH-1211 Geneva 20
Tel. + 41 22 749 01 11
Fax + 41 22 749 09 47
E-mail copyright@iso.org
Web www.iso.org
Published in Switzerland
ii © ISO 2004 – All rights reserved

ISO 10434:2004(E)
Contents Page
Foreword. iv
Introduction . v
1 Scope. 1
2 Normative references . 1
3 Terms and definitions. 3
4 Pressure/temperature ratings. 3
5 Design . 3
6 Materials. 18
7 Testing, inspection and examination. 21
8 Marking. 24
9 Preparation for despatch. 25
Annex A (informative) Information to be specified by the purchaser . 27
Annex B (informative) Identification of valve terms. 28
Bibliography . 30

ISO 10434:2004(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards bodies
(ISO member bodies). The work of preparing International Standards is normally carried out through ISO
technical committees. Each member body interested in a subject for which a technical committee has been
established has the right to be represented on that committee. International organizations, governmental and
non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely with the
International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization.
International Standards are drafted in accordance with the rules given in the ISO/IEC Directives, Part 2.
The main task of technical committees is to prepare International Standards. Draft International Standards
adopted by the technical committees are circulated to the member bodies for voting. Publication as an
International Standard requires approval by at least 75 % of the member bodies casting a vote.
Attention is drawn to the possibility that some of the elements of this document may be the subject of patent
rights. ISO shall not be held responsible for identifying any or all such patent rights.
ISO 10434 was prepared by Technical Committee ISO/TC 153, Valves, Subcommittee SC 1, Design,
manufacture, marking and testing in collaboration with Technical Committee ISO/TC 67, Materials, equipment
and offshore structures for petroleum, petrochemical and natural gas industries, Subcommittee SC 6,
Processing equipment and systems.
This second edition cancels and replaces the first edition (ISO 10434:1998), which has been technically
revised.
iv © ISO 2004 – All rights reserved

ISO 10434:2004(E)
Introduction
The purpose of this International Standard is to establish the basic requirements and practices for flanged and
butt-welding end steel gate valves of bolted bonnet construction that parallel those given in American
Petroleum Institute API Standard 600, eleventh edition, 2001 (ISO 10434:1998). It is not the purpose of this
International Standard to replace ISO 6002 or any other International Standard that is not identified with
petroleum refinery, petrochemical or natural gas industry applications.

INTERNATIONAL STANDARD ISO 10434:2004(E)

Bolted bonnet steel gate valves for the petroleum,
petrochemical and allied industries
1 Scope
This International Standard specifies the requirements for a heavy-duty series of bolted bonnet steel gate
valves for petroleum refinery and related applications where corrosion, erosion and other service conditions
would indicate a need for full port openings, heavy wall sections and large stem diameters.
This International Standard sets forth the requirements for the following gate valve features:
 bolted bonnet;
 outside screw and yoke;
 rising stems;
 non-rising handwheels;
 single or double gate;
 wedge or parallel seating;
 metallic seating surfaces;
 flanged or butt-welding ends.
It covers valves of the nominal sizes DN:
 25; 32; 40; 50; 65; 80; 100; 150; 200; 250; 300; 350; 400; 450; 500; 600;
corresponding to nominal pipe sizes NPS:
 1; 11/4; 11/2; 2; 21/2; 3; 4; 6; 8; 10; 12; 14; 16; 18; 20; 24;
and applies for pressure Class designations:
 150; 300; 600; 900; 1500; 2500.
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated
references, only the edition cited applies. For undated references, the latest edition of the referenced
document (including any amendments) applies.
ISO 7-1, Pipe threads where pressure-tight joints are made on the threads — Part 1: Dimensions, tolerances
and designation
ISO 10434:2004(E)
ISO 5208, Industrial valves — Pressure testing of valves
ISO 5209, General purpose industrial valves — Marking
ISO 5210, Industrial valves — Multi-turn valve actuator attachments
ISO 5752, Metal valves for use in flanged pipe systems — Face-to-face and centre-to-face dimensions
ISO 9606-1, Approval testing of welders — Fusion welding — Part 1: Steels
ISO 15607, Specification and qualification of welding procedures for metallic materials — Part 1: General
rules
ISO 15609-1, Specification and qualification of welding procedures for metallic materials — Welding
1)
procedure specification — Part 1: Arc welding
ISO 15610, Specification and qualification of welding procedures for metallic materials — Qualification based
on tested welding consumables
ISO 15614-1, Specification and qualification of welding procedures for metallic materials — Welding
procedure test — Part 1: Arc and gas welding of steels and arc welding of nickel and nickel alloys
ISO 15614-2, Specification and qualification of welding procedures for metallic materials — Welding
2)
procedure test — Part 2: Arc welding of aluminium and its alloys
ASME B1.1, Unified inch screw threads (UN and UNR thread form)
ASME B1.5, Acme screw threads
ASME B1.8, Stub acme screw threads
ASME B1.12, Class 5 interference-fit thread
ASME B1.20.1, Pipe threads, general purpose (inch)
ASME B16.5, Pipe flanges and flanged fittings
ASME B16.10, Face-to face and end-to-end dimensions of valves
ASME B16.11, Forged fittings, socket-welding and threaded
ASME B16.34:1996, Valves — Flanged, threaded and welding end
ASME B18.2.2, Square and hex nuts — Inch series
ASME BPVC-IX, BPVC Section IX — Welding and brazing qualifications
ASTM A193, Standard specification for alloy-steel and stainless steel bolting materials for high temperature
service
ASTM A194, Standard specification for carbon and alloy steel nuts for bolts for high pressure or high
temperature service, or both
1) To be published. (Replaces ISO 9956-2:1995)
2) To be published. (Replaces ISO 9956-4:1995)
2 © ISO 2004 – All rights reserved

ISO 10434:2004(E)
ASTM A307, Standard specification for carbon steel bolts and studs, 60 000 PSI tensile strength
MSS-SP-55, Quality standard for steel castings for valves, flanges and fittings and other piping
components — Visual method for evaluation of surface irregularities
3 Terms and definitions
For the purposes of this document, the definitions for pressure designation, Class, and nominal valve size
NPS given in ASME B16.34, and the following apply.
3.1
DN
alphanumeric designation of size for components of a pipework system, which is used for reference purposes,
comprising the letters DN followed by a dimensionless whole number which is indirectly related to the physical
size, in millimetres, of the bore or outside diameter of the end connections
[ISO 6708:1995, definition 2.1]
4 Pressure/temperature ratings
4.1 The pressure/temperature ratings applicable to valves specified in this International Standard shall be in
accordance with those specified in the tables of ASME B16.34 for Standard Class for the applicable material
specification and the applicable Class. Restrictions of temperature and pressure, for example, those imposed
by special soft seals or special trim materials, shall be marked on the valve identification plate, see 8.4.
4.2 The temperature for a corresponding pressure rating is the maximum temperature of the
pressure-containing shell of the valve. In general, this temperature is the same as that of the contained fluid.
The use of a pressure rating corresponding to a temperature other than that of the contained fluid is the
responsibility of the user.
4.3 For temperatures below the lowest temperature listed in the pressure/temperature tables (see 4.1), the
service pressure shall be no greater than the pressure for the lowest listed temperature. The use of valves at
lower temperatures is the responsibility of the user. Consideration should be given to the loss of ductility and
impact strength of many materials at low temperature.
4.4 Double seated valves, in some design configurations, may be capable of trapping liquid in the centre
cavity of the valve when in the closed position. If subjected to an increase in temperature, an excessive build-
up of pressure may occur leading to a pressure boundary failure. Where such condition is possible it is the
responsibility of the user to provide, or require to be provided, means in design, installation or operating
procedure to assure that the pressure in the valve does not exceed that allowed by this International Standard
for the resultant temperature.
5 Design
5.1 Body wall thickness
5.1.1 A valve body schematic is shown as Figure 1. The minimum body wall thickness, t at the time of
,
m
manufacture shall be as given in Table 1, except as indicated in 5.1.2 for butt-welding valve ends. Additional
metal thickness needed for assembly stresses, stress concentrations, and shapes other than circular shall be
determined by individual manufacturers, s
...
