Bayonet lampholders

IEC 61184:2017 This document applies to bayonet lampholders B15d and B22d for connection of lamps and semi-luminaires to a supply voltage of 250 V.
This document also covers lampholders which are integral with a luminaire or intended to be built into appliances. It covers the requirements for the lampholder only.
This fourth edition cancels and replaces the third edition published in 2008 and Amendment 1:2011. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
a) Restructuring of the standard in accordance with IEC Directives Part 2.
b) Clause 18: Update on creepage distances and clearances;
c) Addition of Annex B.

Douilles à baïonnette

L'IEC 61184:2017 Le présent document s'applique aux douilles à baïonnette B15d et B22d destinées à connecter les lampes et les semi-luminaires à une tension d'alimentation de 250 V.
Le présent document couvre également les douilles qui sont intégrées dans un luminaire ou destinées à être incorporées dans des appareils. Il couvre uniquement les exigences applicables à la douille.
Cette quatrième édition annule et remplace la troisième édition parue en 2008 et son Amendement 1:2011. Cette édition constitue une révision technique.
Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a) Restructuration de la norme conformément aux Directives IEC, Partie 2.
b) Article 18: Mise à jour des distances dans l’air et des lignes de fuite;
c) Ajout de l’Annexe B.
