ISO/IEC 14496-10:2012/DAM 2
Information technolog — Coding of audio-visual objects —
Part 10: Advanced Video Coding, AMENDMENT 2: MVC
extensions for inclusion of depth maps
AMENDMENT 2
In 0.6, add the following paragraph after the paragraph that starts with “Multiview video coding”:
An extension of multiview video coding that also supports the inclusion of depth maps is specified in Annex I allowing
the construction of bitstreams that represent multiple views with corresponding depth views. Similar to multiview video
coding, bitstreams that include multiple depth views may also contain sub-bitstreams that conform to this specification.
For temporal bitstream scalability, i.e., the presence of a sub-bitstream with a smaller temporal sampling rate than the
bitstream, complete access units are removed from the bitstream when deriving the sub-bitstream. For view bitstream
scalability, i.e. the presence of a sub-bitstream with fewer views than those included in the bitstream, NAL units are
removed from the bitstream when deriving the sub-bitstream. In this case, inter-view prediction, i.e., the prediction of one
view by data of another view signal, is typically used for efficient coding.

In 0.7, add the following paragraph after the paragraph that starts with “Annex H specifies”:
Annex I specifies MVC extensions for inclusion of depth maps, referred to as 3D Video Coding (3DVC). The reader is
referred to Annex I for the entire decoding process for 3DVC, which is specified there with references being made to
clauses 2-9 and Annexes A-E and Annex H. Subclause I.10 specifies one profile for 3DVC (Multiview and Depth).

© ISO/IEC 2012 – All rights reserved 1

ISO/IEC 14496-10:2012/DAM 2
In 7.3.1, replace the syntax table with:

nal_unit( NumBytesInNALunit ) { C Descriptor
forbidden_zero_bit All f(1)
nal_ref_idc All u(2)
nal_unit_type All u(5)
NumBytesInRBSP = 0
nalUnitHeaderBytes = 1
if( nal_unit_type = = 14 | | nal_unit_type = = 20  | |
nal_unit_type = = 21) {
svc_extension_flag All u(1)
if( !svc_extension_flag | | nal_unit_type = = 21 ) )
nal_unit_header_mvc_extension( ) /* specified in Annex H */ All
else
nal_unit_header_svc_extension( ) /* specified in Annex G */ All
nalUnitHeaderBytes += 3
}
for( i = nalUnitHeaderBytes; i < NumBytesInNALunit; i++ ) {
if( i + 2 < NumBytesInNALunit && next_bits( 24 ) = = 0x000003 ) {
rbsp_byte[ NumBytesInRBSP++ ] All b(8)
rbsp_byte[ NumBytesInRBSP++ ] All b(8)
i += 2
emulation_prevention_three_byte /* equal to 0x03 */ All f(8)
} else
rbsp_byte[ NumBytesInRBSP++ ] All b(8)
}
}
2 © ISO/IEC 2012 – All rights reserved

ISO/IEC 14496-10:2012/DAM 2
In 7.3.2.1.3, replace the syntax table with:

subset_seq_parameter_set_rbsp( ) { C Descriptor
seq_parameter_set_data( ) 0
if( profile_idc = = 83 | | profile_idc = = 86 ) {
seq_parameter_set_svc_extension( ) /* specified in Annex G */ 0
svc_vui_parameters_present_flag 0 u(1)
if( svc_vui_parameters_present_flag = = 1 )
svc_vui_parameters_extension( ) /* specified in Annex G */ 0
} else if( profile_idc = = 118 | | profile_idc = = 128 ) {
bit_equal_to_one /* equal to 1 */ 0 f(1)
seq_parameter_set_mvc_extension( ) /* specified in Annex H */ 0
mvc_vui_parameters_present_flag 0 u(1)
if( mvc_vui_parameters_present_flag = = 1 )
mvc_vui_parameters_extension( ) /* specified in Annex H */ 0
}
if( profile_idc = = 138 ) {
bit_equal_to_one /* equal to 1 */ 0 f(1)
seq_parameter_set_mvc_extension( ) /* specified in Annex H */ 0
seq_parameter_set_3dvc_extension( ) 0
}
additional_extension3_flag 0 u(1)
if( additional_extension3_flag = = 1 )
while( more_rbsp_data( ) )
additional_extension3_data_flag 0 u(1)
rbsp_trailing_bits( ) 0
}
In 7.3.3, replace the syntax table with:

slice_header( ) { C Descriptor
first_mb_in_slice 2 ue(v)
slice_type 2 ue(v)
pic_parameter_set_id 2 ue(v)
if( separate_colour_plane_flag = = 1 )
colour_plane_id 2 u(2)
frame_num 2 u(v)
if( !frame_mbs_only_flag ) {
field_pic_flag 2 u(1)
if( field_pic_flag )
bottom_field_flag 2 u(1)
}
if( IdrPicFlag )
idr_pic_id 2 ue(v)
if( pic_order_cnt_type = = 0 ) {
pic_order_cnt_lsb 2 u(v)
if( bottom_field_pic_order_in_frame_present_flag && !field_pic_flag )
© ISO/IEC 2012 – All rights reserved 3

ISO/IEC 14496-10:2012/DAM 2
delta_pic_order_cnt_bottom 2 se(v)
}
if( pic_order_cnt_type = = 1 && !delta_pic_order_always_zero_flag ) {
delta_pic_order_cnt[ 0 ] 2 se(v)
if( bottom_field_pic_order_in_frame_present_flag && !field_pic_flag )
delta_pic_order_cnt[ 1 ] 2 se(v)
}
if( redundant_pic_cnt_present_flag )
redundant_pic_cnt 2 ue(v)
if( slice_type = = B )
direct_spatial_mv_pred_flag 2 u(1)
if( slice_type = = P | | slice_type = = SP | | slice_type = = B ) {
num_ref_idx_active_override_flag 2 u(1)
if( num_ref_idx_active_override_flag ) {
num_ref_idx_l0_active_minus1 2 ue(v)
if( slice_type = = B )
num_ref_idx_l1_active_minus1 2 ue(v)
}
}
if( nal_unit_type = = 20 | | nal_unit_type = = 21 )
ref_pic_list_mvc_modification( ) /* specified in Annex H */ 2
else
ref_pic_list_modification( ) 2
if( ( weighted_pred_flag && ( slice_type = = P | | slice_type = = SP ) ) | |
( weighted_bipred_idc = = 1 && slice_type = = B ) )
pred_weight_table( ) 2
if( nal_ref_idc != 0 )
dec_ref_pic_marking( ) 2
if( entropy_coding_mode_flag && slice_type != I && slice_type != SI )
cabac_init_idc 2 ue(v)
slice_qp_delta 2 se(v)
if( slice_type = = SP | | slice_type = = SI ) {
if( slice_type = = SP )
sp_for_switch_flag 2 u(1)
slice_qs_delta 2 se(v)
}
if( deblocking_filter_control_present_flag ) {
disable_deblocking_filter_idc 2 ue(v)
if( disable_deblocking_filter_idc != 1 ) {
2 se(v)
slice_alpha_c0_offset_div2
2 se(v)
slice_beta_offset_div2
}
}
if( num_slice_groups_minus1 > 0 &&
slice_group_map_type >= 3 && slice_group_map_type <= 5)
slice_group_change_cycle 2 u(v)
}
4 © ISO/IEC 2012 – All rights reserved

ISO/IEC 14496-10:2012/DAM 2
Replace Table 7-1 with:
nal_unit_type Content of NAL unit and RBSP C Annex A Annex G Annex I
syntax structure NAL unit and NAL unit
type class Annex H type class
NAL unit
type class
0 Unspecified non-VCL non-VCL
non-VCL
1 Coded slice of a non-IDR picture 2, 3, 4 VCL VCL
VCL
slice_layer_without_partitioning_rbsp( )
2 Coded slice data partition A 2 VCL not
not
slice_data_partition_a_layer_rbsp( ) applicable
applicable
3 Coded slice data partition B 3 VCL not
not
slice_data_partition_b_layer_rbsp( ) applicable
applicable
4 Coded slice data partition C 4 VCL not
not
slice_data_partition_c_layer_rbsp( ) applicable
applicable
5 Coded slice of an IDR picture 2, 3 VCL VCL
VCL
slice_layer_without_partitioning_rbsp( )
6 Supplemental enhancement information 5 non-VCL non-VCL
(SEI)
non-VCL
sei_rbsp( )
7 Sequence parameter set 0 non-VCL non-VCL
non-VCL
seq_parameter_set_rbsp( )
8 Picture parameter set 1 non-VCL non-VCL
non-VCL
pic_parameter_set_rbsp( )
9 Access unit delimiter 6 non-VCL non-VCL
non-VCL
access_unit_delimiter_rbsp( )
10 End of sequence 7 non-VCL non-VCL
non-VCL
end_of_seq_rbsp( )
11 End of stream 8 non-VCL non-VCL
non-VCL
end_of_stream_rbsp( )
12 Filler data 9 non-VCL non-VCL
non-VCL
filler_data_rbsp( )
13 Sequence parameter set extension 10 non-VCL non-VCL
non-VCL
seq_parameter_set_extension_rbsp( )
14 Prefix NAL unit 2 non-VCL suffix
suffix
prefix_nal_unit_rbsp( ) dependent
dependent
15 Subset sequence parameter set 0 non-VCL non-VCL
non-VCL
subset_seq_parameter_set_rbsp( )
16.18 Reserved non-VCL non-VCL
non-VCL
19 Coded slice of an auxiliary coded 2, 3, 4 non-VCL non-VCL
picture without partitioning
non-VCL
slice_layer_without_partitioning_rbsp( )
20 Coded slice extension 2, 3, 4 non-VCL VCL
VCL
slice_layer_extension_rbsp( )
21 Coded slice extension for depth view 2, 3, 4 non-VCL VCL
VCL
© ISO/IEC 2012 – All rights reserved 5

ISO/IEC 14496-10:2012/DAM 2
components /*specified in Annex I */
slice_layer_extension_rbsp( ) /*
specified in Annex I */
22.23 Reserved non-VCL non-VCL
VCL
24.31 Unspecified non-VCL non-VCL non-VCL

In 7.4.1, add the following paragraph in the semantics of svc_extension_flag just before the semantics of
rbsp_byte[ i ].
The value of svc_extension_flag shall be equal to 0 for coded video sequences conforming to one or more profiles
specified in Annex I. Decoders conforming to one or more profiles specified in Annex I shall ignore (remove from the
bitstream and discard) NAL units for which nal_unit_type is equal to 14, 20, or 21 and for which svc_extension_flag is
equal to 1.
In 7.4.2.1.3, make the following changes:
Replace the sentence following text in the semantics of chroma_format_idc after “inclusive.” with:
When chroma_format_idc is not present and when profile_idc is equal to 138, it shall be inferred to be equal to 0 (4:0:0
chroma format), otherwise, it shall be inferred to be equal to 1 (4:2:0 chroma format).

Substitute each occurrence of “additional_extension2_flag” with “additional_extension3_flag”.
Replace the semantics of additional_extension2_data_flag with the following:
additional_extension3_data_flag may have any value. It shall not affect the conformance to profiles specified in
Annex A, G, H, or I.
6 © ISO/IEC 2012 – All rights reserved

ISO/IEC 14496-10:2012/DAM 2
Replace Annex C with:
Annex C\
Hypothetical reference decoder

− (This annex forms an integral part of this Recommendation | International Standard)
This annex specifies the hypothetical reference decoder (HRD) and its use to check bitstream and decoder conformance.
Two types of bitstreams are subject to HRD conformance checking for this Recommendation | International Standard.
The first such type of bitstream, called Type I bitstream, is a NAL unit stream containing only the VCL NAL units and
filler data NAL units for all access units in the bitstream. The second type of bitstream, called a Type II bitstream,
contains, in addition to the VCL NAL units and filler data NAL units for all access units in the bitstream, at least one of
the following:
– additional non-VCL NAL units other than filler data NAL units,
– all leading_zero_8bits, zero_byte, start_code_prefix_one_3bytes, and trailing_zero_8bits syntax elements that form
a byte stream from the NAL unit stream (as specified in Annex B).
Figure C-1 shows the types of bitstream conformance points checked by the HRD.
Non-VCL NAL units other
VCL NAL units than filter data NAL units
Filter data NAL units
Byte stream format
encapsulation
(see Annex B)
H.264(09)_FC-1
Figure C-1 – Structure of byte streams and NAL unit streams for HRD conformance checks
The syntax elements of non-VCL NAL units (or their default values for some of the syntax elements), required for the
HRD, are specified in the semantic subclauses of clause 7, Annexes D and E, and subclauses G.7, G.13, G.14, H.7, H.13,
H.14, I.7, I.13, and I.14.
Two types of HRD parameter sets (NAL HRD parameters and VCL HRD parameters) are used. The HRD parameter sets
are signalled as follows:
– When the coded video sequence conforms to one or more of the profiles specified in Annex A and the decoding
process specified in clauses 2-9 is applied, the HRD parameter sets are signalled through video usability information
as specified in subclauses E.1 and E.2, which is part of the sequence parameter set syntax structure.
– When the coded video sequence conforms to one or more of the profiles specified in Annex G and the decoding
process specified in Annex G is applied, the HRD parameter sets are signalled through the SVC video usability
information extension as specified in subclauses G.14.1 and G.14.2, which is part of the subset sequence parameter
set syntax structure.
© ISO/IEC 2012 – All rights reserved 7

ISO/IEC 14496-10:2012/DAM 2
NOTE 1 – For coded video sequences that conform to both, one or more of the profiles specified in Annex A and one
or more of the profiles specified in Annex G, the signalling of the applicable HRD parameter sets is depending on
whether the decoding process specified in clauses 2-9 or the decoding process specified in Annex G is applied.
– When the coded video sequence conforms to one or more of the profiles specified in Annex H and the decoding
process specified in Annex H is applied, the HRD parameter sets are signalled through the MVC video usability
information extension as specified in subclauses H.14.1 and H.14.2, which is part of the subset sequence parameter
set syntax structure.
NOTE 2 – For coded video sequences that conform to both, one or more of the profiles specified in Annex A and one
or more of the profiles specified in Annex H, the signalling of the applicable HRD parameter sets is depending on
whether the decoding process specified in clauses 2-9 or the decoding process specified in Annex H is applied.
– When the coded video sequence conforms to one or more of the profiles specified in Annex I and the decoding
process specified in Annex I is applied, the HRD parameter sets are signalled through the MVC video usability
information extension as specified in subclauses I.14, which is part of the subset sequence parameter set syntax
structure.
NOTE 3 – For coded video sequences that conform to one or more of the profiles specified in Annex A, one or more
of the profiles specified in Annex H and one or more of the profiles specified in Annex I, the signalling of the
applicable HRD parameter sets is depending on whether the decoding process specified in clauses 2-9, the decoding
process specified in Annex H or the decoding process specified in Annex I is applied.
All sequence parameter sets and picture parameter sets referred to in the VCL NAL units, and corresponding buffering
period and picture timing SEI messages shall be conveyed to the HRD, in a timely manner, either in the bitstream (by
non-VCL NAL units), or by other means not specified in this Recommendation | International Standard.
In Annexes C, D, and E and subclauses G.12, G.13, G.14, H.12, H.13, H.14, I.12, I.13, and I.14, the specification for
"presence" of non-VCL NAL units is also satisfied when those NAL units (or just some of them) are conveyed to
decoders (or to the HRD) by other means not specified by this Recommendation | International Standard. For the purpose
of counting bits, only the appropriate bits that are actually present in the bitstream are counted.
NOTE 3 – As an example, synchronization of a non-VCL NAL unit, conveyed by means other than presence in the
bitstream, with the NAL units that are present in the bitstream, can be achieved by indicating two points in the
bitstream, between which the non-VCL NAL unit would have been present in the bitstream, had the encoder decided
to convey it in the bitstream.
When the content of a non-VCL NAL unit is conveyed for the application by some means other than presence within the
bitstream, the representation of the content of the non-VCL NAL unit is not required to use the same syntax specified in
this annex.
NOTE 4 – When HRD information is contained within the bitstream, it is possible to verify the conformance of a
bitstream to the requirements of this subclause based solely on information contained in the bitstream. When the HRD
information is not present in the bitstream, as is the case for all "stand-alone" Type I bitstreams, conformance can
only be verified when the HRD data is supplied by some other means not specified in this Recommendation |
International Standard.
The HRD contains a coded picture buffer (CPB), an instantaneous decoding process, a decoded picture buffer (DPB), and
output cropping as shown in Figure C-2.
8 © ISO/IEC 2012 – All rights reserved

ISO/IEC 14496-10:2012/DAM 2
Hypothetical stream
scheduler (HSS)
Type I or type II bitstream
Coded picture
buffer (CPB)
Access units
Decoding process
(instantaneous)
Reference
Pictures
pictures
Decoded picture
buffer (DPB)
Pictures
Output cropping
Output cropped pictures
Figure C-2 – HRD buffer model
The CPB size (number of bits) is CpbSize[ SchedSelIdx ]. The DPB size (number of frame buffers) is
Max( 1, max_dec_frame_buffering ). When the coded video sequence conforms to one or more of the profiles specified
in Annex H and the decoding process specified in Annex H is applied, the DPB size is specified in units of view
components. When the coded video sequence conforms to one or more of the profiles specified in Annex I and the
decoding process specified in Annex I is applied, the DPB size is specified in units of texture view components and depth
view components.
The HRD operates as follows. Data associated with access units that flow into the CPB according to a specified arrival
schedule are delivered by the HSS. The data associated with each access unit are removed and decoded instantaneously
by the instantaneous decoding process at CPB removal times. Each decoded picture is placed in the DPB at its CPB
removal time unless it is output at its CPB removal time and is a non-reference picture. When a picture is placed in the
DPB it is removed from the DPB at the later of the DPB output time or the time that it is marked as "unused for
reference".
For each picture in the bitstream, the variable OutputFlag for the decoded picture and, when applicable, the reference
base picture is set as follows:
– If the coded video sequence containing the picture conforms to one or more of the profiles specified in Annex A and
the decoding process specified in clauses 2-9 is applied, OutputFlag is set equal to 1.
– Otherwise, if the coded video sequence containing the picture conforms to one or more of the profiles specified in
Annex G and the decoding process specified in Annex G is applied, the following applies:
– For a reference base picture, OutputFlag is set equal to 0.
– For a decoded picture, OutputFlag is set equal to the value of the output_flag syntax element of the target layer
representation.
– Otherwise (the coded video sequence containing the picture conforms to one or more of the profiles specified in
Annex H and the decoding process specified in Annex H is applied), the following applies:
© ISO/IEC 2012 – All rights reserved 9

ISO/IEC 14496-10:2012/DAM 2
– For the decoded view components of the target output views, OutputFlag is set equal to 1.
– For the decoded view components of other views, OutputFlag is set equal to 0.
– Otherwise (the coded video sequence containing the picture conforms to one or more of the profiles specified in
Annex I and the decoding process specified in Annex I is applied), the following applies:
– For the decoded texture view components and depth view component with same VOIdx of the target output
views, OutputFlag is set equal to 1.
– For the decoded texture view components and depth view component with same VOIdx of other views,
OutputFlag is set equal to 0.
The operation of the CPB is specified in subclause C.1. The instantaneous decoder operation is specified in clauses 2-9
(for coded video sequences conforming to one or more of the profiles specified in Annex A) and in Annex G (for coded
video sequences conforming to one or more of the profiles specified in Annex G) and in Annex H (for coded video
sequences conforming to one or more of the profiles specified in Annex H) and in Annex I (for coded video sequences
conforming to one or more of the profiles specified in Annex I). The operation of the DPB is specified in subclause C.2.
The output cropping is specified in subclause C.2.2.
NOTE 5 – Coded video sequences that conform to both, one or more of the profiles specified in Annex A and one or
more of the profiles specified in Annex G, can be decoded either by the decoding process specified in clauses 2-9 or
by the decoding process specified in Annex G. The decoding result and the HRD operation may be depending on
which of the decoding processes is applied.
NOTE 6 – Coded video sequences that conform to both, one or more of the profiles specified in Annex A and one or
more of the profiles specified in Annex H, can be decoded either by the decoding process specified in clauses 2-9 or
by the decoding process specified in Annex H. The decoding result and the HRD operation may be depending on
which of the decoding processes is applied.
NOTE 7 – Coded video sequences that conform to one or more of the profiles specified in Annex A, one or more of
the profiles specified in Annex H and one or more of the profiles specified in Annex I, can be decoded either by the
decoding process specified in clauses 2-9, by the decoding process specified in Annex H or by the decoding process
specified in Annex I. The decoding result and the HRD operation may be depending on which of the decoding
processes is applied.
HSS and HRD information concerning the number of enumerated delivery schedules and their associated bit rates and
buffer sizes is specified in subclauses E.1.1, E.1.2, E.2.1, E.2.2, G.14.1, G.14.2, H.14.1, H.14.2 and I.14. The HRD is
initialised as specified by the buffering period SEI message as specified in subclauses D.1.1 and D.2.1. The removal
timing of access units from the CPB and output timing from the DPB are specified in the picture timing SEI message as
specified in subclauses D.1.2 and D.2.2. All timing information relating to a specific access unit shall arrive prior to the
CPB removal time of the access unit.
When the coded video sequence conforms to one or more of the profiles specified in Annex G and the decoding process
specified in Annex G is applied, the following is specified:
(a) When an access unit contains one or more buffering period SEI messages that are included in scalable nesting
SEI messages and are associated with values of DQId in the range of ( ( DQIdMax >> 4) << 4 ) to
( ( ( DQIdMax >> 4 ) << 4 ) + 15 ), inclusive, the last of these buffering period SEI messages in decoding order
is the buffering period SEI message that initialises the HRD. Let hrdDQId be the largest value of
16 * sei_dependency_id[ i ] + sei_quality_id[ i ] that is associated with the scalable nesting SEI message
containing the buffering period SEI message that initialises the HRD, let hrdDId and hrdQId be equal to
hrdDQId >> 4 and hrdDQId & 15, respectively, and let hrdTId be the value of sei_temporal_id that is
associated with the scalable nesting SEI message containing the buffering period SEI message that initialises
the HRD.
(b) The picture timing SEI messages that specify the removal timing of access units from the CPB and output
timing from the DPB are the picture timing SEI messages that are included in scalable nesting SEI messages
associated with values of sei_dependency_id[ i ], sei_quality_id[ i ], and sei_temporal_id equal to hrdDId,
hrdQId, and hrdTId, respectively.
(c) The HRD parameter sets that are used for conformance checking are the HRD parameter sets, included in the
SVC video usability information extension of the active SVC sequence parameter set, that are associated with
values of vui_ext_dependency_id[ i ], vui_ext_quality_id[ i ], and vui_ext_temporal_id[ i ] equal to hrdDId,
hrdQId, and hrdTId, respectively. For the specification in this annex, num_units_in_tick, time_scale,
fixed_frame_rate_flag, nal_hrd_parameters_present_flag, vcl_hrd_parameters_present_flag,
low_delay_hrd_flag, and pic_struct_present_flag are substituted with the values of
vui_ext_num_units_in_tick[ i ], vui_ext_time_scale[ i ], vui_ext_fixed_frame_rate_flag[ i ],
10 © ISO/IEC 2012 – All rights reserved

ISO/IEC 14496-10:2012/DAM 2
vui_ext_nal_hrd_parameters_present_flag[ i ], vui_ext_vcl_hrd_parameters_present_flag[ i ],
vui_ext_low_delay_hrd_flag[ i ], and vui_ext_pic_struct_present_flag[ i ], respectively, with i being the value
for which vui_ext_dependency_id[ i ], vui_ext_quality_id[ i ], and vui_ext_temporal_id[ i ] are equal to hrdDId,
hrdQId, and hrdTId, respectively.
When the coded video sequence conforms to one or more of the profiles specified in Annex H and the decoding process
specified in Annex H is applied, the following is specified:
(a) When an access unit contains one or more buffering period SEI messages that are included in MVC scalable
nesting SEI messages, the buffering period SEI message that is associated with the operation point being
decoded is the buffering period SEI message that initialises the HRD. Let hrdVId[ i ] be equal to
sei_op_view_id[ i ] for all i in the range of 0 to num_view_components_op_minus1, inclusive, and let hrdTId
be the value of sei_op_temporal_id, that are associated with the MVC scalable nesting SEI message containing
the buffering period SEI message that initialises the HRD.
(b) The picture timing SEI messages that specify the removal timing of access units from the CPB and output
timing from the DPB are the picture timing SEI messages that are included in MVC scalable nesting SEI
messages associated with values of sei_op_view_id[ i ] equal to hrdVId[ i ] for all i in the range of 0 to
num_view_components_op_minus1, inclusive, and sei_temporal_id equal to hrdTId.
(c) The HRD parameters that are used for conformance checking are the HRD parameters, included in the MVC
video usability information extension of the active MVC sequence parameter set, that are associated with values
of vui_mvc_view_id[ i ][ j ] for all j in the range of 0 to vui_mvc_num_target_output_views_minus1[ i ],
inclusive, equal to hrdVId[ j ], and the value of vui_mvc_temporal_id[ i ] equal to hrdTId. For the specification
in this annex, num_units_in_tick, time_scale, fixed_frame_rate_flag, nal_hrd_parameters_present_flag,
vcl_hrd_parameters_present_flag, low_delay_hrd_flag, and pic_struct_present_flag are substituted with the
values of vui_mvc_num_units_in_tick[ i ], vui_mvc_time_scale[ i ], vui_mvc_fixed_frame_rate_flag[ i ],
vui_mvc_nal_hrd_parameters_present_flag[ i ], vui_mvc_vcl_hrd_parameters_present_flag[ i ],
vui_mvc_low_delay_hrd_flag[ i ], and vui_mvc_pic_struct_present_flag[ i ], respectively, with i being the
value for which vui_mvc_view_id[ i ] is equal to hrdVId[ j ] for all j in the range of 0 to
vui_mvc_num_traget_output_views_minus1[ i ], inclusive, and vui_mvc_temporal_id[ i ] equal to hrdTId.
When the coded video sequence conforms to one or more of the profiles specified in Annex I and the decoding process
specified in Annex I is applied, the following is specified:
(a) When an access unit contains one or more buffering period SEI messages that are included in 3DVC scalable
nesting SEI messages, the buffering period SEI message that is associated with the operation point being
decoded is the buffering period SEI message that initialises the HRD. Let hrdVId[ i ] be equal to
sei_op_view_id[ i ] for all i in the range of 0 to num_view_components_op_minus1, inclusive, and let hrdTId
be the value of sei_op_temporal_id, that are associated with the 3DVC scalable nesting SEI message containing
the buffering period SEI message that initialises the HRD.
(b) The picture timing SEI messages that specify the removal timing of access units from the CPB and output
timing from the DPB are the picture timing SEI messages that are included in 3DVC scalable nesting SEI
messages associated with values of sei_op_view_id[ i ] equal to hrdVId[ i ] for all i in the range of 0 to
num_view_components_op_minus1, inclusive, and sei_temporal_id equal to hrdTId.
(c) The HRD parameter sets that are used for conformance checking are the HRD parameter sets, included in the
MVC video usability information extension of the active 3DVC sequence parameter set, that are associated with
values of vui_mvc_view_id[ i ][ j ] for all j in the range of 0 to vui_mvc_num_target_output_views_minus1[ i ],
inclusive, equal to hrdVId[ j ], and the value of vui_mvc_temporal_id[ i ] equal to hrdTId. For the specification
in this annex, num_units_in_tick, time_scale, fixed_frame_rate_flag, nal_hrd_parameters_present_flag,
vcl_hrd_parameters_present_flag, low_delay_hrd_flag, and pic_struct_present_flag are substituted with the
values of vui_mvc_num_units_in_tick[ i ], vui_mvc_time_scale[ i ], vui_mvc_fixed_frame_rate_flag[ i ],
vui_mvc_nal_hrd_parameters_present_flag[ i ], vui_mvc_vcl_hrd_parameters_present_flag[ i ],
vui_mvc_low_delay_hrd_flag[ i ], and vui_mvc_pic_struct_present_flag[ i ], respectively, with i being the
value for which vui_mvc_view_id[ i ] is equal to hrdVId[ j ] for all j in the range of 0 to
vui_mvc_num_traget_output_views_minus1[ i ], inclusive, and vui_mvc_temporal_id[ i ] equal to hrdTId.
The HRD is used to check conformance of bitstreams and decoders as specified in subclauses C.3 and C.4, respectively.
NOTE 7 – While conformance is guaranteed under the assumption that all frame-rates and clocks used to generate the
bitstream match exactly the values signalled in the bitstream, in a real system each of these may vary from the
signalled or specified value.
© ISO/IEC 2012 – All rights reserved 11

ISO/IEC 14496-10:2012/DAM 2
All the arithmetic in this annex is done with real values, so that no rounding errors can propagate. For example, the
number of bits in a CPB just prior to or after removal of an access unit is not necessarily an integer.
The variable t is derived as follows and is called a clock tick:
c
t = num_units_in_tick  time_scale (C-1)
c
The following is specified for expressing the constraints in this annex:
– Let access unit n be the n-th access unit in decoding order with the first access unit being access unit 0.
– Let picture n be the primary coded picture or the decoded primary picture of access unit n.
C.1 Operation of coded picture buffer (CPB)
The specifications in this subclause apply independently to each set of CPB parameters that is present and to both the
Type I and Type II conformance points shown in Figure C-1.
C.1.1 Timing of bitstream arrival
The HRD may be initialised at any one of the buffering period SEI messages. Prior to initialisation, the CPB is empty.
NOTE – After initialisation, the HRD is not initialised again by subsequent buffering period SEI messages.
Each access unit is referred to as access unit n, where the number n identifies the particular access unit. The access unit
that is associated with the buffering period SEI message that initialises the CPB is referred to as access unit 0. The value
of n is incremented by 1 for each subsequent access unit in decoding order.
The time at which the first bit of access unit n begins to enter the CPB is referred to as the initial arrival time t ( n ).
ai
The initial arrival time of access units is derived as follows:
– If the access unit is access unit 0, t ( 0 ) = 0,
ai
– Otherwise (the access unit is access unit n with n > 0), the following applies:
– If cbr_flag[ SchedSelIdx ] is equal to 1, the initial arrival time for access unit n, is equal to the final arrival time
(which is derived below) of access unit n − 1, i.e.,
t ( n ) = t ( n − 1 ) (C-2)
ai af
– Otherwise (cbr_flag[ SchedSelIdx ] is equal to 0), the initial arrival time for access unit n is derived by
t ( n ) = Max( t ( n − 1 ), t ( n ) ) (C-3)
ai af ai,earliest
where t ( n ) is derived as follows:
ai,earliest
– If access unit n is not the first access unit of a subsequent buffering period, t ( n ) is derived as
ai,earliest
t ( n ) = t ( n ) − ( initial_cpb_removal_delay[ SchedSelIdx ] +
ai,earliest r,n
initial_cpb_removal_delay_offset[ SchedSelIdx ] )  90000 (C-4)
with t ( n ) being the nominal removal time of access unit n from the CPB as specified in subclause C.1.2
r,n
and initial_cpb_removal_delay[ SchedSelIdx ] and initial_cpb_removal_delay_offset[ SchedSelIdx ]
being specified in the previous buffering period SEI message.
– Otherwise (access unit n is the first access unit of a subsequent buffering period), t ( n ) is derived as
ai,earliest
t ( n ) = t ( n ) − ( initial_cpb_removal_delay[ SchedSelIdx ]  90000 ) (C-5)
ai,earliest r,n
12 © ISO/IEC 2012 – All rights reserved

ISO/IEC 14496-10:2012/DAM 2
with initial_cpb_removal_delay[ SchedSelIdx ] being specified in the buffering period SEI message
associated with access unit n.
The final arrival time for access unit n is derived by
t ( n ) = t ( n ) + b( n )  BitRate[ SchedSelIdx ] (C-6)
af ai
where b( n ) is the size in bits of access unit n, counting the bits of the VCL NAL units and the filler data NAL units for
the Type I conformance point or all bits of the Type II bitstream for the Type II conformance point, where the Type I and
Type II conformance points are as shown in Figure C-1.
The values of SchedSelIdx, BitRate[ SchedSelIdx ], and CpbSize[ SchedSelIdx ] are constrained as follows:
– If the content of the active sequence parameter sets for access unit n and access unit n − 1 differ, the HSS selects a
value SchedSelIdx1 of SchedSelIdx from among the values of SchedSelIdx provided in the active sequence
parameter set for access unit n that results in a BitRate[ SchedSelIdx1 ] or CpbSize[ SchedSelIdx1 ] for access
unit n. The value of BitRate[ SchedSelIdx1 ] or CpbSize[ SchedSelIdx1 ] may differ from the value of
BitRate[ SchedSelIdx0 ] or CpbSize[ SchedSelIdx0 ] for the value SchedSelIdx0 of SchedSelIdx that was in use for
access unit n − 1.
– Otherwise, the HSS continues to operate with the previous values of SchedSelIdx, BitRate[ SchedSelIdx ] and
CpbSize[ SchedSelIdx ].
When the HSS selects values of BitRate[ SchedSelIdx ] or CpbSize[ SchedSelIdx ] that differ from those of the previous
access unit, the following applies:
– the variable BitRate[ SchedSelIdx ] comes into effect at time t ( n )
ai
– the variable CpbSize[ SchedSelIdx ] comes into effect as follows:
– If the new value of CpbSize[ SchedSelIdx ] exceeds the old CPB size, it comes into effect at time t ( n ),
ai
– Otherwise, the new value of CpbSize[ SchedSelIdx ] comes into effect at the time t ( n ).
r
C.1.2 Timing of coded picture removal
When an access unit n is the access unit with n equal to 0 (the access unit that initialises the HRD), the nominal removal
time of the access unit from the CPB is specified by
t ( 0 ) = initial_cpb_removal_delay[ SchedSelIdx ]  90000 (C-7)
r,n
When an access unit n is the first access unit of a buffering period that does not initialise the HRD, the nominal removal
time of the access unit from the CPB is specified by
t ( n ) = t ( n ) + t * cpb_removal_delay( n ) (C-8)
r,n r,n b c
where t ( n ) is the nominal removal time of the first access unit of the previous buffering period and
r,n b
cpb_removal_delay( n ) is the value of cpb_removal_delay specified in the picture timing SEI message associated with
access unit n.
The nominal removal time t (n) of an access unit n that is not the first access unit of a buffering period is given by
r,n
t ( n ) = t ( n ) + t * cpb_removal_delay( n ) (C-9)
r,n r,n b c
where t ( n ) is the nominal removal time of the first access unit of the current buffering period and
r,n b
cpb_removal_delay( n ) is the value of cpb_removal_delay specified in the picture timing SEI message associated with
access unit n.
The removal time of access unit n is specified as follows:
– If low_delay_hrd_flag is equal to 0 or t ( n ) >= t ( n ), the removal time of access unit n is specified by
r,n af
© ISO/IEC 2012 – All rights reserved 13

ISO/IEC 14496-10:2012/DAM 2
t ( n ) = t ( n ) (C-10)
r r,n
– Otherwise (low_delay_hrd_flag is equal to 1 and t ( n ) < t ( n )), the removal time of access unit n is specified by
r,n af
t ( n ) = t ( n ) + t * Ceil( ( t ( n ) − t ( n ) ) t )  (C-11)
r r,n c af r,n c
NOTE – The latter case indicates that the size of access unit n, b( n ), is so large that it prevents removal at the
nominal removal time.
When an access unit n is the first access unit of a buffering period, n is set equal to n at the removal time t ( n ) of the
b r
access unit n.
C.2 Operation of the decoded picture buffer (DPB)
The decoded picture buffer contains frame buffers. When a coded video sequence conforming to one or more of the
profiles specified in Annex A is decoded by applying the decoding process specified in clauses 2-9, each of the frame
buffers may contain a decoded frame, a decoded complementary field pair or a single (non-paired) decoded field that is
marked as "used for reference" (reference pictures) or is held for future output (reordered or delayed pictures). When a
coded video sequence conforming to one or more of the profiles specified in Annex G is decoded by applying the
decoding process specified in Annex G, each frame buffer may contain a decoded frame, a decoded complementary field
pair, a single (non-paired) decoded field, a decoded reference base frame, a decoded reference base complementary field
pair or a single (non-paired) decoded reference base field that is marked as "used for reference" (reference pictures) or is
held for future output (reordered or delayed pictures). When a coded video sequence conforming to one or more of the
profiles specified in Annex H is decoded by applying the decoding process specified in Annex H, each of the frame
buffers may contain a decoded frame view component, a decoded complementary field view component pair, or a single
(non-paired) decoded field view component that is marked as "used for reference" (reference pictures) or is held for
future output (reordered or delayed pictures) or is held as reference for inter-view prediction (inter-view only reference
components). When a coded video sequence conforming to one or more of the profiles specified in Annex I is decoded
by applying the decoding process specified in Annex I, each of the frame buffers may contain a decoded texture frame
view component, a decoded depth frame view component, a decoded complementary texture field view component pair,
or a single (non-paired) decoded texture field view component that is marked as "used for reference" (reference pictures)
or is held for future output (reordered or delayed pictures) or is held as reference for inter-view prediction (inter-view
only reference components).
Prior to initialisation, the DPB is empty (the DPB fullness is set to zero). The following steps specified in this subclause
all happen instantaneously at t ( n ) and in the order listed. When the decoding process specified in Annex H or Annex I
r
is applied, the view components of the current primary coded picture are processed by applying the ordered steps to each
view component in increasing order of the associated view order index VOIdx. During the invocation of the process for a
particular texture view, only the texture view components of the particular view are considered and during the invocation
of the process for a particular depth view, only the depth view components of the particular view are considered. Prior to
initialisation, the DPB is empty (the DPB fullness is set to zero). Inside each view component of the current primary
coded picture, depth view component if present, is processed after the texture view component within the same view
component.
...
