IEC TS 62351-7:2010

IEC/TS 62351-7 ®
Edition 1.0 2010-07
TECHNICAL
SPECIFICATION
colour
inside
Power systems management and associated information exchange –
Data and communications security –
Part 7: Network and system management (NSM) data object models

IEC/TS 62351-7:2010(E)
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by

any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from either IEC or

IEC's member National Committee in the country of the requester.
If you have any questions about IEC copyright or have an enquiry about obtaining additional rights to this publication,
please contact the address below or your local IEC member National Committee for further information.

Droits de reproduction réservés. Sauf indication contraire, aucune partie de cette publication ne peut être reproduite
ni utilisée sous quelque forme que ce soit et par aucun procédé, électronique ou mécanique, y compris la photocopie
et les microfilms, sans l'accord écrit de la CEI ou du Comité national de la CEI du pays du demandeur.

Si vous avez des questions sur le copyright de la CEI ou si vous désirez obtenir des droits supplémentaires sur cette

publication, utilisez les coordonnées ci-après ou contactez le Comité national de la CEI de votre pays de résidence.

IEC Central Office
3, rue de Varembé
CH-1211 Geneva 20
Switzerland
Email: inmail@iec.ch
Web: www.iec.ch
About IEC publications
The technical content of IEC publications is kept under constant review by the IEC. Please make sure that you have the
latest edition, a corrigenda or an amendment might have been published.
ƒ Catalogue of IEC publications: www.iec.ch/searchpub
The IEC on-line Catalogue enables you to search by a variety of criteria (reference number, text, technical committee,…).
It also gives information on projects, withdrawn and replaced publications.
ƒ IEC Just Published: www.iec.ch/online_news/justpub
Stay up to date on all new IEC publications. Just Published details twice a month all new publications released. Available
on-line and also by email.
ƒ Electropedia: www.electropedia.org
The world's leading online dictionary of electronic and electrical terms containing more than 20 000 terms and definitions
in English and French, with equivalent terms in additional languages. Also known as the International Electrotechnical
Vocabulary online.
ƒ Customer Service Centre: www.iec.ch/webstore/custserv
If you wish to give us your feedback on this publication or need further assistance, please visit the Customer Service
Centre FAQ or contact us:
Email: csc@iec.ch
Tel.: +41 22 919 02 11
Fax: +41 22 919 03 00
IEC/TS 62351-7 ®
Edition 1.0 2010-07
TECHNICAL
SPECIFICATION
colour
inside
Power systems management and associated information exchange –
Data and communications security –
Part 7: Network and system management (NSM) data object models

INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
PRICE CODE
W
ICS 33.200 ISBN 978-2-88912-050-5
– 2 – TS 62351-7 © IEC:2010(E)

CONTENTS
FOREWORD.4

1 Scope.6

2 Normative references .6

3 Terms and definitions .6

4 Glossary of terms and definitions.6

5 Background of network and system management (NSM) requirements (informative).6

5.1 Objectives of IEC NSM standards.6

5.1.1 Scope of end-to-end security.6
5.1.2 End-to-end security measures .7
5.1.3 Security purposes.8
5.1.4 Role of network and system management (NSM) in end-to-end
security .8
5.1.5 Scope of the NSM standard .10
5.2 Current lack of coherent information infrastructure .10
5.3 Intrusion detection systems (IDS) .12
5.3.1 ISO/IEC 18043 IDS guidelines.12
5.3.2 Intrusion detection system (IDS) concepts .13
5.3.3 IDS: Passive observation techniques.14
5.3.4 IDS: Active security monitoring architecture with NSM data objects .15
5.4 Network and system management (NSM) concepts .15
5.4.1 IETF and ISO network management standards .15
5.4.2 ISO NSM categories .16
5.4.3 Simple network management protocol (SNMP) .16
5.4.4 Management information bases (MIBs).16
5.4.5 NSM “data objects” for power system operations .17
6 Security and reliability NSM requirements for power system operations
(informative) .17
6.1 NSM requirements: Monitoring and controlling the networks and protocols .17
6.1.1 Network configuration monitoring and control .17
6.1.2 Network backup monitoring .18
6.1.3 Network communications failures and degradation monitoring .18
6.1.4 Communication protocol monitoring .18
6.2 NSM requirements: Monitoring and management of end systems .19
6.2.1 Monitoring end systems.19
6.2.2 Security control and management of end systems .20
6.3 NSM requirements: Intrusion detection functions .20
6.3.1 Detecting unauthorized access .20
6.3.2 Detecting resource exhaustion as a denial of service (DoS) attack .21
6.3.3 Detecting buffer overflow DoS attacks .21
6.3.4 Detecting tampered/Malformed PDUs .22
6.3.5 Detecting physical access disruption .22
6.3.6 Detecting invalid network access .22
6.3.7 Detecting coordinated attacks.23
7 NSM abstract data types .23
7.1 Abbreviated terms .23
7.2 NSM data object constructs.24

TS 62351-7 © IEC:2010(E) – 3 –

7.2.1 NSM data object fields.24

7.2.2 Construction of data objects .25

7.2.3 Access to data objects.26

7.3 High level NSM data type structures.26

7.3.1 Opaque (not known / not specified / special).30

8 NSM abstract data objects.30

8.1 Communications health NSM data objects.30

8.1.1 Network configuration monitoring and control .30

8.1.2 Network backup monitoring .31

8.1.3 Network communications failures and degradation monitoring .32
8.1.4 Communication protocol monitoring .33
8.2 End system health NSM data objects .33
8.2.1 End system monitoring .33
8.2.2 End system security management .35
8.3 Intrusion detection NSM data objects .35
8.3.1 Unauthorized access NSM data objects.35
8.3.2 Resource exhaustion NSM data objects.35
8.3.3 Buffer overflow NSM data objects.36
8.3.4 Tampered/malformed PDUs.36
8.3.5 Physical access disruption.37
8.3.6 Invalid network access .37
8.3.7 Coordinated attacks.38
Bibliography.39

Figure 1 – Comparison of NSM data objects with IEC 61850 objects.9
Figure 2 – Management of both the power system infrastructure and the information
infrastructure .9
Figure 3 – Power system operations systems, illustrating the security monitoring
architecture.12
Figure 4 – Information exchange between applications: generic communication
topology.13
Figure 5 – Active security monitoring architecture with NSM data objects .15
Figure 6 – Alarm structure .26
Figure 7 – Status structure.27
Figure 8 – Measurement structure .27

Figure 9 – Setting structure.28
Figure 10 – Array.28
Figure 11 – Table .29
Figure 12 – Control hardware.29
Figure 13 – Control software.30

– 4 – TS 62351-7 © IEC:2010(E)

INTERNATIONAL ELECTROTECHNICAL COMMISSION

____________
POWER SYSTEMS MANAGEMENT AND
ASSOCIATED INFORMATION EXCHANGE –

DATA AND COMMUNICATIONS SECURITY –

Part 7: Network and system management (NSM) data object models

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of

patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
The main task of IEC technical committees is to prepare International Standards. In
exceptional circumstances, a technical committee may propose the publication of a technical
specification when
• the required support cannot be obtained for the publication of an International Standard,
despite repeated efforts, or
• the subject is still under technical development or where, for any other reason, there is the
future but no immediate possibility of an agreement on an International Standard.
Technical specifications are subject to review within three years of publication to decide
whether they can be transformed into International Standards.
IEC 62351-7, which is a technical specification, has been prepared by IEC technical
committee 57: Power systems management and associated information exchange.

TS 62351-7 © IEC:2010(E) – 5 –

The text of this technical specification is based on the following documents:

Enquiry draft Report on voting

57/1003/DTS 57/1062/RVC
Full information on the voting for the approval of this technical specification can be found in

the report on voting indicated in the above table.

A list of all parts of the IEC 62351 series, under the general title: Power systems management

and associated information exchange – Data and communications security, can be found on

the IEC website.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.
The committee has decided that the contents of this publication will remain unchanged until
the stability date indicated on the IEC web site under "http://webstore.iec.ch" in the data
related to the specific publication. At this date, the publication will be be
• transformed into an International standard,
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
A bilingual version of this publication may be issued at a later date.

IMPORTANT – The 'colour inside' logo on the cover page of this publication indicates
that it contains colours which are considered to be useful for the correct
understanding of its contents. Users should therefore print this document using a
colour printer.
– 6 – TS 62351-7 © IEC:2010(E)

POWER SYSTEMS MANAGEMENT AND
ASSOCIATED INFORMATION EXCHANGE –

DATA AND COMMUNICATIONS SECURITY –

Part 7: Network and system management (NSM) data object models

1 Scope
Power systems operations are increasingly reliant on information infrastructures, including
communication networks, intelligent electronic devices (IEDs), and self-defining
communication protocols. Therefore, management of the information infrastructure has
become crucial to providing the necessary high levels of security and reliability in power
system operations. Using the concepts developed in the IETF simple network management
protocol (SNMP) standards for network management, IEC/TS 62351-7 defines network and
system management (NSM) data object models that are specific to power system operations.
These NSM data objects will be used to monitor the health of networks and systems, to detect
possible security intrusions, and to manage the performance and reliability of the information
infrastructure.
The NSM data objects use the naming conventions developed for IEC 61850, expanded to
address NSM issues. These data objects, and the data types of which they are comprised, are
defined as abstract models of data objects. The actual bits-and-bytes formats of the data
objects will depend upon the mapping of these abstract NSM data objects to specific
protocols, such as IEC 61850, IEC 60870-5, IEC 60870-6, IEC 61968/IEC 61970 (CIM), web
services, SNMP or any other appropriate protocol. Those mappings will need to be
standardized in separate documents.
2 Normative references
The following referenced documents are indispensable for the application of this document.
For dated references, only the edition cited applies. For undated references, the latest edition
of the referenced document (including any amendments) applies.
IEC/TS 62351-2, Power systems management and associated information exchange – Data
and communications security – Part 2: Glossary of terms
3 Terms and definitions
For the purposes of the present document, the terms and definitions given in IEC/TS 62351-2
apply.
4 Glossary of terms and definitions
See IEC/TS 62351-2.
5 Background of network and system management (NSM) requirements
(informative)
5.1 Objectives of IEC NSM standards
5.1.1 Scope of end-to-end security
End-to-end security encompasses not only deliberate attacks but also inadvertent actions.

TS 62351-7 © IEC:2010(E) – 7 –

This statement is crucial to understanding the scope of this standard. Although some

definitions of “security” just include the protection of systems against the deliberate attacks of

terrorists or cyber hackers, often more damage is done by carelessness, equipment failures

and natural disasters than by those deliberate attacks. Therefore, in this standard, “security”

covers all hazards, including deliberate attacks, inadvertent mistakes, equipment failures,

software problems and natural disasters. For the security and reliability of power system

operations, it does not matter whether a problem was caused by a deliberate attack or by an
inadvertent action.
In addition, many of the same measures that could be used against deliberate attacks can be
used against inadvertent actions. Therefore, it is useful and cost-effective to address both

types of security threats with the same types of security measures.

5.1.2 End-to-end security measures
IEC/TS 62351-3 to IEC/TS 62351-6 address security measures for communication protocols.
End-to-end security entails a much larger scope than just the authentication of users and the
encryption of these protocols. End-to-end security involves security policies, access control
mechanisms, key management, audit logs, and other critical infrastructure protection issues.
It also entails securing the information infrastructure itself.
As discussed in IEC/TS 62351-1, security threat agents include:
a) Inadvertent: Threat agents which may cause inadvertent “attacks” on systems:
• careless users;
• employees who bypass security;
• safety system failures;
• equipment failures;
• natural disasters.
b) Deliberate: Threat agents which undertake deliberate attacks:
• disgruntled employee;
• industrial espionage agents;
• vandals;
• cyber hackers;
• viruses and worms;
• thieves;
• terrorists.
The key point is that the overall security of power system operations is threatened not only by
deliberate acts of terrorism but by many other, sometimes deliberate, sometimes inadvertent
threats that can ultimately have more devastating consequences than direct espionage.
As noted in IEC/TS 62351-1, securing protocols using IEC/TS 62351-3 to IEC/TS 62351-6
essentially provides authentication and (for some protocols) encryption over the
communications link, covering 3 of the 4 security requirements: integrity, confidentiality and
non-repudiation. These very important security measures still, however, leave serious gaps:
– First, they cover only the protocols over the communications link, and do not address
the end users and end equipment. Masquerading users, equipment failures or
undetected intrusions can disrupt operations even if the data exchanges are continuing
correctly.
– Second, they do not address denial of service. Denial of service can take many forms,
from slowed data exchanges, failures of equipment, faults in communication paths,
sporadic or decreased availability, interference and theft.

– 8 – TS 62351-7 © IEC:2010(E)

Although the main objective of security measures may be to prevent security attacks, security

measures cannot be entirely preventative. If only prevention were attempted, then when

(there is always a when) an attacker does manage to penetrate a periphery, they would have

complete freedom to do whatever damage they wanted to. Therefore, “prevention” of attacks

should be viewed as both deterrence and delay of attacks. In addition, security protection

needs to be provided to counter attacks that were not deterred.

5.1.3 Security purposes
The purposes for security protection are often described as 5 layers, with security measures

addressing one or more of these layers:

• Deterrence and delay, to try to avoid attacks or at least delay them long enough for
counter actions to be undertaken. This is the primary defence, but should not be
viewed as the only defence.
• Detection of attacks, primarily those that were not deterred, but could include attempts
at attacks. Detection is crucial to any other security measures since if an attack is not
recognized, little can be done to prevent it. Intrusion detection capabilities can play a
large role in this effort.
• Assessment of attacks, to determine the nature and severity of the attack. For
instance, has the attack breached the confidentiality of private data, or is the attack
more of a nuisance such as the printer not being available.
• Communication and notification, so that the appropriate authorities and/or computer
systems can be made aware of the security attack in a timely manner. Network and
system management can play a large role in this effort.
• Response to attacks, which includes actions by the appropriate authorities and
computer systems to mitigate the effect of the attack in a timely manner. This response
can then deter or delay a subsequent attack.
5.1.4 Role of network and system management (NSM) in end-to-end security
End-to-end security involves far more than encryption or authentication, which are the primary
security methods. As discussed in IEC/TS 62351-1 and shown in Figure 1, the entire
information infrastructure must be made secure and reliable in order to provide security and
reliability of power system operations. Figure 2 shows the management of both the power
system infrastructure and the information infrastructure.

TS 62351-7 © IEC:2010(E) – 9 –

IEC  1638/10
Figure 1 – Comparison of NSM data objects with IEC 61850 objects

IEC  1639/10
Figure 2 – Management of both the power system infrastructure
and the information infrastructure

– 10 – TS 62351-7 © IEC:2010(E)

Not all of these security and reliability requirements can be filled by network and system

management (NSM), but many of them can be ameliorated. Specifically, the following

functions can be provided by NSM:

• Monitoring the status of software applications, hardware equipment, and

communications. This status monitoring can provide notification of changes, such as
equipment failures, abnormal configuration changes, software “crashes” or failures,
temporary communication disruptions, and permanent communication failures.

• Monitoring the performance of systems and communications. This performance

monitoring can record data traffic conditions, software application performance

changes, data throughput changes, performance results from communication
configuration changes, etc.
• Intrusion detection. In addition to obvious intrusions, this detection must be sensitive to
“normal” conditions in order to attempt to detect subtle changes in conditions which
might signal an intrusion. This intrusion detection would utilize the information from the
status and performance monitoring.
• Configuration management. The configuration of communications networks and
equipment can be managed, either by establishing automatic changes based on events
(e.g. move to backup channel if the primary channel fails), or by manually changing the
configuration, such as taking one piece of equipment out of service and replacing it
with another.
5.1.5 Scope of the NSM standard
The scope of the IEC NSM standard includes the following requirements.
• Monitoring communications networks and end equipment in operational environments,
with the purpose of detecting possible attacks, including attacks against confidentiality,
integrity, denial of service, and non-repudiation. This monitoring covers performance,
configuration, faults, and security. The functions supported by this monitoring include
equipment failure/fault detection, performance assessment, certificate assessment,
intrusion detection, audit logging, access control, anti-virus protection, backup and
remote monitoring of physical security.
• Controls for communication networks and end equipment, with the purpose of
preventing or mitigating possible attacks, including attacks against confidentiality,
integrity, denial of service, and non-repudiation. The functions supported by these
controls include running diagnostics, re-configuration, re-start and application program
control.
The end-to-end security issues NOT covered by these NSM standards include:
– security policies;
– identity establishment of users and equipment;
– credential establishment;
– certificate management, such as certificate establishment and certificate revocation;
– physical security measures such as fences, gates, video surveillance, except for the
monitoring and control of the equipment used for physical security.
5.2 Current lack of coherent information infrastructure
The information infrastructure in power operations is not typically treated as a coherent
infrastructure, but is viewed as a collection of individual communication channels, separate
databases, multiple systems, and different protocols. Often SCADA systems perform some
minimal communications monitoring, such as whether communications are available to their
remote terminal units (RTUs), and then they flag data as “unavailable” if communications are
lost. However, it is up to the maintenance personnel to track down what the problem is, what
equipment is affected, where the equipment is located, and what should be done to fix the
problem. All of this is a lengthy and ad hoc process. In the mean time, the power system is
not being adequately monitored, and some control actions may be impossible. As the analysis

TS 62351-7 © IEC:2010(E) – 11 –

of the August 14, 2003 blackout showed, the primary reason behind the blackout itself was

the lack of critical information made available to the right user at the right time.

Every utility is different in what information is available to its maintenance staff.

Telecommunication technicians are generally responsible for tracking down any microwave or

fibre cable problems; telecommunication service providers must track their networks;

database administrators must determine if data is being retrieved correctly from substation

automation systems or from geographical information system (GIS) databases; protocol

engineers must correct protocol errors; application engineers must determine if applications

have crashed, have not converged or are in an endless loop; and operators must filter through
large amounts of data to determine if a possible “power system problem” is really an

“information system problem”.
In the future, the problem of information management will become increasingly complex.
SCADA systems will no longer have exclusive control over the communications to the field,
which may be provided by telecommunication providers, or by the corporate networks, or by
other utilities. Intelligent electronic devices (IEDs) will have applications executing within them
whose proper functioning is critical to power system reliability. Field devices will be
communicating with other field devices, using channels not monitored by any SCADA system.
Information networks in substations will rely on local “self-healing” procedures which will also
not be explicitly monitored or controlled by today’s SCADA systems.
Security and reliability NSM data objects need to be defined that are specific for the power
industry. These NSM data objects will support communications network integrity, system and
application health, Intrusion detection systems (IDS), firewalls, and other security/network
management requirements that are unique to power system operations. The basic elements of
power system operations system with the addition of a security monitoring architecture are
shown in Figure 3.
– 12 – TS 62351-7 © IEC:2010(E)

Security Monitoring Architecture, Using NSM Data Objects

Control Center
Engineering TASE.2 link to
Systems External Systems
Historical Database
IDS
and Data Interface
Firewall
Firewall
Operator User
Security
SCADA System
Interface
Client
IDS
WAN
Legend:
Substation
Firewall
Clients
IDS
Security
Servers
Server
Substation
Capacitor Bank
Master
Controller
Other
Firewall
PT
CT
Voltage
Circuit
Automated
NSM Data Objects
Regulator
Breaker Load Tap Switch
Protection
Changer
Intrusion Detection
Relay
Feeders
System (IDS)
IEC  1640/10
Figure 3 – Power system operations systems, illustrating
the security monitoring architecture
The security and reliability requirements that the NSM data objects will fulfil include the types
of monitoring and control discussed in the following subclauses.
5.3 Intrusion detection systems (IDS)
5.3.1 ISO/IEC 18043 IDS guidelines

ISO/IEC 18043 provides guidelines for effective selection, deployment and operations of
intrusion detection systems. In its Introduction, it states:
“Organizations should not only know when, if, and how an intrusion of their network, system
or application occurs, they also should know what vulnerability was exploited and what
safeguards or appropriate risk treatment options (i.e. risk transfer, risk acceptance, risk
avoidance) should be implemented to prevent similar intrusions in the future. Organizations
should also recognize and deflect cyber-based intrusions. This requires an analysis of host
and network traffic and/or audit trails for attack signatures or specific patterns that usually
indicate malicious or suspicious intent. In the mid-1990s, organizations began to use intrusion
detection systems (IDS) to fulfil these needs. The general use of IDS continues to expand
with a wider range of IDS products being made available to satisfy an increasing level of
organizational demands for advanced intrusion detection capability.
In order for an organization to derive the maximum benefits from IDS, the process of IDS
selection, deployment and operations should be carefully planned and implemented by
properly trained and experienced personnel. In the case where this process is achieved, then

TS 62351-7 © IEC:2010(E) – 13 –

IDS products can assist an organization in obtaining intrusion information and can serve as an

important security device within the overall information and communications technology (ICT)

infrastructure.”
5.3.2 Intrusion detection system (IDS) concepts

Cyber security against deliberate or inadvertent attacks is a critical aspect of network and

system management. This cyber security covers not only the security threats aimed at the

data exchanges between systems, but also the security threats within systems due to the
“intrusion” of erroneous messages and/or malicious code.

For data exchanges, identity establishment and authentication are key security capabilities for
ensuring integrity and non-repudiation. Encryption techniques provide security for
confidentiality. None of these methods provide much security for availability: in which denial
of service (DoS) attacks can cause data exchanges between systems to become less
available, slower or totally unavailable.
For internal system cyber security, one of the key security mechanisms is intrusion detection
systems (IDS). These IDSs monitor (either “passively” or “actively”) the traffic on networks,
and, depending upon their capabilities, attempt to determine if some traffic is a security risk,
including whether DoS attacks are taking place. NSM data objects can assist IDSs in avoiding
or minimizing denial of service (DoS) attacks and other security intrusions.
Many different methods can be implemented to detect security-related intrusions in networks
and systems. For end-to-end security, the entire communication path between applications
needs to be evaluated, including through intermediate systems (IS), and can be illustrated
with the model shown in Figure 4.

IEC  1641/10
Figure 4 – Information exchange between applications:
generic communication topology
The simplified diagram depicts two applications attempting to exchange information. In this
diagram, in order to exchange information, the information needs to be:
• transmitted through a local communication stack;
• transmitted from the local communication stack onto a local area network (LAN);
• routed/bridged into a wide area network (WAN) via an intermediate system (IS);
• received by a remote IS;
– 14 – TS 62351-7 © IEC:2010(E)

• transmitted by the remote IS onto the remote application’s LAN;

• received by the remote application’s communication stack;

• delivered to the remote application for processing.

Each of these locations could provide information on possible intrusion detections, including
the following types of integrity, confidentiality, availability and non-repudiation security
threats:
– resource exhaustion or “significant” performance impacts due to unexpectedly large

number of messages being sent, inadvertently or deliberately, which prevent or delay

legitimate messages from being received;

– buffer overflows, caused either by “mistakes” in forming messages or by malicious
attacks to disrupt system operations;
– PDUs (packets) that are (inadvertently) malformed or have been (deliberately)
tampered with;
– invalid network access attempts by messages with unauthorized IP addresses or port
requests;
– invalid application access attempts.
Two basic methods exist for IDSs: passive observation techniques and active security
monitoring. These are discussed in the following subclauses.
5.3.3 IDS: Passive observation techniques
Passive observation techniques (i.e. requiring no modifications to the IS, COMM stack, or
application) require only the addition of “network based IDS” monitors – existing equipment
and networks do not need to be modified, thus making these security upgrades easier and
less expensive to implement. For this reason, passive IDSs are the preferred approach when
considering systems and equipment which are already installed or will use “non-IDS” end
equipment.
Figure 4 illustrates two passive observation points in the local and remote networks, shown as
two blue circles.
Purely passive IDSs have limited ability to detect intrusions since they may not be “aware” of
what normal traffic might be in typical power system operations. However, in addition to these
passive IDSs, NSM data objects can be implemented in systems which house the applications
and communication stacks, as well as in the intermediate systems (IS) (see the many red dots
in Figure 4). These NSM data objects would provide additional intelligence to determine if an
attack is underway, what type of attack is taking place, and the time of the critical events.

The NSM data objects in a legacy system would simply include available information that
could be sent as additional data using the existing protocols. Often this data is available but
either ignored or stored in a local log as an “error”. The key is to identify the important, but
available data, and provide it to the IDS or to a security system.

TS 62351-7 © IEC:2010(E) – 15 –

5.3.4 IDS: Active security monitoring architecture with NSM data objects

Active security monitoring involves designing the networks and the end systems with security

monitoring as part of the design criteria. Rather than relying on what error checking is

available in legacy systems, these systems include in their design the ability to identify and

provide additional security information to a “security client”, including information on

anomalous events, unauthorized messages, data possibly related to DoS attacks, etc.

In this active security monitoring architecture, each layer in the protocol stack would monitor

for possible security attacks, and many applications would provide key error and failure data.

A security provider would manage the NSM data objects, possibly setting appropriate

thresholds, limits, and other parameters in order to fine-tune the response to more closely fit
each power system operational environment. Upon the detection of an anomaly, the NSM
data would be sent to the security client for additional analysis (see Figure 5).
This architecture is similar to the SNMP and RMON architectures. However, this does not
imply that the SNMP formats will necessarily be used to transmit the NSM data: the NSM data
objects would be implemented using whatever protocol is being used for other types of
communications.
IEC  1642/10
Figure 5 – Active security monitoring architecture with NSM data objects

5.4 Network and system management (NSM) concepts
5.4.1 IETF and ISO network management standards
The technology industry has developed two network management technologies: simple
network management protocol (SNMP) for the internet-based functions (standardized by the
IETF), and common management information protocol (CMIP) as an ISO standard.
In both standards, management information base (MIB) objects must be specified
representing the state of different equipment, applications, and systems. Although some MIB
objects are generic enough for typical network equipment to be used by the power industry,
many specialized MIB objects will need to be developed to represent some of the very
specialized equipment and special environments found in power system operations.

– 16 – TS 62351-7 © IEC:2010(E)

5.4.2 ISO NSM categories
Network management involves many different aspects, but has been organized by the ISO

into 5 areas:
• performance management;
• configuration management;
• accounting management;
• fault management;
• security management.
Of these 5 areas, only accounting management is not directly associated with end-to-end
security. The other 4 areas are either directly or indirectly involved in security. For instance, if
an equipment failure or a careless parameter change causes degradation of performance,
then the reliability of power system operations may be affected; or a change in network
configuration could result in a single point of failure that is not recognized until that failure
occurs; or an undetected intrusion causes time-sensitive data exchanges to slow down and
not reach their destinations in a timely manner.
5.4.3 Simple network management protocol (SNMP)
The simple network management protocol (SNMP) was developed by the IETF as the protocol
for transmitting MIBs over the Internet. Many systems use SNMP internally as well. However,
MIBs do not need to be transmitted by SNMP; any protocol can be used. In this standard, no
explicit protocol is identified for transmitting the MIBs. This means that the MIB data may be
transferred via whatever protocol is being used, using whatever mapping to objects is
appropriate.
Some systems and equipment do include SNMP. In these cases, the MIBs could be mapped
to SNMP directly.
5.4.4 Management information bases (MIBs)
Management information bases (MIBs) are used to define what information is needed to
manage the information infrastructure as securely and reliably as the powe
...
