STANDARDSIST EN 12166:1999/AC:2004SIST EN 12166:19991DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 12166
June 2011 ICS 77.150.30 Supersedes EN 12166:1998English Version
Copper and copper alloys - Wire for general purposes
Cuivre et alliages de cuivre - Fils pour usages généraux
Kupfer und Kupferlegierungen - Drähte zur allgemeinen Verwendung This European Standard was approved by CEN on 14 April 2011.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2011 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 12166:2011: ESIST EN 12166:2011

Position of wire cross-section within a coil, reel, spool or drum . 30Bibliography . 32 SIST EN 12166:2011

Tables Table 1 — Composition of low alloyed copper alloys . 15 Table 2 — Composition of copper-nickel-zinc alloys . 16 Table 3 — Composition of copper-tin alloys . 16 Table 4 — Composition of copper-zinc alloys. 17 Table 5 — Composition of copper-zinc-lead alloys . 18 Table 6 — Composition of complex copper-zinc alloys . 18 Table 7 — Mechanical properties of wire of low alloyed copper alloys . 19 Table 8 — Mechanical properties of wire of copper-nickel-zinc alloys . 21 Table 9 — Mechanical properties of wire of copper-tin alloys . 22 Table 10 — Mechanical properties of wire of copper-zinc alloys . 23 Table 11 — Mechanical properties of wire of copper-zinc-lead alloys . 25 Table 12 — Mechanical properties of wire of complex copper-zinc alloys . 26 Table 13 — Grain size designations . 26 Table 14 — Tolerances on diameter of round wire . 27 Table 15 — Tolerances on width across-flats of square or regular polygonal wire . 27 Table 16 — Tolerances on width and thickness of rectangular wire . 28 Table 17 — Corner radii for square or rectangular wire . 28 Table 18 — Sampling rate . 29
D-89079 Ulm
Attention is drawn to the possibility that some of the elements of this document may be the subject of patent rights other than those identified above. CEN shall not be held responsible for identifying any or all such patent rights. SIST EN 12166:2011

The sampling procedures and the methods of test for verification of conformity to the requirements of this European Standard are also specified. 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 1173, Copper and copper alloys — Material condition designation EN 1412, Copper and copper alloys — European numbering system EN 1655, Copper and copper alloys — Declarations of conformity EN 10204:2004, Metallic products — Types of inspection documents EN ISO 2624, Copper and copper alloys — Estimation of average grain size (ISO 2624:1990) EN ISO 6507-1, Metallic materials — Vickers hardness test — Part 1: Test method (ISO 6507-1:2005) EN ISO 6892-1, Metallic materials — Tensile testing — Part 1: Method of test at room temperature
(ISO 6892-1:2009) ISO 1190-1, Copper and copper alloys — Code of designation — Part 1: Designation of materials 3 Terms and definitions For the purposes of this document, the following terms and definitions apply. 3.1 wire wound product of uniform cross-section along its whole length NOTE Rectangles may have round or sharp corners. 3.2 deviation from circular form
difference between the maximum and the minimum diameters measured at any one cross-section of a round product [EN 12163:2011] SIST EN 12166:2011

Material condition for a product which is stress relieved. G. Material condition designated by the mid-range value of grain size requirement for the product with mandatory grain size requirements (Table 13). NOTE The G. material condition is normally applicable only to round wires in the soft material condition made from alloys given in Tables 3, 4 and non-leaded alloys given in Table 2. Exact conversion between material conditions designated R., H. and G. is not possible. Except when the suffix S is used, material condition is designated by only one of the above designations. 4.3 Product The product designation provides a standardized pattern of designation from which a rapid and unequivocal description of a product is conveyed in communication. It provides mutual comprehension at the international level with regard to products which meet the requirements of the relevant European Standard. The product designation is no substitute for the full content of the standard. The product designation for products to this standard shall consist of:  denomination (Wire);  number of this European Standard (EN 12166); SIST EN 12166:2011

Wire EN 12166 — CuZn39Pb3 — H115 — RCT6,0 ×××× 5,0 — SH
or
Wire EN 12166 —
CW614N — H115 — RCT6,0 ×××× 5,0 — SH Denomination Number of this European Standard Material designation Material condition designation Cross-sectional shape and nominal dimensions in millimetres Corner designation EXAMPLE 2 Wire conforming to this standard, in material designated either CuZn39Pb3 or CW614N, in material condition R430, round, nominal diameter 6,0 mm, tolerance class B, shall be designated as follows:
Wire EN 12166 — CuZn39Pb3 — R430 — RND6,0B
or
Wire EN 12166 —
CW614N — R430 — RND6,0B 5 Ordering information In order to facilitate the enquiry, order and confirmation of order procedures between the purchaser and the supplier, the purchaser shall state on his enquiry and order the following information: a) quantity of product required (mass); b) denomination (Wire); c) number of this European Standard (EN 12166); SIST EN 12166:2011

1 000 kg Wire EN 12166 — CuZn39Pb3 — H115 — RCT 6,0 ×××× 5,0 — SH
— 25 kg coils
or
1 000 kg Wire EN 12166 — CW614N — H115 — RCT 6,0 ×××× 5,0 — SH
— 25 kg coils EXAMPLE 2 Ordering details for 5 000 kg wire for general purposes conforming to EN 12166, in material designated either CuZn39Pb3 or CW614N, in material condition R420, round, nominal diameter 6,0 mm, tolerance class B, on 1 000 kg spools:
5 000 kg Wire EN 12166 — CuZn39Pb3 — R430 — RND6,0B
— 1 000 kg spools
or
5 000 kg Wire EN 12166 — CW614N — R430 — RND6,0B
— 1 000 kg spools SIST EN 12166:2011
