IEC 62016:2003

INTERNATIONAL IEC
STANDARD
First edition
2003-12
Core model of the electronics domain
Reference number
Publication numbering
As from 1 January 1997 all IEC publications are issued with a designation in the
60000 series. For example, IEC 34-1 is now referred to as IEC 60034-1.
Consolidated editions
The IEC is now publishing consolidated versions of its publications. For example,
edition numbers 1.0, 1.1 and 1.2 refer, respectively, to the base publication, the
base publication incorporating amendment 1 and the base publication incorporating
amendments 1 and 2.
Further information on IEC publications
The technical content of IEC publications is kept under constant review by the IEC,
thus ensuring that the content reflects current technology. Information relating to
this publication, including its validity, is available in the IEC Catalogue of
publications (see below) in addition to new editions, amendments and corrigenda.
Information on the subjects under consideration and work in progress undertaken
by the technical committee which has prepared this publication, as well as the list
of publications issued, is also available from the following:
• IEC Web Site (www.iec.ch)
• Catalogue of IEC publications
The on-line catalogue on the IEC web site (http://www.iec.ch/searchpub/cur_fut.htm)
enables you to search by a variety of criteria including text searches, technical
committees and date of publication. On-line information is also available on
recently issued publications, withdrawn and replaced publications, as well as
corrigenda.
• IEC Just Published
This summary of recently issued publications (http://www.iec.ch/online_news/
justpub/jp_entry.htm) is also available by email. Please contact the Customer
Service Centre (see below) for further information.
• Customer Service Centre
If you have any questions regarding this publication or need further assistance,
please contact the Customer Service Centre:
Email: custserv@iec.ch
Tel: +41 22 919 02 11
Fax: +41 22 919 03 00
INTERNATIONAL IEC
STANDARD 62016
First edition
2003-12
Core model of the electronics domain

© IEC 2003 – Copyright - all rights reserved
No part of this publication may be reproduced or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without permission in writing from the publisher.
International Electrotechnical Commission, 3, rue de Varembé, PO Box 131, CH-1211 Geneva 20, Switzerland
Telephone: +41 22 919 02 11 Telefax: +41 22 919 03 00 E-mail: inmail@iec.ch Web: www.iec.ch
PRICE CODE
Commission Electrotechnique Internationale
XH
International Electrotechnical Commission
Международная Электротехническая Комиссия
For price, see current catalogue

– 2 – 62016  IEC:2003(E)
CONTENTS
FOREWORD.5
INTRODUCTION.7

1 Scope and object.8
2 Reference documents.9
3 General modelling issues .9
3.1 Ownership and reference.9
3.2 Uniqueness by value .12
3.3 Default values.12
3.4 Optional versus empty sets .12
3.5 Model topology.12
4 Concepts.13
4.1 The information base.13
4.2 Global ports and global port bundles .13
4.3 Libraries.13
4.4 Cells.14
4.5 Clusters and cell representation sets.14
4.6 Cell representations.14
4.7 Master ports and master port bundles .14
4.8 Instances.15
4.9 Instance ports and instance port bundles .15
5 Connectivity.16
5.1 Logical connectivity.16
5.2 Structural connectivity with wide instances .17
5.3 Structural connectivity of connectivity views .19
6 The design hierarchy mechanism .21
6.1 The design hierarchy.21
6.2 Annotations.23
7 Core Model for electronic design .24
7.1 Libraries.24
7.2 Interfacing to cells.25
7.3 Cell definition hierarchies.27
7.4 Instantiation.27
7.5 Logical connectivity.28
7.6 Structural connectivity.28
7.7 Global connectivity.32
7.8 Design and configuration.33
7.9 Annotation.34
8 Core Model EXPRESS-G.34
8.1 Partial EXPRESS-G of cell .35
8.2 Partial EXPRESS-G of cell_representation .36
8.3 Partial EXPRESS-G of cluster .37
8.4 Partial EXPRESS-G of cluster_configuration .38
8.5 Partial EXPRESS-G of cluster_interface.39
8.6 Partial EXPRESS-G of connectivity_generic_bus .40

62016  IEC:2003(E) – 3 –
8.7 Partial EXPRESS-G of connectivity_generic_net .41
8.8 Partial EXPRESS-G of design .42
8.9 Partial EXPRESS-G of global_port .43
8.10 Partial EXPRESS-G of information_base.44
8.11 Partial EXPRESS-G of instance.45
8.12 Partial EXPRESS-G of instance_configuration.46
8.13 Partial EXPRESS-G of library.47
8.14 Partial EXPRESS-G of master_port_annotate.48
8.15 Partial EXPRESS-G of name_information.49
8.16 Partial EXPRESS-G of occurrence_annotate .50
8.17 Partial EXPRESS-G of occurrence_annotate .51
8.18 Partial EXPRESS-G of occurrence_annotate .52
8.19 Partial EXPRESS-G of occurrence_hierarchy_annotate.53
8.20 Partial EXPRESS-G of port_structure .54
8.21 Partial EXPRESS-G of property.55
8.22 Partial EXPRESS-G of property_override .56
8.23 Partial EXPRESS-G of signal .57
9 Core Model schemas.58
9.1 connectivity_structure_model.58
9.2 connectivity_view_model.59
9.3 design_hierarchy_model.60
9.4 design_management_model.62
9.5 documentation_model.63
9.6 hierarchy_model.64
9.7 information_base_model.67
9.8 library_model .68
9.9 logical_connectivity_model.69
9.10 support_definition_model.70
10 Core Model information model .72
10.1 connectivity_structure_model.72
10.2 design_hierarchy_model.89
10.3 documentation_model.114
10.4 hierarchy_model.116
10.5 information_base_model.157
10.6 support_definition_model.166
11 Index .188

Figure 1 – The owner relationship.10
Figure 2 – Owner relationship with multiple potential owners .11
Figure 3 – The reference mechanism .11
Figure 4 – Uniqueness by value .12
Figure 5 – An example of signal hierarchy .17
Figure 6 – A net joins a port on an instance in the commoned style .18
Figure 7 – A bus joins a port bundle on an instance in the commoned style .18
Figure 8 – A bus joins a port bundle on an instance in the fanned-out style .19
Figure 9 – Internal and external libraries.25
Figure 10 – Port bundling – 1.26

– 4 – 62016  IEC:2003(E)
Figure 11 – Port bundling – 2.26
Figure 12 – Instantiation .27
Figure 13 – Connectivity net .28
Figure 14 – Connectivity bus.29
Figure 15 – Connectivity bus – Commoning .29
Figure 16 – Connectivity bus – Logical equivalent of commoning .30
Figure 17 – Connectivity bus – Fanning-out .30
Figure 18 – Connectivity bus – Logical equivalent of fanning-out .31
Figure 19 – Connectivity bus-slice .31
Figure 20 – Connectivity ripper .32
Figure 21 – Global port scoping .33

62016  IEC:2003(E) – 5 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
___________
CORE MODEL OF THE ELECTRONICS DOMAIN

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with an IEC Publication.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 62016 has been prepared by IEC technical committee 93: Design
automation.
The document was released by the feeder organization, Government Electronics and
Information Technology Association, a sector of the Electronic Industries Alliance (EIA), for
committee draft, comment, and review by members of IEC TC93 .
The text of this standard is based on the following documents:
FDIS Report on voting
93/172/FDIS 93/176/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
___________
The EIA feeder organization retains the copyright and intellectual property of this work but provides permission
for IEC to reproduce and exploit the information contained herein.

– 6 – 62016  IEC:2003(E)
This standard does not follow the rules for the structure of International Standards given in
the ISO/IEC Directives, Part 2.
The committee has decided that the contents of this publication will remain unchanged until
2012-07. At this date, the publication will be
• reconfirmed;
• withdrawn;
• replaced by a revised edition, or
• amended.
62016  IEC:2003(E) – 7 –
INTRODUCTION
The Core Model of the electronics domain provides a common basis for design information
handled by CAD systems within the electronic domain. It is the purpose of this model to
provide a conceptual representation of the electronics domain, so that the compliant CAD
systems handle a similar set of concepts, thus making inter-communication, sharing and
exchange of design information a much easier task. It is not the purpose of this model to
describe implementation details or to provide a data representation of electronics domain
information.
The Core Model of the electronics domain, Edition 1.0, is referred to as the “Core Model”
throughout this document. The Core Model, in part, has been created by enhancing the
industry connectivity consensus model, EDIF CFI DR Alignment Model Version 1.0
(www.edif.org).
The chosen description language for this Core Model is EXPRESS, as defined by ISO 10303-11.
It is necessary to describe the Core Model as an information model in order to provide a
formal definition of the design information that shall be be recognized by the compliant CAD
systems. The benefits of a formal description derive from its ability to provide an
unambiguous representation of concepts, attributes and relationships, and the global rules
and constraints that may be applied. By having such a description, it is possible to check the
consistency and the correctness of the model as well as to provide a reliable starting-point for
further development. It also facilitates the design of correct electronics CAD implementations
based on this Core Model, as the actual implementation methods can be checked against
the model.
This Core Model includes connectivity, hierarchy and design information for the electronics
domain. Future parts of this Core Model standard may be extended to include other
categories of information (for example, cell_representation, schematic representation, the
PCB domain, symbols and display information).
In order to facilitate the creation of other parts of this Core Model standard, some objects
have been used in this Core Model to facilitate support for other parts of the electronics
domain. There are two types of such objects.
• Entities, such as cell_representation, are important concepts that provide support for
defining other Core Model parts.
• Constraints: Some of constraints of this Core Model use conditions that are always true.
They have been written in this way in order to ensure that they remain valid when the
model is extended.
– 8 – 62016  IEC:2003(E)
CORE MODEL OF THE ELECTRONICS DOMAIN

1 Scope and object
This International Standard provides the semantics definitions for the following categories of
information related to electronic circuit designs. Each category of design information is
modelled as an EXPRESS schema.
The Core Model consists of 10 schemas. Each of them is presented in this document as a
separate chapter. At the beginning of each chapter, a description of the corresponding
schema is provided.
• The hierarchy_model schema describes the hierarchical information of a cell, i.e. the way
a cell may be divided into other cells.
A circuit may be divided into cells which, in turn, may be further subdivided into other
cells, thus creating a hierarchy. The hierarchy information describes the cells, the possible
cell representations and their instances.
• The design_hierarchy_model schema describes the annotation on an occurrence
hierarchy.
The definition of a design requires that specific representations (views) of design objects
in the hierarchy are selected. This unambiguously creates a configured design hierarchy.
This concept is similar to the configuration of a design in VHDL and is related to view
selection mechanisms of other electronics design domain information models in industry.
The design hierarchy identifies top-level design cells and may provide annotated design-
specific data into the elaborated hierarchy.
• The connectivity_view_model schema describes the connectivity information of a cell.
This describes the way in which the circuits are connected in order that information or
energy may flow from one part of a design or product to another. The Core Model
subdivides this information into
• the logical_connectivity_model schema which describes the connectivity for a given
level of a hierarchy.
Logical connectivity information describes the bit level, abstract electrical connectivity
for a given level of a hierarchy, in terms of signals and signal groups.
• the connectivity_structure_model schema which describes the structural connectivity
of a connectivity view.
Structural connectivity information describes the connectivity, for a given level of a
hierarchy, from the structural point of view. The structural connectivity is specified in
terms of busses, nets and rippers. Such a structural representation is used to provide
support for physical implementation and annotation.
• The library_model schema describes the technology information contained in a library, as
well as the reusable objects and data.
A library provides a means of grouping cell definitions. A library may be used to group
other classes of reusable objects and information as well. Information in a library may be
related in terms of technology information.
• The information_base_model schema describes the information in an information base.
The information_base describes the kind of information that can be found directly in an
information base.
62016  IEC:2003(E) – 9 –
In addition, the following information is also included in the model.
• The design_management_model schema provides the design management information.
This information is needed to trace back to the source or the owner of the data.
• The documentation_model schema describes the documentation provided for an object.
• The support_definition_model schema contains the definition of some auxiliary entities,
types and functions that are used by several schemas.
Names of objects used in this Core Model standard were chosen to be the same as the names
of the similar objects and concepts in existing electronics domain information models
wherever possible.
2 Reference documents
IEC 61690-1:2000, Electronic design interchange format (EDIF) – Part 1: Version 300
IEC 61690-2:2000, Electronic design interchange format (EDIF) – Part 2: Version 400
ISO 13030-11:1994, Industrial automation systems and integration – Product representation
and exchange – Part 11: Description methods: The EXPRESS-I language reference manual
3 General modelling issues
This standard describes the general modelling techniques and conventions used by the Core
Model. The most important concept discussed here is that of relationship between entities
(ownership and reference). In addition, issues such as uniqueness in aggregates, default
values, empty sets and model topology are presented.
3.1 Ownership and reference
An object is said to be the “owner” of another object, if the latter can only exist in the context
of the former. From the point of view of the information model, this means that an instance of
the “owned” object can exist if, and only if, there is an instance of the owner object. Any given
instance of an object must have exactly one owner. Some examples of owner relationships
are provided below.
By contrast, if an object references another object, the existence of the latter is not dependent
on the existence of the former. In the information model this means that the existence of an
instance of the referenced object is not related to the existence of any instance of the object
that references it. A given instance may be referenced by any number of other instances
unless stated otherwise by a constraint.
Generally speaking, the referencing mechanism provides a way of sharing data whereas the
ownership dependence is used to create a scope for the objects and to control their
existence.
The difference between the two types of relationship is important because of their effects in
an actual implementation. If the implementation provides a static representation of data (such
as an EDIF file), an owned object can be textually contained in the definition of the owner,
whereas a referenced object is used by the referencing object but may be declared in another
context. If the system allows dynamic representation of the data (like CFI DR PI), the
difference between ownership and reference is reflected in the process of object creation and
destruction. Indeed, whenever an object is destroyed, its owned objects are destroyed too,
unlike the referenced objects which continue to exist.

– 10 – 62016  IEC:2003(E)
The EXPRESS language does not provide a direct method of specifying whether an object is
owned or referenced. However, the Alignment Model represents the two types of relationship
in different ways by using the techniques and conventions described below.
3.1.1 Ownership
Let us consider the example presented in Figure 1 which shows the owner relationship
between a library and its contained cells:

ENTITY library
cells : OPTIONAL SET [1:?] OF cell;
...
END_ENTITY;
ENTITY cell
...
INVERSE
containing_library : library FOR cells;
END_ENTITY;
Figure 1 – The owner relationship
In this example, ownership is modelled straightforwardly by using the EXPRESS INVERSE
clause. Its meaning is that, for every instance of a cell, there is exactly one instance of the
library that contains that cell instance.
There are cases, however, when an object may have several potential owners. The example
in Figure 2 shows that a documentation object may be created in the context of a
connectivity_generic_net or a connectivity_generic_bus, etc.
The owner relationship is modelled by using the INVERSE clause. Its meaning is that there
may exist, at most, one instance of the connectivity_generic_net and, at most, one instance of
a connectivity_generic_bus, etc, that contain a given documentation instance. However,
any instance of the documentation may exist as a member of the “document” SET
in a connectivity_generic_net or as a member of the “document” SET in a
connectivity_generic_bus, etc, but not as all of them. Therefore, a domain rule (the
WHERE clause) is used in order to ensure that there is only one owner of the
documentation instance in the database. Of course, there are other objects that reference
that documentation instance.
62016  IEC:2003(E) – 11 –
ENTITY connectivity_generic_net
ABSTRACT SUPERTYPE OF (ONEOF(connectivity_net,
connectivity_sub_net));
...
document : OPTIONAL SET [1:?] OF documentation;
...
END_ENTITY;
ENTITY connectivity_generic_bus
ABSTRACT SUPERTYPE OF (ONEOF(connectivity_bus,
connectivity_bus_slice,
connectivity_sub_bus));
...
document : OPTIONAL SET [1:?] OF documentation;
...
END_ENTITY;
ENTITY documentation;
...
INVERSE
containing_generic_net:
SET [0:1] OF connectivity_generic_net FOR document;
containing_generic_bus:
SET [0:1] OF connectivity_generic_bus FOR document;
...
WHERE
containment_constraint:
(* Each "documentation" is defined in only one place. *)
SIZEOF(containing_generic_net) +
SIZEOF(containing_generic_bus) +
...
END_ENTITY;
Figure 2 – Owner relationship with multiple potential owners

3.1.2 Reference
The reference mechanism can be used to share common data between several objects. Let
us consider a master_logical_port which has a default connection to a global_port. Since it is
possible for several master_logical_ports to have the same default connection, the
global_port is referenced by the master_logical_port. In this case, the global_port does not
contain an INVERSE attribute for the master_logical_port because it is not owned by it. In
order to increase the readability of the model, the references to other objects are tagged as
such. Figure 3 gives an example of object referencing.

ENTITY master_logical_port;
default_connection : OPTIONAL global_port; -- reference
...
END_ENTITY;
Figure 3 – The reference mechanism

– 12 – 62016  IEC:2003(E)
3.2 Uniqueness by value
EXPRESS defines the uniqueness in aggregates to be “by reference”. This means that a set
cannot contain the same object twice but it may contain two different objects with exactly the
same value. Therefore, a special EXPRESS function is used whenever uniqueness by value is
required, as shown in Figure 4.

ENTITY library
document      : OPTIONAL SET [1:?] OF documentation;
status_of_copyright : OPTIONAL SET [1:?] OF copyright;
status_of_written  : OPTIONAL SET [1:?] OF written;
...
WHERE
unique_status_of_copyright:
value_unique(status_of_copyright);
unique_status_of_written:
value_unique(status_of_written);
unique_document:
value_unique(document);
END_ENTITY;
Figure 4 – Uniqueness by value
The example shows that a library should not contain two identical documentation, copyright
information or author information, i.e. it cannot contain two instances of documentation,
copyright or written with the same value.
3.3 Default values
The default values, which are used by the CAD systems, are relevant to the actual
implementations rather than to the information models. Therefore, the Core Model does not
contain a specification of these values.
3.4 Optional versus empty sets
In EXPRESS, a set which may have no elements can be described by either
• OPTIONAL SET [1:upper_limit] OF base_type, or by
• SET [0:upper_limit] OF base_type.
However, the concepts modelled by the two descriptions are quite different. An OPTIONAL
SET shows the fact that the set may or may not exist whereas a SET[0 : upper_limit]
shows that the set always exists but it may be empty. The Core Model uses the former
method.
3.5 Model topology
The topology is the graph representation of the relationships between the concepts defined in
the model. Two possible approaches have been considered.
• A tree representation in which there is a concept (the root of the tree) that is a
generalization of all the other concepts defined in the model. An example of Information
Model that uses this topology is the CFI DR IM.
• A forest representation in which there are several categories of concepts that do not have
any common features. An example of Information Model that uses this topology is the
EDIF IM.
62016  IEC:2003(E) – 13 –
The forest representation has been chosen for the Core Model. An advantage of this
representation (as opposed to the tree representation) is that it reduces the maximum depth
of the leaves in the model hierarchy.
4 Concepts
This chapter describes the fundamental concepts defined by the Core Model. These concepts
may be thought of as creating a hierarchy which is abstract at its higher level and becomes
progressively more detailed. At the highest level of the structure, an information_base may
contain designs and libraries. Each library is a collection of cells which are grouped according
to a set of common characteristics. A cell is the main design object which may be instantiated
later in another cell, thus creating a design hierarchy. A cell may be connected to other cells
by means of its interface. These concepts are described in the following sections.
4.1 The information base
An information_base describes the data that can be found in the database of a compliant CAD
system. This information may include libraries, designs, global_ports and global_port_bundles
and unit definitions. The Core Model is an information model that describes one information
base. All the entities defined in the Core Model belong, directly or indirectly, to the
information_base object. The model of the information_base entity can be found in the
information_base_model schema. A partial EXPRESS-G diagram is also available.
4.2 Global ports and global port bundles
Certain ports such as GND, VCC or clocks are used in common by several modules of an
electronic circuit. The Core Model describes this by using the concept of global port, which is
modelled by the global_port entity. The global_ports are defined in the information_base and
are, therefore, visible in all the cells and designs defined in this information base.
It is sometimes convenient to address several ports as if they were a single port. In order to
do this the Core Model uses the concept of port bundle. A port bundle provides a means of
creating a structured port by grouping other ports and/or port bundles defined in the same
context. In the case of global_ports, the port bundle is modelled by the global_port_bundle
entity.
Both the global_port and the global_port_bundle are described in the information_base_model
schema. A partial EXPRESS-G diagram is also available.
4.3 Libraries
A library provides a means of grouping design units (cell definitions). In future versions of the
Core Model a library will contain other classes of reusable objects, as well.
A library may be locally defined, in which case the definition of the contained cells is included
in the information base. Libraries may also be externally defined, which implies that the
details of the cell definitions are not available within the information base.
The library_model schema describes the model for the library entity. A partial EXPRESS-G
diagram is also available. According to where the contained data can be found, the library
entity is subtyped into internal_library and external_library. The internal_library corresponds
to the case where the library is locally defined. Therefore, since all the data is present in the
information_base, an internal_library may contain implementation information. An
external_library corresponds to the case where the library data is not contained in the
information_base and, therefore, it does not include implementation details.

– 14 – 62016  IEC:2003(E)
4.4 Cells
A cell is the basic design unit described by the Core Model. In order to be able to represent
complex circuits, a cell can be divided into other cells, thus creating a hierarchy. The model of
the cell entity is given in the hierarchy_model schema. A partial EXPRESS-G cell entity is
subtyped into internal_cell and external_cell according to whether it describes information
defined locally or not. An internal_cell contains locally defined data and may, therefore,
contain implementation information. An external_cell does not include implementation details.
Since an internal_cell contains data defined in the current information_base, it can only
belong to an internal_library. Similarly, an external_cell belongs to an external_library.
4.5 Clusters and cell representation sets
A cell is described by means of cell_representations. Cell_representations that share the
same interface can be grouped into clusters. A cell can contain more than one cluster.
A cluster may be instantiated in another cell view, thus creating a design hierarchy. A cluster
is subtyped into internal_cluster and external_cluster which are used by internal_cell and
external_cell respectively. An internal_cluster may only contain internal_cell_representations,
and an external_cluster only external_cell_representations. The model of the cluster entity is
given in the hierarchy_model schema. A partial EXPRESS-G diagram is also available.
Cell representation sets are used to group cell_representations of the same cell that have a
close relationship based on reasons other than a common interface. Simple annotation is
provided within the cell representation set in order to specify the reason for the grouping. The
model for the cell_representation_set entity can be found in the hierarchy_model schema.
4.6 Cell representations
A cell_representation describes chosen aspects of a cell. At present, the Core Model supports
only one type of cell_representation, the connectivity view. Future versions of the model will
be extended, however, with other view types such as schematic and pcblayout, as well as
with symbols. A cell_representation may be either an internal_cell_representation or an
external_cell_representation. An internal_cell_representation belongs to an internal_cluster
and describes an internal_cell. Similarly, an external_cell_representation belongs to an
external_cluster and describes an external_cell. An internal_cell_representation can establish
a direct relationship with other cell_representations in order to provide versioning and data
management control information. Hence, an internal_cell_representation may be a new
version of another cell_representation of the same type or may be derived from another
cell_representation. If the internal_cell_representation is derived from another
cell_representation, their type can be different. The interface of a cell_representation is
obtained from its containing cluster.
The model of the cell_representation entity can be found in the hierarchy_model schema.
A partial EXPRESS-G internal_connectivity_view and external_connectivity_view are given in
the connectivity_view_model schema.
4.7 Master ports and master port bundles
The interface of a cluster consists of ports and port bundles. These objects represent the only
places where a connection can be made to a cell. The interface of a cluster is described by
the cluster_interface entity.
In the Core Model, each port in the cluster interface is described by a master_logical_port
entity which describes its logical connectivity information. A master_logical_port can be
associated with one or several master_structure_ports which describe the structural
connectivity information of the port. It is possible that a master_logical_port is not associated
with any master_structure_port.

62016  IEC:2003(E) – 15 –
The size of the master_logical_port and master_structure_port is always one. The master_
logical_port entity is subtyped into input_master_logical_port, output_master_logical_port,
bidirectional_master_logical_port and unspecified_direction_master_logical_port, which
correspond to the possible directions of the port. In addition, a port contains information such
as its designator, its properties and its external load capacitance. It is possible to specify a
global_port as the default connection for a master_logical_port.
It is sometimes convenient to address several ports as if they were a single port. In order to
be able to do this, a grouping method is provided. The Core Model uses the concept of port
bundle in order to describe a structured port. A port bundle in the cluster interface
is described by a master_logical_port_bundle entity, which groups master_logical_ports
and/or other master_logical_port_bundles defined in the same interface. The same
master_logical_port may be referenced by more than one master_logical_port_bundle.
However, it cannot be referenced more than once by the same master_logical_port_bundle,
either directly or indirectly.
The availability of a master_logical_port_bundle for structural connectivity is indicated by the
master_structure_port_bundle entity. A master_logical_port_bundle can be associated with
more than one master_structure_port_bundle.
A structured port can be defined in the interface of a cluster by using the port_structure entity.
A port_structure describes a possible structuring of the structure ports and port bundles of a
cluster interface. It can represent either an ordered or an unordered structured port.
The models for the master_logical_port, master_structure_port, master_logical_port_bundle,
master_structure_port_bundle and port_structure entities are given in the hierarchy_model
schema. Partial EXPRESS-G diagrams for cluster_interface and port_structure are also
available.
4.8 Instances
A cluster may be instantiated in a cell view, thus enabling the creation of a design hierarchy.
The instance entity models the instance of a cluster. The interface of the instance consists of
instance_structure_ports and instance_structure_port_bundles which must reference
master_structure_ports and master_structure_port_bundles defined in the interface of the
instantiated cluster. If the width of the instance is greater than one, the instance represents
an arrayed instance.
The advantage of the instantiation mechanism is that the choice o
...
