EN 3708-003:2006

Overview

EN 3708-003:2006 is a European standard developed by CEN that defines the requirements for removable feedback sealed modules used in aerospace modular interconnection systems. This standard applies specifically to terminal junction systems designed for extreme operational environments, including temperatures from -55 °C to 175 °C and altitudes up to 21,000 meters. These feedback modules form a critical component within aerospace electrical systems, providing reliable, sealed interconnections essential for safe and efficient aircraft operation.

Key Topics

• Operating Conditions
  The standard specifies modules that perform reliably under harsh conditions typical in aerospace applications, such as low temperatures, high heat, and high-altitude pressures.

• Module Dimensions and Coding
  Modules are categorized into codes A, B, C, or D, corresponding to different sizes and contact configurations. Dimensions and mass are tightly regulated for compatibility and interchangeability within modular systems.

• Interconnection Diagrams
  Each module type has defined interconnection patterns allowing for various groupings of contacts. Visual aids and coding ensure clarity in installation and maintenance.

• Sealing and Removability
  Modules are sealed to protect against environmental factors such as moisture and dust, while also offering a removable design to facilitate maintenance and replacement.

• Marking and Identification
  Each module must bear specific markings, including manufacturer references, production date, and product codes to ensure traceability and compliance.

• Testing and Quality Assurance
  Mandatory tests such as flammability assessments (EN 2591-317) and periodic visual inspections (EN 2591-101) are prescribed to uphold safety and performance standards.

Applications

EN 3708-003:2006 modules are utilized extensively in aerospace electrical systems where modular interconnection flexibility is vital. Practical applications include:

• Aircraft Electrical Wiring
  Providing secure junctions for complex electrical circuits that must withstand fluctuating environmental conditions.

• Avionics Systems
  Ensuring reliable feedback pathways critical for flight control, navigation, and communication systems.

• Maintenance and Upgrades
  Their removable and standardized design allows for efficient servicing, replacement, or upgrading of electrical modules without compromising system integrity.

This standard supports aerospace manufacturers and maintenance organizations in achieving consistent quality and interoperability, thereby enhancing aircraft safety and operational efficiency.

Related Standards

To fully comply with aerospace modular interconnection requirements, EN 3708-003:2006 works in conjunction with several related standards:

• EN 3708-001: Technical specification for modular interconnection terminal junction systems - foundational definitions, terms, and technical requirements.

• EN 2591-101: Visual examination methods for aerospace electrical and optical connections - essential for routine inspections.

• EN 2591-317: Flammability test methods for aerospace electrical and optical connections - ensuring fire safety compliance.

These standards collectively ensure that aerospace interconnection systems meet stringent European safety and performance criteria for critical aircraft electrical components.
