IEC 62619:2022
(Main)Secondary cells and batteries containing alkaline or other non-acid electrolytes - Safety requirements for secondary lithium cells and batteries, for use in industrial applications
Secondary cells and batteries containing alkaline or other non-acid electrolytes - Safety requirements for secondary lithium cells and batteries, for use in industrial applications
IEC 62619:2022 specifies requirements and tests for the safe operation of secondary lithium cells and batteries used in industrial applications, including stationary applications. When there exists an IEC International Standard specifying test conditions and requirements for cells used in special applications and which is in conflict with this document, the former takes precedence (e.g., IEC 62660 series on road vehicles). The following are some examples of applications that utilize cells and batteries under the scope of this document:
- Stationary applications: telecom, uninterruptible power supplies (UPS), electrical energy storage system, utility switching, emergency power, and similar applications.
- Motive applications: forklift truck, golf cart, automated guided vehicle (AGV), railway vehicles, and marine vehicles, with the exception of road vehicles.
Accumulateurs alcalins et autres accumulateurs à électrolyte non acide - Exigences de sécurité pour les accumulateurs au lithium pour utilisation dans des applications industrielles
IEC 62619:2022 spécifie les exigences et les essais pour le fonctionnement en toute sécurité des accumulateurs au lithium utilisés dans des applications industrielles, y compris les applications stationnaires. Lorsqu'il existe une Norme internationale IEC qui spécifie des conditions d'essai et des exigences pour des éléments destinés à des applications particulières, et qui est en contradiction avec le présent document, la publication particulière est appliquée en priorité (par exemple, la série IEC 62660 sur les véhicules routiers). Ci-après figurent des exemples d’applications qui emploient les éléments et les batteries inclus dans le domaine d’application du présent document :
- applications stationnaires: télécommunications, alimentation sans interruption (ASI), système de stockage d'énergie électrique, sélecteur de service, alimentation de secours et applications similaires;
- applications mobiles: chariot élévateur à fourche, voiturette de golf, véhicule à guidage automatique (AGV, automated guided vehicle), véhicules ferroviaires et marins, à l'exclusion des véhicules routiers.
