ASTM D7909-21a
(Guide)Standard Guide for Placement of Intentional Leaks During Electrical Leak Location Surveys of Geomembranes
Standard Guide for Placement of Intentional Leaks During Electrical Leak Location Surveys of Geomembranes
SIGNIFICANCE AND USE
4.1 Geomembranes are used as low-permeability barriers to control liquids from leaking from landfills, ponds, and other containments. The liquids may contain contaminants that, if released, can cause damage to the environment. Leaking liquids can also erode the subgrade. Leakage can result in product loss or otherwise prevent the installation from performing its intended containment purpose. For these reasons, it is desirable that the geomembrane have as little leakage as practical.
4.2 Geomembrane leaks can result even when the quality of the subgrade preparation, the quality of the material placed on the geomembrane, and the quality of the workmanship are not deficient.
4.3 Electrical leak location methods are an effective final quality assurance (QA) measure to locate previously undetected leaks in electrically insulating geomembranes. Practices for these implementations are contained in Guide D6747 and Practices D7002, D7007, D7240, D7703, D7953, and D8265.
4.4 It is important to realize that the detection of leaks depends not only on the capabilities of the leak location equipment, procedures, and experience of the leak location practitioner, but also on local site conditions that are not under the control of the leak location practitioner. In particular, to detect a leak, there shall be an electrical conduction path through the leak and through the materials above and below the leak to allow sufficient electrical current through the leak for detection. Some site conditions, such as a leak not making contact with the subgrade, dry geotextile, or geocomposite above or below the leak; dry materials above or below the leak; degree of isolation between the materials above and below the geomembrane; and other factors, may preclude the detection of leaks. Therefore, the use of a properly placed leak is also a test of site preparations and conditions.
4.5 It is not necessarily proper to conclude that, if a leak is not detected, a leak location survey using...
