SIST EN 2693:2005

Overview

SIST EN 2693:2005 is a European Standard developed by the European Committee for Standardization (CEN) specifically for aerospace applications. This document specifies the technical requirements for aluminium alloy AL-P5086-H111 sheet and strip with thicknesses ranging from 0.3 mm to 6 mm. The standard aims to ensure high-quality material performance, reliability, and safety in the aerospace industry. SIST EN 2693:2005 replaces the earlier EN 2693:1993 and aligns with aerospace manufacturing standards to provide uniformity across member countries.

Key Topics

• Material Designation: Aluminium alloy AL-P5086-H111, designed for aerospace-grade sheet and strip products.
• Thickness Range: Applicable for sheets and strips with thickness 0.3 mm ≤ a ≤ 6 mm.
• Chemical Composition: Specifies precise element limits including Si, Fe, Cu, Mn, Mg, Cr, Zn, Ti, and Al ensuring optimal mechanical and corrosion-resistant properties.
• Mechanical Properties: Requires minimum proof stress of 100 MPa and tensile strength of at least 240 MPa for various thickness ranges; elongation percentages are also defined.
• Delivery Condition: Material supplied in H111 heat treatment state, to maintain consistent strength and ductility.
• Production Method: Rolled sheet and strip manufactured under strict aerospace standards.
• Test Procedures: Testing samples and pieces follow the specifications of EN 4400-2, including tensile, bending, and corrosion resistance tests.
• Application-Specific Quality Controls: Emphasis on dimensional and marking inspection, external defect checks, and product qualification aligned with aerospace requirements.

Applications

SIST EN 2693:2005 standard aluminum alloy sheets and strips are specifically designed for use in aerospace manufacturing and assembly, including:

• Aircraft structural components where high strength-to-weight ratio and corrosion resistance are essential.
• Aerospace panels, fuselage linings, and secondary structural elements.
• Components requiring precise dimensional control and mechanical reliability under operational stresses.
• Applications demanding compatibility with aerospace heat treatments and surface treatments to maintain integrity and durability.

The alloy AL-P5086-H111 is ideal for lightweight aerospace engineering, providing excellent formability, weldability, and resistance to environmental degradation.

Related Standards

SIST EN 2693:2005 references and works in connection with several key aerospace material standards to holistically cover the production and application spectrum:

• EN 4258: General organization of aerospace metallic material standardization, offering a framework for linking related EN standards.
• EN 4400-2: Technical specifications for aluminum and aluminum alloy wrought products covering sheet and strip dimensions, testing, and requirements.
• EN 4500-2: Specific rules for drafting and presenting standards related to aluminum, aluminum alloys, and magnesium alloys in aerospace applications.

Compliance with these interconnected standards helps manufacturers meet rigorous aerospace quality assurance criteria, ensuring materials perform reliably in critical environments.
