1 Scope
This part of IEC 60966 is a detail specification that relates to semi-rigid cable assemblies
composed of type 50-12 low loss semi-rigid coaxial cables and connectors such as type 7-16
(IEC 61169-4), type 4.1-9.5 (IEC 61169-11), type N (IEC 61169-16), type S7-16 (IEC 61169-53)
or type 4.3-10 (IEC 61169-54).
This detail specification applies to the cable assemblies (jumper cables) for mobile
communication, particularly for the cable assemblies used between the main feeder and
antennas or between the main feeder and equipment system or between remote radio heads
and antennas. The operating frequency is up to 6 000 MHz.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies.
For undated references, the latest edition of the referenced document (including any
amendments) applies.
IEC 60068-2-11, Environmental testing – Part 2-11: Tests Test Ka: Salt mist
IEC 60529, Degrees of protection provided by enclosures (IP Code)
IEC 60966-1:2019, Radio frequency and coaxial cable assemblies – Part 1: Generic
specification – General requirements and test methods
IEC 60966-4, Radio frequency and coaxial cable asse
...
