INTERNATIONAL STANDARD ISO 6182-7:2020(E)
Fire protection — Automatic sprinkler systems —
Part 7:
Requirements and test methods for early suppression fast
response (ESFR) sprinklers
1 Scope
This document specifies performance requirements, test methods and marking requirements for
pendent early suppression fast response (ESFR) sprinklers.
NOTE This document currently provides requirements for K202 and K242 ESFR pendent sprinklers.
2 Normative reference
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 7-1, Pipe threads where pressure-tight joints are made on the threads — Part 1: Dimensions, tolerances
and designation
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at http:// www .electropedia .org/
3.1 General
3.1.1
actual delivered density
ADD
rate at which water is deposited from an operating sprinkler onto the top horizontal surface of a
simulated burning combustible array
3.1.2
assembly load
force exerted on the sprinkler body excluding hydrostatic pressure
3.1.3
average design strength
glass bulb supplier’s specified and assured lowest average axial design strength of any batch of 50 bulbs
3.1.4
design load
force exerted on the release element at the service load (3.1.10) of the sprinkler
© ISO 2020 – All rights reserved 1

---------------------- Page: 8 ----------------------
ISO 6182-7:2020(E)

3.1.5
early suppression fast response automatic sprinkler
ESFR
sprinkler that is intended to provide early suppression of a fire when installed on the appropriate
sprinkler piping
3.1.6
orientation A
orientation with the airflow perpendicular to both the waterway axis and the plane of the frame arms
and with the heat responsive element upstream of the frame arms
Note 1 to entry: See Figure 1.
3.1.7
orientation B
orientation with the airflow perpendicular to both the waterway axis and the plane of the frame arms
and with the heat responsive element downstream of the frame arms
Note 1 to entry: See Figure 1.
a) Orientation A
b) Orientation B
Key
1 tunnel test section (elevation view)
a
Airflow.
Figure 1 — Orientations A and B
3.1.8
protective covers
protective caps or straps intended to provide temporary protection for sprinklers during shipping,
handling and installation
3.1.9
response time index
RTI
measure of sprinkler sensitivity
RTIt= u
2 © ISO 2020 – All rights reserved

---------------------- Page: 9 ----------------------
ISO 6182-7:2020(E)

where
t is equal to the time constant, expressed in seconds, of the heat-responsive element;
u is the gas velocity, expressed in metres per second.
0,5
Note 1 to entry: The RTI is expressed in units of (m·s) .
3.1.10
service load
combined force exerted on the sprinkler body by the assembly load (3.1.2) of the sprinkler and the
equivalent force of the rated pressure on the inlet
3.1.11
sprinkler
thermosensitive device designed to react at a predetermined temperature by automatically releasing a
stream of water and distributing it in a specified pattern and quantity over a designated area
Note 1 to entry: For the purposes of this document, "sprinkler" is intended to refer to ESFR (3.1.5) sprinklers.
3.2 Types of sprinklers according to type of heat responsive element
3.2.1
fusible element sprinkler
sprinkler that opens under the influence of heat by the melting of a component
3.2.2
glass bulb sprinkler
sprinkler that opens under the influence of heat by the bursting of the glass bulb through pressure
resulting from expansion of the fluid enclosed therein
3.3 Sprinklers classified according to position
3.3.1
pendent sprinkler
sprinkler arranged in such a way that the water stream is directed
...
