ELECTRICAL RELAYS –
TESTS AND MEASUREMENTS –
Part 38: Mechanical interlock
1 Scope
This part of IEC 63522 is used for testing all kinds of electrical relays and for evaluating their
ability to perform under expected conditions of transportation, storage and all aspects of
operational use.
NOTE 1 Examples for electrical relays in the sense of this document include electromechanical relays, reed relays,
reed contacts, reed switches, solid state relays, time relays and technology combinations of these.
This document defines a standard test method for mechanical interlock.
This test is applicable to the elementary relays which have the mechanical interlocking
mechanism.
NOTE 2 The electrical interlocking is not applicable to this test.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies.
For undated references, the latest edition of the referenced document (including any
amendments) applies.
IEC 63522-0:–, Electrical relays – Tests and measurements – Part 0: General and guidance
3 Terms and definitions
For the purposes of this document, the terms and definitions given in IEC 63255-0 and the
following apply.
ISO and IEC maintain terminology databases for use in standardization at the following
addresses:
• IEC Electropedia: available at https://www.electropedia.org/
• ISO Online browsing platform: available at https://www.iso.org/obp
3.1
opposing contact
other normally open contact of specific normally closed contact and vice versa
3.2
mechanical interlock
interlock which mechanically prevents the operation of the device under test (DUT) if certain
conditions are not met
