Aerospace series - Connector, electrical, rectangular, modular - Operating temperature 175 °C continuous - Part 027: Rack and panel rear mounted plug for 2 and 4 modules, series 3 - Product standard

This document specifies the rack and panel rear mounted plug 2 and 4 modules, series 3 used in the family of rectangular electrical connectors. The receptacles corresponding to those plugs are specified in EN 4165-002.

Luft- und Raumfahrt - Elektrischer Rechtecksteckverbinder in modularer Bauweise - Betriebstemperatur 175 °C konstant - Teil 027: Freier rückseitiger Einschub- und Gehäusesteckverbinder mit 2 und 4 Modulen, Serie 3 - Produktnorm

Série aérospatiale - Connecteurs électriques rectangulaires, modulaires - Température d'utilisation 175 °C continu - Partie 027 : Fiches de rack à fixations inversées 2 et 4 modules, série 3 - Norme de produit

Le présent document spécifie les fiches de rack à fixations inversées série 3, pour 2 et 4 modules, utilisées dans la famille des connecteurs électriques rectangulaires. Les embases correspondant à ces fiches sont spécifiées dans l’EN 4165-002.

Aeronavtika - Konektorji, električni, pravokotni, modularni - Stalna delovna temperatura 175 °C - 027. del: Zadnji vtič za stojalo in ploščo za 2 in 4 module, serije 3 - Standard za proizvod

General Information

Status
Not Published
Publication Date
01-Sep-2024
ICS
49.060 - Aerospace electric equipment and systems
Technical Committee
ASD-STAN - Aerospace
Drafting Committee
ASD-STAN/D 2/S 3 - Elements of Connection (Connectors, Contacts, rear accessories, crimping tools
Current Stage
4060 - Closure of enquiry - Enquiry
Start Date
25-May-2023
Completion Date
25-May-2023
Ref Project
oSIST prEN 4165-027:2023 - Aerospace series - Connector, electrical, rectangular, modular - Operating temperature 175 °C continuous - Part 027: Rack and panel rear mounted plug for 2 and 4 modules, series 3 - Product standard

Relations

Revises
EN 4165-027:2015 - Aerospace series - Connectors, electrical, rectangular, modular - Operating temperature 175 °C continuous - Part 027: Rack and panel rear mounted plug for 2 and 4 modules, series 3 - Product standard
Effective Date
19-Jan-2023

Overview

prEN 4165-027 defines the product standard for rack and panel rear mounted plugs for 2- and 4-module configurations in the Series 3 family of rectangular electrical connectors. Developed under ASD-STAN and submitted to CEN, this draft standard aligns with the Aerospace series requirement for an operating temperature of 175 °C continuous and references the corresponding receptacle specification in EN 4165-002.

The document sets out required characteristics, design classes, marking requirements and references the technical specification given in EN 4165-001.

Key Topics

  • Scope: Product standard for Series 3 rack and panel rear mounted plugs for 2 and 4 modules; receptacles covered by EN 4165-002.
  • Operating temperature: Rated for continuous operation at 175 °C.
  • Design figures: Plugs shall conform to the dimensions and layouts shown in the referenced figures for 2-module and 4-module configurations (Figure 1 and Figure 2).
  • Coupling torque: Screw coupling torque on panel is specified as 0.6 N·m ± 0.1 N·m.
  • Plug classes (Table 1):
    • Class W - Housing (shell) olive drab cadmium plated, aluminium alloy; 500 hours resistance to salt mist; max 175 °C continuous.
    • Class F - Housing (shell) black nickel plated, aluminium alloy; 96 hours resistance to salt mist; max 175 °C continuous.
  • Marking: Marking shall include the identity block per Clause 6, date of manufacture (year–week) and the manufacturer’s name or trademark.
  • Normative references: EN 4165-001 (technical specification) is normative for this part.

Applications

This part of EN 4165 targets designers, manufacturers and procurement specialists working on aerospace electrical systems that require modular rectangular connectors with high-temperature capability and proven corrosion resistance. Practical applications include:

  • Avionics racks and panel interfaces where compact, modular connector design is required.
  • Aerospace equipment subject to elevated operating temperatures (up to 175 °C continuous).
  • Systems requiring defined corrosion resistance and standardized marking for traceability.

Benefits for users include predictable mechanical interfaces, defined environmental durability classes (W/F), and alignment with the EN 4165 connector family for interchangeability and system integration.

Related Standards

Relevant documents referenced in prEN 4165-027 include:

  • EN 4165-001 - Technical specification for the EN 4165 connector family.
  • EN 4165-002 - Specification of performance and contact arrangements (receptacles corresponding to these plugs).
  • EN 4165-003, EN 4165-013, EN 4165-014, EN 4165-021 - Related product standards and accessory definitions within the EN 4165 series.
  • EN 2424 - Marking of aerospace products.

For implementers, reference the figures and tables in the standard for exact dimensional, material and marking requirements and consult EN 4165-001 for the full technical specification.

Get Certified

Connect with accredited certification bodies for this standard

Sponsored listings

Frequently Asked Questions

prEN 4165-027 is a draft published by the European Committee for Standardization (CEN). Its full title is "Aerospace series - Connector, electrical, rectangular, modular - Operating temperature 175 °C continuous - Part 027: Rack and panel rear mounted plug for 2 and 4 modules, series 3 - Product standard". This standard covers: This document specifies the rack and panel rear mounted plug 2 and 4 modules, series 3 used in the family of rectangular electrical connectors. The receptacles corresponding to those plugs are specified in EN 4165-002.

This document specifies the rack and panel rear mounted plug 2 and 4 modules, series 3 used in the family of rectangular electrical connectors. The receptacles corresponding to those plugs are specified in EN 4165-002.

prEN 4165-027 is classified under the following ICS (International Classification for Standards) categories: 49.060 - Aerospace electric equipment and systems. The ICS classification helps identify the subject area and facilitates finding related standards.

prEN 4165-027 has the following relationships with other standards: It is inter standard links to EN 4165-027:2015. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.

prEN 4165-027 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
