SIST EN 61543:1998

SLOVENSKI SIST EN 61543:1998
prva izdaja
STANDARD
september 1998
Residual current-operated protective devices (RCDs) for household and similar
use - Electromagnetic compatibility (IEC 61543:1995)
ICS 5HIHUHQþQDãWHYLOND
29.020; 29.120.50
SIST EN 61543:1998(en)
! "#$%!&!%’()*#+’

---------------------- Page: 1 ----------------------

NORME CEI
INTERNATIONALE IEC
1543
INTERNATIONAL
Première édition
STANDARD
First edition
1995-04
Dispositifs différentiels résiduels (DDR)
pour usages domestique et analogues –
Compatibilité électromagnétique
Residual current-operated protective devices
(RCDs) for household and similar use –
Electromagnetic compatibility
© CEI 1995 Droits de reproduction réservés — Copyright — all rights reserved
Aucune partie de cette publication ne peut être reproduite ni No part of this publication may be reproduced or utilized in
utilisée sous quelque forme que ce soit et par aucun pro- any form or by any means, electronic or mechanical,
cédé, électronique ou mécanique, y compris la photocopie et including photocopying and microfilm, without permission
les microfilms, sans l'accord écrit de l'éditeur. in writing from the publisher.
Bureau Central de la Commission Electrotechnique Internationale 3, rue de Varembé Genève, Suisse
Commission Electrotechnique Internationale
CODE PRIX
International Electrotechnical Commission
PRICE CODE
IEC Megutyliapontiaa 3neKTpoîexHwiectta g KOMHCCHA
Pour prix, voir catalogue en vigueur •
•
For price, see current catalogue

---------------------- Page: 2 ----------------------

1543 ©
IEC:1995 - 3 -
INTERNATIONAL ELECTROTECHNICAL COMMISSION
RESIDUAL CURRENT-OPERATED PROTECTIVE
DEVICES (RCDs) FOR HOUSEHOLD AND SIMILAR USE –
ELECTROMAGNETIC COMPATIBILITY
FOREWORD
1) The IEC (International Electrotechnical Commission) is a worldwide organization for standardization
comprising all national electrotechnical committees (IEC National Committees). The object of the IEC is to
promote international cooperation on all questions concerning standardization in the electrical and
electronic fields. To this end and in addition to other activities, the IEC publishes International Standards.
Their preparation is entrusted to technical committees; any IEC National Committee interested in
the subject dealt with may participate in this preparatory work. International, governmental and
non-governmental organizations liaising with the IEC also participate in this preparation. The IEC
collaborates closely with the International Organization for Standardization (ISO) in accordance with
conditions determined by agreement between the two organizations.
2) The formal decisions or agreements of the IEC on technical matters, prepared by technical committees on
which all the National Committees having a special interest therein are represented, express, as nearly as
possible, an international consensus of opinion on the subjects dealt with.
They have the form of recommendations for international use published in the form of standards, technical
3)
reports or guides and they are accepted by the National Committees in that sense.
4) In order to promote international unification, IEC National Committees undertake to apply IEC International
Standards transparently to the maximum extent possible in their national and regional standards. Any
divergence between the IEC Standard and the corresponding national or regional standard shall be clearly
indicated in the latter.
International Standard IEC 1543 has been prepared by sub-committee 23E: Circuit-
breakers and similar equipment for household use, of IEC technical committee 23:
Electrical accessories.
The text of this standard is based on the following documents:
DIS Report on voting
23E/202/DIS 23E/218/RVD
Full information on the voting for the approval of this standard can be found in the report
on voting indicated in the above table.

---------------------- Page: 3 ----------------------

- 5 -
1543 ©IEC:1995
INTRODUCTION
This International Standard includes definitions, standard electromagnetic conditions,
conditions of operation in service and electromagnetic tests necessary for devices provid-
ing residual current protection.
It applies when required in a product standard and in conjunction with it, at present for:
- IEC 1008-series for RCCBs;
- IEC 1009-series for RCBOs.
It is intended to apply also for the same purpose, in conjunction with future IEC stan-
dards, for portable residual current devices without integral overcurrent protection for
household and similar uses (PRCDs), to residual current devices without integral
overcurrent protection incorporated in or to be associated with fixed socket-outlets
(SRCDs) - now under consideration - and to other RCDs incorporating overcurrent protec-
tion.

---------------------- Page: 4 ----------------------

1543©IEC:1995 - 7 -
RESIDUAL CURRENT-OPERATED PROTECTIVE
DEVICES (RCDs) FOR HOUSEHOLD AND SIMILAR USE –
ELECTROMAGNETIC COMPATIBILITY
1 Scope
This. International Standard is intended to ensure electromagnetic compatibility (EMC) of
devices providing residual current protection, for rated voltages not exceeding 440 V a.c.,
intended principally for protection of persons against shock hazards.
This standard applies for environmental conditions which occur in installations connected
to low-voltage public networks or similar. It may also provide guidance for ensuring EMC
for other products intended for safety purposes or for products including electronic circuits
and for which a high level of continuity of service is required.
For EMC test requirements not included in the product standards reference should be
made to this product family standard.
2 Normative references
The following normative documents contain provisions which, through reference in this
text, constitute provisions of this International Standard. At the time of publication, the
editions indicated were valid. All normative documents are subject to revision, and parties
to agreements based on this International Standard are encouraged to investigate the
possibility of applying the most recent editions of the normative documents indicated
below. Members of IEC and ISO maintain registers of currently valid International
Standards.
IEC 1000-4-2: 1995, Electromagnetic compatibility (EMC) - Part 4: Testing and
measurement techniques - Section 2: Electrostatic discharge immunity test - Basic EMC
publication
IEC 1000-4-4: 1995, Electromagnetic compatibility (EMC) - Pa rt 4: Testing and
measurement techniques - Section 4: Electrical fast transient/burst immunity test - Basic
EMC publication
lEC 1000-2-2: 1990, Electromagnetic compatibility (EMC) - Part 2: Environment - Section 2:
Compatibility levels for low-frequency conducted disturbances and signalling in public low-
voltage power supply systems
IEC 1000-4-1: 1992, Electromagnetic compatibility (EMC) - Pa rt 4: Testing and
measurement techniques - Section 1: Overview of immunity tests - Basic EMC publication

---------------------- Page: 5 ----------------------

o
1543 O IEC:1995 - 9 -
IEC 1008-1: 1990, Residual current operated circuit-breakers without integral overcurrent
protection (RCCBs) - Part 1: General rules
Amendment 1 (1992)
IEC 1009-1: 1991, Residual current operated circuit-breakers with integral overcurrent
protection (RCBOs) for household and similar uses - Part 1: General rules
CISPR 14: 1993, Limits and methods of measurements of radio disturbance characteristic
of electrical motor-operated and thermal appliances for household and similar purposes,
electric tools and electric apparatus
3 Standard electromagnetic environmental conditions
Standard electromagnetic environmental conditions are those conditions which occur in
installations connected to low-voltage public networks or similar.
3.1 Low-frequency electromagnetic phenomena
Table 1 lists the low-frequency electromagnetic phenomena considered under the environmental
conditions taken into account.
Table 1
Phenomena Environmental conditions
Reference
T 1.1 Harmonics, interharmonics With levels of harmonics and interharmonics according
to IEC 1000-2-2
T 1.2 Signalling voltages In presence of signalling voltages (without resonance)
Between 0,85 and 1,1 Un and possible voltage dips of
T 1.3 Voltage amplitude variations
short duratio
...
