IEC 60335-2-79:1995/AMD1:2000
(Amendment)Amendment 1 - Safety of household and similar electrical appliances - Part 2-79: Particular requirements for high pressure cleaners and steam cleaners, for industrial and commercial use
Amendment 1 - Safety of household and similar electrical appliances - Part 2-79: Particular requirements for high pressure cleaners and steam cleaners, for industrial and commercial use
General Information
Relations
Buy Standard
Standards Content (Sample)
INTERNATIONAL IEC
STANDARD
60335-2-79
AMENDMENT 1
2000-07
Amendment 1
Safety of household and similar
electrical appliances –
Part 2-79:
Particular requirements for high pressure
cleaners and steam cleaners, for industrial
and commercial use
Amendement 1
Sécurité des appareils électrodomestiques et analogues –
Partie 2-79:
Règles particulières pour les appareils de nettoyage
à haute pression et les appareils de nettoyage à vapeur,
à usage industriel et commercial
IEC 2000 Copyright - all rights reserved
International Electrotechnical Commission 3, rue de Varembé Geneva, Switzerland
Telefax: +41 22 919 0300 e-mail: inmail@iec.ch IEC web site http://www.iec.ch
Commission Electrotechnique Internationale
PRICE CODE
D
International Electrotechnical Commission
For price, see current catalogue
– 2 – 60335-2-79 Amend. 1 © IEC:2000(E)
FOREWORD
This amendment has been prepared by subcommittee 61J: Electrical motor-operated cleaning
appliances for industrial use, of IEC technical committee 61: Safety of household and similar
electrical appliances.
The text of this amendment is based on the following documents:
FDIS Report on voting
61J/112/FDIS 61J/117/RVD
Full information on the voting for the approval of this amendment can be found in the report
on voting indicated in the above table.
A bilingual version of this amendment may be issued at a later date.
___________
Page 9
2 Definitions
Add, on page 11, the following definition:
2.115
water jetter
high-pressure pipe-cleaning device, consisting of a nozzle at the end of a high-pressure hose
Page 17
7.12.1 Addition:
Insert, on page 19, the following new text at the end of the subclause:
Instructions for use for water jetters (if applicable) shall be given, such as "Insert hose to red
mark before turning on the appliance".
60335-2-79 Amend. © IEC:2000(E) – 3 –
Page 19
Insert the following text:
8.1.4 Add after the last paragraph:
Isolated battery systems of 18 to 24 cells of either acid or alkaline electrochemistry, including
gel batteries, shall be regarded as Class III provided that
– the maximum voltage per cell on charge does not exceed 2,7 V;
– there are no earthed parts (see clause 27);
– conductive parts cannot fall on to and thereby bridge live parts
...
