ISO 13597:2000
(Main)Aerospace - Inserts, self-locking, with MJ threads, open type, in metallic material, coated or uncoated - Dimensions
Aerospace - Inserts, self-locking, with MJ threads, open type, in metallic material, coated or uncoated - Dimensions
This International Standard specifies the dimensions of open inserts, with self-locking MJ threads, in metallic material, coated or uncoated, for honeycomb and composite materials. The classification referring to strength and temperature, depending on the core material and potting compound, is not specified. This International Standard is only applicable to the compilation of aerospace product standards.
Aéronautique et espace — Douilles filetées, à freinage interne et filetage MJ, du type ouvert, en matériau métallique, revêtues ou non revêtues — Dimensions
La présente Norme internationale spécifie les dimensions des douilles filetées ouvertes, à freinage interne et filetage MJ, en matériau métallique, revêtues ou non revêtues, pour des matériaux composites et à nids d'abeilles. La classification concernant la résistance et la température, étant fonction du matériau de base et du mastic de remplissage, n'est pas spécifiée. La présente Norme internationale est applicable uniquement à l'élaboration de normes de produit destinées aux constructions aérospatiales.
General Information
- Status
- Published
- Publication Date
- 23-Feb-2000
- Technical Committee
- ISO/TC 20/SC 4 - Aerospace fastener systems
- Drafting Committee
- ISO/TC 20/SC 4 - Aerospace fastener systems
- Current Stage
- 9060 - Close of review
- Completion Date
- 04-Mar-2030
Overview
ISO 13597:2000 is an international standard developed by the International Organization for Standardization (ISO) that specifies the dimensions of self-locking inserts with MJ threads, designed for aerospace applications. These inserts are open type, manufactured in metallic materials, and may be coated or uncoated. The standard focuses specifically on inserts used with honeycomb and composite materials commonly found in aerospace structures.
This standard ensures uniformity and compatibility of inserts, facilitating reliable fastening solutions in demanding aerospace environments. ISO 13597:2000 applies exclusively to the compilation of aerospace product standards and excludes classifications referring to strength and temperature, which depend on the core material and potting compound.
Key Topics
Insert Type and Material
The standard covers open-type, self-locking inserts with MJ threaded profiles in metallic materials, with options for coated or uncoated finishes.Dimensional Specifications
All dimensions and tolerances are precisely defined in millimeters. These apply to inserts post any surface coating processes, ensuring consistent performance and interchangeability.Thread Standards Reference
ISO 13597 references ISO 5855-2:1999 for limit dimensions related to MJ threads, bolts, and nuts, providing a cohesive framework for thread compatibility.Design Features
- Self-locking MJ threads that maintain secure fastening in composite sandwich panels.
- Optional anti-rotation features on the shank or bottom flange to enhance mechanical locking.
- Potting and vent holes to support installation in composite materials and assist in bonding.
Application in Honeycomb and Composite Panels
Inserts conform to the needs of aerospace sandwich panel assemblies, where lightweight and strong fastening solutions are critical.
Applications
Aerospace Manufacturing
ISO 13597 inserts are widely used in aircraft and space vehicle manufacturing for fastening components to composite and honeycomb sandwich structures. Their self-locking nature ensures vibration resistance and durability in harsh environments.Maintenance and Repair
During aircraft maintenance, replacement inserts conforming to ISO 13597 guarantee continued safety and structural integrity without the risk of incompatibility.Composite Panel Fabrication
The standard supports manufacturing processes involving potting compounds and core materials to embed inserts securely within multifunctional composite panels.
Related Standards
- ISO 5855-2:1999 – Aerospace MJ threads: Defines limit dimensions for bolts and nuts complementing the insert thread profiles given in ISO 13597.
- ISO/TC 20 – Technical committee responsible for aircraft and spacecraft standardization, ensuring coordinated development of aerospace fastener systems.
- Aerospace Fastening Standards – Applicable documents covering other types of inserts, fasteners, and locking mechanisms used in aerospace structures.
Why ISO 13597:2000 Matters
Ensures Dimensional Consistency
Critical for the interchangeability and reliability of inserts in aerospace assemblies.Enhances Fastening Reliability
Self-locking MJ threads reduce risk of loosening under vibration, a frequent challenge in aerospace environments.Supports Composite Material Use
Addresses the unique needs of fastening within composite and honeycomb core structures, enhancing aerospace design flexibility.
By adhering to ISO 13597:2000, aerospace manufacturers and suppliers standardize the use of self-locking metallic inserts, achieve greater product reliability, and streamline assembly processes in advanced composite structures.
ISO 13597:2000 - Aerospace -- Inserts, self-locking, with MJ threads, open type, in metallic material, coated or uncoated -- Dimensions
ISO 13597:2000 - Aéronautique et espace -- Douilles filetées, a freinage interne et filetage MJ, du type ouvert, en matériau métallique, revetues ou non revetues -- Dimensions
Frequently Asked Questions
ISO 13597:2000 is a standard published by the International Organization for Standardization (ISO). Its full title is "Aerospace - Inserts, self-locking, with MJ threads, open type, in metallic material, coated or uncoated - Dimensions". This standard covers: This International Standard specifies the dimensions of open inserts, with self-locking MJ threads, in metallic material, coated or uncoated, for honeycomb and composite materials. The classification referring to strength and temperature, depending on the core material and potting compound, is not specified. This International Standard is only applicable to the compilation of aerospace product standards.
This International Standard specifies the dimensions of open inserts, with self-locking MJ threads, in metallic material, coated or uncoated, for honeycomb and composite materials. The classification referring to strength and temperature, depending on the core material and potting compound, is not specified. This International Standard is only applicable to the compilation of aerospace product standards.
ISO 13597:2000 is classified under the following ICS (International Classification for Standards) categories: 49.030.99 - Other fasteners. The ICS classification helps identify the subject area and facilitates finding related standards.
ISO 13597:2000 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
