Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2. www.iso.org/directives
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of any
patent rights identified during the development of the document will be in the Introduction and/or on
the ISO list of patent declarations received. www.iso.org/patents
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
The committee responsible for this document is ISO/TC 22, Road vehicles, Subcommittee SC 10, Impact
test procedures.
iv © ISO 2013 – All rights reserved

Introduction
WorldSID is a world harmonized anthropomorphic test device for the evaluation of motor vehicle side-
impact protection.
The aim of this International Standard is to provide a repeatable seating and positioning procedure that
can be applied across the world vehicle fleet.
INTERNATIONAL STANDARD ISO 17949:2013(E)
Impact test procedures for road vehicles — Seating and
positioning procedures for anthropomorphic test devices —
Procedure for the WorldSID 5Oth percentile male side-
impact dummy in front outboard seating positions
1 Scope
This International Standard specifies the conditions and requirements for the recommended placement
of the WorldSID 50th percentile male side-impact dummy (WS50), as defined in ISO 15830-1, ISO 15830-2,
ISO 15830-3, and ISO 15830-4, when used in front outboard seating positions of motor vehicles for side-
impact testing.
2 Normative references
The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated
references, the latest edition of the referenced document (including any amendments) applies.
ISO 15830-1, Road vehicles — Design and performance specifications for the WorldSID 50th percentile male
side-impact dummy — Part 1: Terminology and rationale
ISO 15830-2, Road vehicles — Design and performance specifications for the WorldSID 50th percentile male
side-impact dummy — Part 2: Mechanical subsystems
ISO 15830-3, Road vehicles — Design and performance specifications for the WorldSID 50th percentile male
side-impact dummy — Part 3: Electronic subsystems
ISO 15830-4, Road vehicles — Design and performance specifications for the WorldSID 50th percentile male
side impact dummy — Part 4: User’s manual
SAE J 826, Devices for use and defining and measuring vehicle seating accommodation
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1
test seat
seating position, driver, or front passenger that is to be evaluated
3.2
saggital plane
vertical plane that divides the human body into left/right sections
Note 1 to entry: See Figure 1.
3.3
coronal plane
vertical plane that is perpendicular to the sagittal plane and that divides the human body into
anterior/posterior sections
Note 1 to entry: See Figure 1.
Key
1 sagittal plane
2 coronal plane
3 transverse plane
Figure 1 — Anatomical planes
4 Symbols and abbreviated terms
X forward direction of the vehicle
Y lateral direction of the vehicle
Z downward direction of the vehicle
5 Requirements for vehicle seats preparation
5.1 Seat adjustments
a) Position any adjustable parts that provide additional support so that they are in the lowest or fully
retracted position, e.g.:
— Position the seat’s adjustable lumbar supports so that the lumbar supports are in the lowest,
retracted, or deflated adjustment positions.
2 © ISO 2013 – All rights reserved

— Position an adjustable seat cushion length to the retracted position.
— Position an adjustable leg support
...
