EN 4165-001:2007

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Luft- und Raumfahrt - Elektrische Rechtecksteckverbinder in modularer Bauweise - Betriebstemperatur 175 °C konstant - Teil 001: Technische lieferbedingungenSérie aérospatiale - Connecteurs électriques modulaires - Températures d'utilisation 175°C continu - Partie 001 : Spécification techniqueAerospace series - Connectors, electrical, rectangular, modular - Operating temperature 175 °C continuous - Part 001: Technical specification49.060Aerospace electric equipment and systemsICS:Ta slovenski standard je istoveten z:EN 4165-001:2007SIST EN 4165-001:2009en01-februar-2009SIST EN 4165-001:2009SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 4165-001
April 2007 ICS 49.060 English Version
Aerospace series - Connectors, electrical, rectangular, modular -Operating temperature 175 °C continuous - Part 001: Technical specification
Série aérospatiale - Connecteurs électriques modulaires - Températures d'utilisation 175 °C continu - Partie 001 : Spécification technique
Luft- und Raumfahrt - Elektrischer Rechtecksteckverbinder in modularer Bauweise - Betriebstemperatur 175 °C konstant - Teil 001: Technische lieferbedingungen This European Standard was approved by CEN on 30 September 2005.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre: rue de Stassart, 36
B-1050 Brussels © 2007 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 4165-001:2007: ESIST EN 4165-001:2009

* All its parts quoted in this standard. 1) Published as ASD Prestandard at the date of publication of this standard. 2) Published by: Department of Defense (DOD), the Pentagon, Washington, DC 20301, USA. SIST EN 4165-001:2009

The plug contains a coupling screw and the receptacle a coupling nut. This family of connectors provides two housing sizes (2 or 4 modules), two series (series 2 and scoop proof series 3) and two mating-unmating systems (screw or rack and panel). The connectors are polarized by centre keying mechanism; polarization shall be obtained before the male contacts enter the module of the female contacts and before the coupling system is engaged. Keying mechanism shall provide 36 position keying capabilities. These connectors use different types of contacts (signal, power, coaxial, …) defined in EN 3155-002. 4.2 Receptacle The receptacle may be attached by:  rectangular flange with two mounting holes;  two end flanges with transversal holes (panel mounting) and lateral holes (stackable mounting). The receptacle contains a centre coupling nut which also ensures the polarization function (coding pin) by external keys. The main key is fixed and is wider than the other. Polarization is ensured by the different positions which the secondary key may take and the different positions in which the coding pin may be fixed in the housing. The module cavities are identified on the housing of the receptacle by letter A, B, C, D for size 4 (four modules) and letter A, B for size 2 (two modules). The cavities are polarized by two keyways location.
3) Published by: Society of Automotive Engineers, Inc. (SAE), 400 Commonwealth Drive, Warrendale, PA 15096-0001, USA. SIST EN 4165-001:2009

The female modules use female contacts and male modules use male contacts. These modules use crimp or solder contacts of sizes 22, 20, 16, 12 and 8. They are rear release and held in the housing by two retention tines. They are removed from the rear with a specific tool. The modules have two keys which engage in the keyways of the housing. Polarization is ensured by the different positions which the secondary keys may take. The modules are identified by letter A, B, C, D or N (universal). A blank module is installed in a cavity where no contacts are required. This module is a male module with a universal polarization (N) installable in all coding cavities (A, B, C, D) and in all housing types (plug or receptacle). Modules shall be interchangeable in cavities of housing with different configurations. 4.7 Keying mechanism 4.7.1 Coding pin (receptacle) Keying mechanism shall provide 36 position keying capabilities. These 36 positions are given with 6 different coding pins, identified by colour code. The main key is wider than the other, polarization is ensured by the SIST EN 4165-001:2009

4.8 Materials and surface treatment 4.8.1 General When dissimilar metals are in close contact, adequate protection against corrosion shall be used for the electromotive force of the cell not to exceed 0,25 V. 4.8.2 Housings The material of the housing for the connectors shall be aluminium alloy or composite, protected against corrosion by nickel or cadmium plating (see EN 4165-002). Non conductive black anodized protection over aluminium material is also available. 4.8.3 Contacts Removable contacts (see EN 3155-002). 4.8.4 Non-metallic materials The materials used for module, seals and grommets shall have mechanical characteristics consistent with the required use. 5 Design 5.1 Housings The connector housings shall be a one piece construction. They shall accommodate the rear accessories and other fittings defined in this specification (see EN 4165-002). The rectangular flange receptacle can furthermore be fitted with a conductive gasket ensuring electrical continuity between the connector housing and panel. The threads shall conform to ISO 263. The coupling mechanism shall be designed so that the male and female contacts engage when it is rotated and disengaged when it is rotated counter-clockwise. The centre coupling screw shall be a hexagonal socket head screw and compatible with the coupling torque values defined in the product standard. The accessories shall be fixed by screw or clip on the rear of connectors. SIST EN 4165-001:2009

Key 1 Receptacle assembly 2 Plug assembly 3 Rack plug assembly 4 Mechanical bottoming plate Figure 1 Table 1 — Engagement contacts
A B C D Series 2 38,5 37,8 33,4 32,9 40,0 36,0 34,9 30,9 Series 3 47,1 46,4 42,0 41,5 40,0 36,0 34,9 30,9
A B C D Sizes 22 – 20 – 16 – 12 6,66 6,20 6,38 5,93 3,00 2,54 3,27 2,82 Size 8 6,79 6,33 6,51 5,93 2,87 2,41 3,27 2,69
6.2.3 Plug and receptacle, series 3 Insert and contact position Dimensions are in millimetres, see Figure 3. Key 1 Mechanical bottom of receptacle 5 Mechanical bottom of plug 2 Female insert assembly (all sizes) 6 See EN 4165-020. 3 See EN 4165-019. 7 See Figure 6. 4 Male insert assembly (all sizes) 8 See Figures 4 and 5. a For sizes 22 – 20 – 16 – 12 inserts b For size 8 insert Figure 3 SIST EN 4165-001:2009

Table 4
A B C D
E Sizes 22 – 20 – 16 – 12 6,66 6,20 14,94 14,49 11,56 11,10 3,27 2,82
Coupling with clicker-nut plug 12,62 12,38 Size 8 6,79 6,33 15,07 14,49 11,43 10,97 3,27 2,69
Coupling with rack plug 21,18 20,94
Key 1 Active thread 12,6 min. Figure 4 Figure 5 SIST EN 4165-001:2009

Key 1 Centre line 2 Groove only for classes F, W and A 3 Module cavities coding see Figure 19. 4 Coding pin cavity see Figure 11. 5 Mechanical bottom of receptacle Figure 8 SIST EN 4165-001:2009

Key 1 Centre line 2 Groove only for classes F, W and A 3 Module cavities coding see Figure 19. 4 Coding pin cavity see Figure 11. 5 Mechanical bottom of receptacle Figure 9 SIST EN 4165-001:2009

Key 1 Centre line 2 Groove only for classes F, W and A 3 Module cavities coding see Figure 19. 4 Coding pin cavity see Figure 11. 5 Mechanical bottom of receptacle Figure 10 SIST EN 4165-001:2009

Key 1 Centre line 2 Bottoming plate for coding pin 3 Mechanical bottom of receptacle Figure 11 SIST EN 4165-001:2009

Key 1 Mechanical bottom of plug 2 Coding key cavity see Figure 17. 3 Module cavities coding see Figure 19. 4 Point of engagement emi feature 5 Centre line Figure 14 SIST EN 4165-001:2009

Key 1 Centre line 2 Mechanical bottom of plug Figure 17 SIST EN 4165-001:2009
...
