IEC 61812-1:2023
(Main)Time relays and coupling relays for industrial and residential use - Part 1: Requirements and tests
Time relays and coupling relays for industrial and residential use - Part 1: Requirements and tests
IEC 61812-1:2023 applies to time relays and coupling relays for industrial applications (for example control, automation, signal and industrial equipment) and for automatic electrical controls for use in, on, or in association with equipment for residential and similar use.
The term “relay” as used in this document comprises all types of time relays and coupling relays, other than measuring relays. This document defines type test and routine test to confirm the service condition. Subclause 3.2 provides definitions for different types of time relays in use in the IEC 61812 series. IEC 61812-1:2023 cancels and replaces the second edition published in 2011. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
a) update of references;
b) addition of requirements for risk assessment;
c) addition of requirements for routine test;
d) renumbering of clauses to bring them into a more logical order;
e) clarification of the requirement for shock;
f) addition of cybersecurity requirements for industrial automation and control systems;
g) addition of environmentally conscious design requirement;
h) addition of common data dictionary reference;
i) addition of terms and definitions of relay types;
j) addition of coupling relays in title;
k) addition of coupling relays in scope.
Relais temporisés et relais de de couplage pour applications industrielles et résidentielles - Partie 1: Exigences et essais
L'IEC 61812-1:2023 s'applique aux relais temporisés et aux relais de couplage pour applications industrielles (par exemple, systèmes industriels de commande, d'automatisation et de signalisation) ainsi qu'aux dispositifs de commande électrique automatiques destinés à être utilisés dans, sur ou avec des équipements pour applications résidentielles et analogues. Le terme "relais", utilisé dans le présent document, comprend tous les types de relais temporisés et de relais de couplage, hormis les relais de mesure. Le présent document définit l'essai de type et l'essai individuel de série qui visent à confirmer la condition de service. Les définitions des différents types de relais temporisés utilisés dans la série IEC 61812 sont données en 3.2. L'IEC 61812-1:2023 annule et remplace la deuxième édition parue en 2011. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a) mise à jour des références;
b) ajout d'exigences relatives à l'appréciation du risque;
c) ajout d'exigences relatives à l'essai individuel de série;
d) renumérotation des paragraphes selon un ordre plus logique;
e) clarification de l'exigence relative aux chocs;
f) ajout d'exigences de cybersécurité pour les systèmes d'automatisation et de commande industrielles;
g) ajout d'une exigence d'écoconception;
h) ajout d'une référence au dictionnaire de données commun;
i) ajout de termes et définitions relatifs aux types de relais;
j) ajout des relais de couplage dans le titre;
k) ajout des relais de couplage dans le domaine d'application.
