Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular, the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www .iso .org/ directives).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of
any patent rights identified during the development of the document will be in the Introduction and/or
on the ISO list of patent declarations received (see www .iso .org/ patents).
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation of the voluntary nature of standards, the meaning of ISO specific terms and
expressions related to conformity assessment, as well as information about ISO's adherence to the
World Trade Organization (WTO) principles in the Technical Barriers to Trade (TBT) see www .iso .org/
iso/ foreword .html.
This document was prepared by Technical Committee ISO/TC 22, Road vehicles, Subcommittee SC 32,
Electrical and electronic components and general system aspects.
A list of all parts in the ISO 19453 series can be found on the ISO website.
Any feedback or questions on this document should be directed to the user’s national standards body. A
complete listing of these bodies can be found at www .iso .org/ members .html.
Introduction
For over fifty years, traction batteries for electric vehicles have been developed to achieve high energy
density and high power output. Specifically, lead-acid battery, Ni-Cd battery and Ni-MH battery
with aqueous electrolyte were most applied to electric vehicles in the early days. Thermal activated
batteries, such as molten salt batteries like sodium sulphur battery and Zebra battery were also
examined. Lithium ion battery penetrated the consumer market in portable battery application from
1991. Currently, it is the most promising candidate of traction battery for electric vehicles. ISO 6469-1
specifies safety requirement of RESS (Rechargeable Energy Storage System) and the ISO 12405
series has been published to specify performance and reliability tests. This document focuses on
environmental and endurance tests of lithium ion battery systems.
The ISO 19453 series specifies the test conditions on environment and reliability for electrical and
electric equipment for the drive system of electric propulsion vehicles. The battery pack or system is the
electric system which charges and discharges electricity through the converter. The test condition for
mechanical load in ISO 19453-3 is too severe to apply to the battery pack or system from the standpoint
of frequency range and amplitude of vibration in the test input spectrum. The test conditions for
climatic load in ISO 19453-4 is also excessive to apply to the battery pack or system, because lithium ion
battery pack is designed to control temperature within adequate operational range. That is the reason
why appropriate conditions for the lithium ion battery are specified in this document.
The purpose of this document is to assist its user in systematically defining and/or applying a set of
internationally accepted environmental conditions, tests and operating requirements, which are based
on the anticipated actual environment in which the equipment will be operated and exposed to during
its life cycle. This document has been developed based on fundamental investigations and vehicle
measurements on voltage class A and B battery pack/system. The following environmental factors have
been considered in the development of the ISO 19453 series.
— World geography and climate
Electric propulsion vehicles are operated in nearly all terrestrial regions of the earth. Significant
variation in environmental conditions due to climatic environment, including diurnal and seasonal
cycles, can therefore be expected. Consideration has been given to worldwide ranges in the
temperature, humidity, precipitation and atmospheric conditions including dust, pollution and altitude.
— Type of electric propulsion vehicle
Operating environment in an electric propulsion vehicle can depend on its electric powertrain
architecture as well as its mass, size, supply voltage and so on. Consideration has been given to typical
types of series production electric propulsion vehicle architectures such as hybrid electric vehicles,
battery electric vehicles, range extender hybrid electric vehicles and fuel cell vehicles, but not including
equipment specific for fuel cell system.
— Vehicle use conditions and operating modes
Environmental conditions in and on the vehicle vary significantly with vehicle use (e.g. driving,
charging during parking, etc.). Operating modes, such as starting, driving, braking, stopping and so
on, have been considered, in particular, for traction battery system.
— Battery durability
For battery system, it is necessary to be resistant to environmental conditions experienced during
manufacture, shipping, handling, storage, vehicle assembly, vehicle usage and vehicle maintenance
and repair.
— Component mass and volume
The mass of battery pack is generally in the range of around 20 kg up to 60 kg for HEV, 80 kg to 150 kg for
PHEV, more than 200 kg for BEV (weight assumptions from year 2020). The battery pack has generally
vi © ISO 2020 – All rights reserved

a large volume and thermal capacity. It is necessary not only to prepare a large chamber but it will also
take a long time to keep the thermal equivalent when performing a thermal shock test.
— Mounting location in the vehicle
HEV battery packs are generally installed inside the vehicle, PHEV battery packs are installed both
outside and inside, and BEV battery packs are generally installed outside. The environmental condition
such as water splashing, dust, salt spray, humidity or corrosion for battery packs installed outside
vehicle interior is more severe than for battery packs installed inside. In this document, test conditions
are specified according to mounting location.
a) Applicability to manufacturers’ responsibility
Due to technology limitations or variations in vehicle design, the vehicle manufacturer may be required
to place a component in a location where it cannot withstand the environmental conditions described
in the ISO 19453 series. Under these circumstances, it is the responsibility of the vehicle manufacturer
to provide the necessary environmental protection.
b) Applicability to wiring harnesses, cables and electrical connectors
Although some environmental conditions and tests in the ISO 19453 series may be relevant to vehicle
wiring harnesses, cables and connectors, its scope is not sufficient to be used as a complete standard.
It is therefore not recommended that the ISO 19453 series is directly applied to such devices and
equipment.
c) Applicability to parts or assemblies inside equipment
The ISO 19453 series describes environmental conditions and tests to be applied to electrical and
electronic equipment directly mounted in or on the vehicle. It is not intended for direct application to
parts or assemblies that are part of the equipment. For example, the ISO 19453 series should not be
directly applied to integrated circuits (ICs) and discrete components, electrical connectors, printed
circuit boards (PCBs), gauges, etc. that are attached in or on the equipment. Electrical, mechanical,
climatic and chemical loads for such parts and assemblies can be quite different from those described
in the ISO 19453 series. Therefore, for those sub-components applying test conditions of the ISO 16750
series can be considered as a reference.
On the other hand, it is desirable to use the ISO 19453 series to help derive environmental conditions
and test requirements for parts and assemblies that are intended for use in road vehicle equipment.
d) Applicability relative to system integration and validation
The user of the ISO 19453 series is cautioned to understand that its scope is limited to conditions and
testing at the equipment level and therefore does not represent all conditions and testing necessary
for complete verification and validation of the vehicle system, for example cold water shock tests
were omitted from this document. Environmental and reliability testing of equipment parts and
vehicle systems may be required. For example, the ISO 19453 series does not necessarily ensure that
environmental and reliability requirements for solder joints, solderless connections, integrated circuits
and so on are met. Such items are assured at the part, material or assembly level. Additionally, vehicle
and system level testing might be required to validate the equipment in the vehicle application.
INTERNATIONAL STANDARD ISO 19453-6:2020(E)
Road vehicles — Environmental conditions and testing for
electrical and electronic equipment for drive system of
electric propulsion vehicles —
Part 6:
Traction battery packs and systems
1 Scope
This document specifies requirements for lithium-ion traction battery packs or systems used in
battery electric, hybrid electric and fuel cell electric road vehicles. This document describes the most
relevant environmental stresses and specifies tests and test boundary conditions. This document
establishes a classification of battery packs or systems and defines different stress levels for testing
when a classification is applicable and required. The objective of this document is to specify standard
test procedures and conditions to enable the observation of the reliability of the lithium-ion traction
battery in the vehicle.
This document specifies tests for a battery pack or system of voltage class A and B.
This document provides the necessary information to set up a dedicated test plan for a battery pack
or system subject to agreement between the customer and supplier. If required, the relevant test
procedures and/or test conditions can also be selected from this document.
NOTE This document only covers requirements and test conditions for a traction battery pack or system
used in passenger cars.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 6469-3, Electrically propelled road vehicles — Safety specifications — Part 3: Electrical safety
ISO 6469-3:2018/Amd 1, Electrically propelled road vehicles — Safety specifications — Part 3: Electrical
safety — Amendment 1: Withstand voltage test for electric power sources
ISO 9227, Corrosion tests in artificial atmospheres — Salt spray tests
ISO 19453-1, Road vehicles — Environmental conditions and testing for electrical and electronic equipment
for drive system of electric propulsion vehicles — Part 1: General
ISO 19453-4, Road vehicles — Environmental conditions and testing for electrical and electronic equipment
for drive system of electric propulsion vehicles — Part 4: Climatic loads
ISO 19453-5, Road vehicles — Environmental conditions and testing for electrical and electronic equipment
for drive system of electric propulsion vehicles — Part 5: Chemical loads
ISO 20653, Road vehicles — Degrees of protection (IP code) — Protection of electrical equipment against
foreign objects, water and access
IEC 60068-2-14, Environmental testing — Part 2-14: Tests — Test N: Change of temperature
IEC 60068-2-27, Environmental testing — Part 2-27: Tests — Test Ea and guidance: Shock
IEC 60068-2-38, Environmental testing — Part 2-38: Tests — Test Z/AD: Composite temperature/humidity
cyclic test
IEC 60068-2-60, Environmental testing — Part 2-60: Tests — Test Ke: Flowing mixed gas corrosion test
IEC 60068-2-64, Environmental testing — Part 2-64: Tests — Test Fh: Vibration, broad-band random and
guidance
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 19453-1, ISO 20653 and the
following apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at http:// www .electropedia .org/
3.1
BMS
battery management system
electronic system that controls, manages, detects or calculates electric and thermal functions of the
battery pack or system and that provides communication between the battery pack or system and
other vehicle controllers
3.2
electric chassis
conductive parts of a vehicle that are electrically connected and whose potential is taken as reference
3.3
ITCS
internal temperature control system
internal thermal management system of a battery pack or system that can heat or cool the battery pack
or system to a target temperature determined by the BMS (3.1)
EXAMPLE Liquid based heating/cooling system.
3.4
main contactor
electronic or mechanic switching/disconnect device for the battery pack or system main power supply
live part (3.5)
3.5
main power supply live part
conductor or conductive part intended to be energized in normal use, but by convention not the electric
chassis (3.2) or the class A auxiliary voltage supply
3.6
MAST
multiaxial simulation table
multiaxial system to induce vibrations or shocks in all three axial dimensions to the DUT
3.7
PSD
power spectral density
measure of signal's power content versus frequency
Note 1 to entry: A PSD is typically used to characterize broadband random signals. The amplitude of the PSD is
normalized by the spectral resolution employed to digitize the signal.
2 © ISO 2020 – All rights reserved

3.8
rated capacity
total number of ampere-hours that can be withdrawn from a fully charged battery pack or system
under test conditions defined by the battery pack or system manufacturer
3.9
technical tightness
inherent characteristic of a system that prevent fluids, gases or dusts from passing from the external to
the internal environment or from the internal to the external environment, or both
4 Symbols and abbreviated terms
4.1 Symbols
1C One-hour charge or discharge rate for the rated battery pack or system capacity.
C/3 Three-hour charge or discharge rate for the rated battery pack or system capacity.
RT Room temperature value as defined in ISO 19453-1.
SOC Maximum state of charge of a battery pack or system specified by the manufacturer.
max
SOC Minimum state of charge of a battery pack or system specified by the manufacturer.
min
t Duration with an electrical current charging the battery pack or system.
ch
t Duration with an electrical current discharging the battery pack or system.
dch
T Ambient temperature of a climate/temperature chamber
amb
T Temperature of the internal temperature control system, for example liquid coolant, of a
ITCS
battery pack or system.
T Highest ambient temperature of a battery pack or system specified by the manufacturer
max
(e.g. storage).
*
T Maximum temperature by electric operation, can be lower than T
max max
T Highest operating temperature of a battery pack or system specified by the manufacturer.
max, DUT
T Highest temperature at which an internal temperature control system, for example liquid
max,ITCS
coolant, of a battery pack or system can be used. Specified by the manufacturer.
T Lowest ambient temperature of a battery pack or system specified by the manufacturer
min
(e.g. storage).
*
T Low temperature, allows large currents, can be higher than T
min min
T Lowest operating temperature of a battery pack or system specified by the manufacturer.
min, DUT
T Lowest temperature at which an internal temperature control system, for example liquid
min,ITCS
coolant, of a battery pack or system can be used. Specified by the manufacturer.
X-axis Vehicle driving direction.
Y-axis Perpendicular to vehicle driving direction and vertical axis.
Z-axis Vertical axis.
4.2 Abbreviated terms
CC/CV Constant current /constant voltage
DOF Degrees of freedom
Device under test. Referring to battery pack or system used for electrically propelled
DUT
road vehicles
ITCS Internal temperature control system
State of charge. Available capacity in a battery pack or system expressed as a percentage
SOC
of rated capacity
5 Operating modes
5.1 General
An overview of the DUT operating modes according to this document is given in Table 1.
Operating modes defined in ISO 19453-1 cannot be applied because modes that are more specific are
required for a battery pack or system.
Operation of the battery pack or system with autonomous functions, for example cell voltage balancing,
in any of the operating modes shall be agreed between customer and supplier.
Table 1 — DUT operating modes
Operating Class A auxilia- BMS Main contactor Electrical op- Internal tem-
mode ry voltage eration of main perature con-
power supply trol system
live part
5.1 Unsupplied Non-operational Open No Deactivated
5.2 Unsupplied Non-operational Open No Deactivated
6.1 Supplied Non-operational Open No Deactivated
6.2 Supplied Operational Open No Deactivated
6.3 Supplied Operational Closed No Deactivated
7.1 Supplied Operational Closed Yes Deactivated
7.2 Supplied Operational Closed Yes Activated
NOTE 1 Auxiliary voltage class A according to ISO 12405-4 refers to the voltage supply of the BMS with U or U as defined
A B
in ISO 19453-1.
NOTE 2 The difference between operating mode 5.1 and 5.2 is the presence of the wiring harness and the connection to all
interfaces.
NOTE 3 The difference between operating mode 7.1 and 7.2 is that in operating mode 7.2 an ITCS is required due to self-
heating effects caused by system activation.
NOTE 4 The conditions for an activated ITCS are set and controlled by the BMS regarding the thermal
management strategy and the operational limits of the battery pack or system. If the ITCS is deactivated, it has no function.
With deactivated ITCS, safety measures to limit the DUT temperature are still allowed at any time.
If the electronic control unit of a battery pack or system cannot provide the necessary BMS functionality,
appropriate additional electric and/or electronic controllers to provide BMS functionality may be used
in agreement between customer and supplier.
If the DUT has an internal temperature control system, the thermal management system and the
corresponding conditioning loop at the test bench equipment shall be operational according to the
given test specifications and controlled by the BMS. For the requested test procedure, the thermal
management strategy and operational limits of the DUT shall be met.
4 © ISO 2020 – All rights reserved

Some test methods in this document require intended temperature settings for the ITCS beyond the
thermal management strategy of the DUT controlled by the BMS. For these test procedures the thermal
management system and conditioning loop at the test bench equipment is controlled externally by
the test equipment according to the test specifications but within the battery system operational and
safety limits.
If a liquid based internal temperature control system is used in the battery pack, the liquid circulating
system shall be filled with the intended liquid (heat transfer medium) of the nominal volume and
pressure. Up until operating mode 6.3 without use of the temperature control system, the openings
can be sealed accordingly. If the fluid system is operated, the nominal flow rate as specified by the
manufacturer should be used.
NOTE 1 For further information on the preparation of the DUT for testing, see ISO 12405-4:2018, 5.4.
NOTE 2 Pressure compensating devices can be needed for testing with liquid based internal temperature
control systems.
5.2 Operating mode 5
No external voltages are applied to the DUT. The main contactor, if present, shall be opened.
— Operating mode 5.1
— Not connected to wiring harness or any electrical interconnections or interfaces. Protective
caps for the electrical interconnections and interfaces can be present.
— Operating mode 5.2
— Connected to wiring harness including all electrical interconnections and interfaces simulating
vehicle installation.
5.3 Operating mode 6
The DUT with all electrical connections made and connected to all interfaces is electrically operated
with class A auxiliary supply voltage U as defined in ISO 19453-1, as in a vehicle with shut-off engine,
B
but without operating load for the main power supply live part of the battery pack or system.
— Operating mode 6.1
— BMS functions are not operational, no communication.
— Battery pack or system shall be without electric operation (e.g. charging, discharging).
— Main contactor, if present, shall be opened.
— Operating mode 6.2
— BMS shall be fully operational according to the test specification.
— Battery pack or system shall be without electric operation (e.g. charging, discharging).
— Main contactor, if present, shall be opened.
— Operating mode 6.3
— BMS shall be fully operational according to the test specification.
— Battery pack or system shall be without electric operation (e.g. charging, discharging).
— Main contactor, if present, shall be closed.
5.4 Operating mode 7
The DUT with all electrical connections made and connected to all interfaces is electrically operated
with class A auxiliary voltage U as defined in ISO 19453-1 and with auxiliary machines, for example
B
cooling system etc. The main contactor, if present, shall be closed.
— Operating mode 7.1
— BMS shall be fully operational according to the test specification.
— Battery pack or system with control in an electrical operating mode in which, if present, the
ITCS is not operational.
— Operating mode 7.2
— BMS shall be fully operational according to the test specification.
— Battery pack or system shall be within control in a typical electrical operating mode, in which
if needed, the ITCS is operational.
6 Functional status classification
Functional status classification is as defined in ISO 19453-1.
The verification of the required functional status takes place by means of continuous parameter
monitoring or a parameter test.
Relevant control and test signals should be logged with sufficient resolution. Battery cycler and climate
chamber data should be monitored
7 Functional status checks
7.1 Electrical requirements check
7.1.1 General
The tests described below are intended to ensure the insulation performance of the basic insulation
measure of a voltage class B battery pack or system after completing environmental tests. The described
tests shall be performed at the end of a sequence of environmental tests. If only a single environmental
test is performed, they shall be performed afterwards.
NOTE 1 Performing the test sequence of an insulation resistance test followed by a withstand voltage test and
finally a second insulation resistance test allows to determine whether the applied voltage level of the withstand
voltage test had a permanent degrading effect on the insulation or not.
NOTE 2 Although not required for a voltage class A battery pack or system, the tests described in this section
can technically also be applied to a voltage class A component, if applicable.
7.1.2 Equipotential bonding
This test ensures the required electrical resistances for equipotential bonding of conductively
connected parts of the DUT. In particular as requirement for 7.1.3 and 7.1.4.
The equipotential bonding test shall be performed in accordance with ISO 6469-3.
The electrical resistance value shall meet the requirements of ISO 6469-3
6 © ISO 2020 – All rights reserved

7.1.3 Insulation resistance
This test measures the resistance value between main power supply live part and conductive parts of
the DUT.
The insulation resistance test shall be performed in accordance with ISO 6469-3.
The insulation resistance value shall meet the requirements of ISO 6469-3.
7.1.4 Withstand voltage test
This test ensures the dielectric withstand voltage capability and detects pre-damaged parts of the
insulation measure and weak points in the design, for example by conductive particles originating from
production or rework, that could result in a failure of the insulation measure at later stages.
The withstand voltage test shall be performed in accordance with ISO 6469-3:2018/Amd 1.
The requirements of ISO 6469-3:2018/Amd 1 shall be met.
7.2 Mechanical requirements check
7.2.1 Technical tightness check of battery pack or system enclosure
The purpose of this test is to verify the technical tightness of the battery pack or system enclosure
according to the desired degree of protection.
The method to check the technical tightness of the traction battery pack or system enclosure with
specified degrees of protection in accordance with ISO 20653 via non-destructive tests and acceptance
criteria shall be agreed between customer and supplier.
NOTE Non-destructive leak test techniques are listed in ISO 20653 or EN 1779. EN 13184, EN 13185 and
EN 1593 support the implementation of techniques according to EN 1779.
The test method shall describe at least following items:
— technique used;
— pre-condition(s) (e.g. required room temperature, required acclimation time of the DUT at room
temperature, condition of pressure compensation device);
— action(s);
— post condition(s);
— pass criteria;
— documentation content in test report;
— equipment.
7.2.2 Leak tightness check of internal temperature control system
The purpose of this test is to verify the leak tightness of the ITCS of the battery pack or system. The test
shall only be performed if the DUT has a liquid medium for the ITCS, for example internal or external
cooling-circuit.
The method for the leak test of the ITCS shall be agreed between customer and supplier.
The acceptance criteria shall be agreed between customer and supplier in order to satisfy the design
requirement.
NOTE 1 This test can be performed with a pressure loss test, pressure difference, leakage volume or in
accordance with EN 1779:1999, Annex A using a tracer gas in conjunction with a leak detector.
NOTE 2 An exemplary description a leak tightness check is given in Annex A.
8 Tests and requirements
8.1 Mechanical categories of battery packs or systems
Traction battery packs or systems for electric vehicles have a wide range of sizes and masses as well
as a variety of mounting locations in the vehicle. Linked to these parameters is the strength of vehicle
and DUT interaction, such as torsional forces. Taking all these factors into account, battery packs or
systems shall be divided into three categories, as shown in Figure 1.
Figure 1 — Example of mechanical categorization and mounting locations
NOTE 1 The categorization according to mass is only meant as a rough guideline. An individual decision for a
specific application which category is applicable can be made between customer and supplier, preferably based
on vehicle measurements or simulations conducted by the customer.
NOTE 2 In case it is difficult to distinguish clearly between categories 2 and 3, a calculation of the vehicle body
with and without the battery pack or system provides valuable information regarding resonance frequencies,
stiffness, etc. If there is a significant difference in the calculation results with and without the battery pack or
system, i.e. a strong interaction, the battery pack or system can be classified in category 3.
8.1.1 Category 1
This category is characterized by:
— local mounting in the vehicle (point-load);
— stiffness of vehicle body has no impact on DUT;
— no significant dynamic interaction of the DUT with the vehicle chassis;
— typical DUT mass ≤20 kg.
8 © ISO 2020 – All rights reserved

8.1.2 Category 2
This category is characterized by:
— local mounting in the vehicle (point-load);
— stiffness of vehicle body has secondary impact on DUT;
— low dynamic interaction of the DUT with the vehicle chassis;
— typical DUT mass >20 kg.
8.1.3 Category 3
This category is characterized by:
— large area mounting in the vehicle with different loads at different points of DUT;
— stiffness of vehicle body has primary impact on DUT;
— interaction with the vehicle chassis and dynamic stiffness;
— DUT can be part of the carrying vehicle structure (structurally integrated
...
