INTRODUCTION to Amendment 1
This document provides additional information to IEC TR 62977-1-31:2021 regarding the
influence of spectral stray light and spectral bandwidth of a spectroradiometer on chromaticity
measurements. It is described in Annex E.
This document also provides the corrections of editorial errors of IEC TR 62977-1-31:2021. The
corrections are:
– Typos are fixed:
• “fiber” and “x(λ), y(λ), z(λ)” is replaced with “fibre” and “𝑥𝑥(𝜆𝜆),𝑦𝑦(𝜆𝜆),𝑧𝑧(𝜆𝜆)”, respectively in
Figure 2,
• “(%)” in the label of vertical axis is removed in Figure 9, Figure 10, and Figure 12,
• “0” label of the tick mark of vertical axis is replaced with “1” in Figure C.4.
– The lists for Formula (A.1) and Formula (B.1) are aligned.

– 4 – IEC TR 62977-1-31:2021/AMD1:2022
© IEC 2022
Figure 2 – Example of configurations for the input optics and detector
Replace, in Figure 2, Figure 2b) and Figure 2c) with the following new Figure 2b) and Figure
2c):
b) Colorimeter c) Spectroradiometer with spectrometer using
grating and array detector
5.5.2.1 General
Replace, in NOTE 2, the fourth sentence with the following new sentence:
Experimental data demonstrating the influence of spectral stray light in a specific application are shown in Annex E
[12].
Add, after NOTE 2, the following new NOTE 3:
NOTE 3 The influence of spectral bandwidth on chromaticity measurements of narrow spectral linewidth light is
shown in Annex E.
© IEC 2022
Figure 9 – Calculated chromaticity differences as a function of wavelength error
Replace Figure 9 with the following new figure:

a) DUT-1 (chromaticity coordinate, x) b) DUT-1 (chromaticity coordinate, y)

c) DUT-2 (chromaticity coordinate, x) d) DUT-2 (chromaticity coordinate, y)

e) DUT-3 (chromaticity coordinate, x) f) DUT-3 (chromaticity coordinate, y)

– 6 – IEC TR 62977-1-31:2021/AMD1:2022
© IEC 2022
Figure 10 – Calculated chromaticity differences as a function of spectral bandwidth
Replace Figure 10 with the following new figure:

a) DUT-1 (chromati
...
