FINAL DRAFT INTERNATIONAL STANDARD ISO/FDIS 23116:2020(E)
Ships and marine technology — Ship’s mooring and towing
fittings — Seats for Panama chocks
1 Scope
This document specifies the types, nominal sizes, dimensions and materials, as well as construction,
manufacturing and marking requirements, for the seats for Panama chocks installed to lead the
mooring and towing rope of a ship. It is applicable to ships passing through the Panama Canal, which
are normally assisted by locomotives using steel towing wires and/or by tug boats. These seats for
chocks meet normal mooring requirements and Panama Canal requirements.
NOTE The seat for Panama chocks (SWL of 90 tons) for Panamax Plus and Neopanamax vessels can be
replaced by seats for closed chocks (see ISO 23113).
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
IMO Circular MSC/Circ.1175, Guidance on shipboard towing and mooring equipment
Panama Canal Requirements — OP Notice to shipping No. N-1-2018 — Vessel requirements
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at http:// www .electropedia .org/
3.1
safe working load
SWL
safe load limit (maximum permissible load) of the fittings used for mooring and towing
4 Classification
4.1 Type
The seat for Panama chocks shall be classified by its installation site as belonging to one of the
following types:
a) Type A: seat for deck-mounted Panama chock;
b) Type B: seat for deck and side shell-mounted Panama chock;
c) Type C: brackets for bulwark-mounted Panama chock.
© ISO 2020 – All rights reserved 1

---------------------- Page: 6 ----------------------
ISO/FDIS 23116:2020(E)

4.2 Nominal sizes
The nominal sizes of the seats for the Panama chocks are denoted by reference to the width of the
opening, in millimetres.
The nominal sizes are 310 and 360.
5 Dimensions
The seats for Panama chocks shall have dimensions and particulars in accordance with Tables 1, 2 and
3, and Figures 1, 2 and 3.
6 M
...
