Textile floor coverings - Classification of needled pile floor coverings

This European Standard describes and specifies needled pile floor coverings in sheet form including use classification according to wear and appearance retention. These floor coverings are intended to be bonded to the substrate.
This European Standard is also applicable to tiles, the additional requirements for which are given in Annex A.

Textile Bodenbeläge - Einstufung von Polvlies-Bodenbelägen

Diese Europäische Norm beschreibt und spezifiziert Polvlies-Bodenbeläge in Rollenform, einschließlich der Gebrauchseinstufung hinsichtlich Verschleiß und Aussehenserhalt.
Diese Europäische Norm gilt auch für Fliesen; die zusätzlichen Anforderungen für Fliesen sind im Anhang A enthalten.

Revêtements de sol textiles - Classement des revétements de sol aiguilletés à velours

Tekstilne talne obloge - Razvrščanje iglanih lasastih talnih oblog

General Information

Status
Withdrawn
Publication Date
02-Oct-2007
Withdrawal Date
06-May-2014
Current Stage
9960 - Withdrawal effective - Withdrawal
Start Date
07-May-2014
Completion Date
07-May-2014

Relations

Buy Standard

Standard
EN 13297:2007
English language
26 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (Sample)


2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Textile floor coverings - Classification of needled pile floor coveringsJRevetements de sol textiles - Classement des revétements de sol aiguilletés a veloursTextile Bodenbeläge - Einstufung von Polvlies-BodenbelägenTa slovenski standard je istoveten z:EN 13297:2007SIST EN 13297:2007en,fr,de59.080.60Tekstilne talne oblogeTextile floor coveringsICS:SIST EN 13297:20011DGRPHãþDSLOVENSKI
STANDARDSIST EN 13297:200701-december-2007

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 13297October 2007ICS 59.080.60Supersedes EN 13297:2000
English VersionTextile floor coverings - Classification of needled pile floorcoveringsRevêtements de sol textiles - Classement des revétementsde sol aiguilletés à veloursTextile Bodenbeläge - Einstufung von Polvlies-BodenbelägenThis European Standard was approved by CEN on 1 March 2007.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2007 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 13297:2007: E

Additional requirements for tiles.17 Annex B (normative)
Suitability for under-floor heating.18 Annex C (normative)
Colour change due to soiling subsequent to spilled water.19 Annex D (normative)
Summary test report.20 Annex E (normative)
Criteria for the assessment of stair suitability.25 Bibliography.26

This European Standard is also applicable to tiles, the additional requirements for which are given in Annex A. 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 984, Textile floor coverings — Determination of the mass per unit area of the use surface of needled floor coverings EN 985:2001, Textile floor coverings — Castor chair test EN 986:2005, Textile floor coverings — Tiles — Determination of dimensional changes due to the effects of varied water and heat conditions and distortion out of plane EN 994, Textile floor coverings — Determination of the side length, squareness and straightness of tiles EN 995, Textile floor coverings — Assessment of the creep of the backings EN 1269, Textile floor coverings — Assessment of impregnations in needled floorcoverings by means of a soiling test EN 1318, Textile floor coverings — Determination of the apparent effective thickness of the backing EN 1471, Textile floor coverings — Assessment of changes in appearance EN 1814, Textile floor coverings — Determination of resistance to damage at cut edges using the
modified Vettermann drum test EN 1963, Textile floor coverings — Tests using the Lisson Tretrad Machine EN 14041, Resilient, textile and laminate floor coverings — Essential characteristics CEN/TS 14159, Textile floor coverings — Requirements for tolerances on (linear) dimensions of rugs, runners, carpet tiles and wall-to-wall carpet and for tolerances on pattern repeat EN 15115, Textile floor coverings — Determination of sensitivity to spilled water
EN ISO 105-A01, Textiles — Tests for colour fastness — Part A01: General principles of testing —
(ISO 105-A01:1994) EN ISO 105-B02, Textiles — Tests for colour fastness — Part B02: Colour fastness to artificial light: Xenon arc fading lamp test (ISO 105-B02:1994, including amendment 1:1998) EN ISO 105-E01, Textiles — Tests for colour fastness — Part E01: Colour fastness to water
(ISO 105-E01:1994)
(ISO 105-X12:2001) EN ISO 140-8, Acoustics — Measurement of sound insulation in buildings and of buildings elements — Part 8: Laboratory measurements of the reduction of transmitted impact noise by floor coverings on a heavyweight standard floor (ISO 140-8:1997) EN ISO 354, Acoustics - Measurement of sound absorption in a reverberation room (ISO 354:2003) EN ISO 717-2, Acoustics — Rating of sound insulation in buildings and of building elements — Part 2: Impact sound insulation (ISO 717-2:1996) EN ISO 845, Cellular plastics and rubbers — Determination of apparent (bulk) density (ISO 845:1988) EN ISO 11378-2, Textile floor coverings — Laboratory soiling tests — Part 2: Drum test
(ISO 11378-2:2001) ISO 1765, Machine-made textile floor coverings — Determination of thickness ISO 1766, Textile floor coverings — Determination of thickness of pile above the substrate ISO 2424:1992, Textile floor coverings — Vocabulary ISO 2551, Machine-made textile floor coverings — Determination of dimensional changes due to the effects of varied water and heat conditions ISO 6356, Textile floor coverings — Assessment of static electrical propensity — Walking test ISO 8302, Thermal insulation — Determination of steady-state thermal resistance and related properties — Guarded hot plate apparatus ISO 8543, Textile floor coverings — Methods for determination of mass ISO 10361, Textile floor coverings — Production of changes in appearance by means of Vettermann drum and hexapod tumbler testers ISO 10965, Textile floor coverings — Determination of electrical resistance 3 Terms and definitions For the purposes of this document, the terms and definitions given in ISO 2424:1992 and the following apply. 3.1 non adhered tile (loose laid) tile installed without any use of a bonding system (see Annex A) 3.2 adhered removable tile tile installed with a bonding system allowing easy removal and reinstallation (see Annex A) 3.3 permanent adhered tile tile installed with a permanent bonding system (see Annex A)

The chemical bonding system is on the back. 4.2 Levels of use Needled pile floor coverings are classified as suitable for different levels of use in accordance with the performance requirements specified in Clause 7. The different levels of use are described in Table 1.

Moderate / light 22
General / medium
22+
General
HeavyCommercial a
Moderate
General
Heavy a Class 33 should be used as the basis to which additional requirements are added to provide an individual full specification. If symbols are to be used for the use classes, luxury rating classes and additional characteristics, the symbols listed in CEN/TS 15398 shall be used which can also be found on www.floorsymbols.com. For very specific use such as airports, theatres or industrial use, the technical requirements should be discussed and agreed between all parties involved. 5 Identification requirements This clause specifies the characteristics for identification of the product and requirements for tolerances for the identifying properties. The manufacturer shall provide the following information in accordance with the definitions in ISO 2424:  commercial references,  type of bonding,  type of backing and shall declare the values of the characteristics in Table 2.

Test methods Tolerances Fibre composition of use surface
a  Dimensions
CEN/TS 14159 CEN/TS 14159 Total thickness mm ISO 1765  Thickness of pile above the substrate (for type 2 and type 3 product) mm ISO 1766 Nominal + 15 %
- 10 % Total mass per unit area g/m2 ISO 8543 Nominal + 15 %
- 7,5 % Mass per unit area of the use-surface (for type 2 and type 3 product) g/m2 EN 984 Nominal + 15 %
− 10 % Foam backing – if applicable • Apparent thickness mm EN 1318 Nominal ± 0,5 mm • Apparent density g/cm³EN ISO 845
a Attention is drawn to the European Directives 96/73 and 96/74 which cover the fibre composition and are reflected in the national regulations 6 Basic requirements Needled pile floor coverings shall conform to the basic requirements specified in Table 3.

Table 3 — Basic requirements Characteristics Requirements Test methods Dimensional stability a shrinkage
≤ 1,2 % in either direction
extension
≤ 0,5 % in ei
...
