EN 61076-3-100:2000

SLOVENSKI STANDARD
01-september-2002
Connectors with assessed quality, for use in d.c., low frequency analogue and
digital high-speed data applications - Part 3-100: Rectangular connectors with
assessed quality - Detail specification for a range of shielded connectors with
trapezoidal-shaped shells and non-removable ribbon contacts on a 1.27 mm
double row (IEC 61076-3-100:1999)
Connectors for use in d.c., low-frequency analogue and digital high speed data
applications -- Part 3-100: Rectangular connectors with assessed quality - Detail
specification for a range of shielded connectors with trapezoidal-shaped shells and non-
removable ribbon contacts on a 1,27 mm double row
Steckverbinder für Gleichspannungs- und Niederfrequenzanwendungen sowie digitale
Anwendungen mit hoher Übertragungsrate -- Teil 3-100: Rechteckige Steckverbinder mit
bewerteter Qualität - Bauartspezifikation für eine Reihe von geschirmten Steckverbindern
mit trapezförmigen Kragen und nicht auswechselbaren Streifenkontakten in einem
Raster von 1,27 mm, doppelreihig
Connecteurs pour applications analogiques en courant continu et à basse fréquence et
pour applications numériques utilisant des débits élevés pour le transfert des données --
Partie 3-100: Connecteurs rectangulaires sous assurance de la qualité - Spécification
particulière pour une famille de connecteurs blindés à boîtiers trapézoïdaux, deux
rangées au pas de 1,27 mm et contacts à lame, non démontables
Ta slovenski standard je istoveten z: EN 61076-3-100:2000
ICS:
31.220.10 9WLþLLQYWLþQLFHNRQHNWRUML Plug-and-socket devices.
Connectors
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

NORME CEI
INTERNATIONALE IEC
61076-3-100
INTERNATIONAL
QC 480201XX0001
STANDARD
Première édition
First edition
1999-11
Connecteurs pour applications analogiques
en courant continu et à basse fréquence et pour
applications numériques utilisant des débits
élevés pour le transfert des données –
Partie 3-100:
Connecteurs rectangulaires sous assurance de la qualité –
Spécification particulière pour une famille de connecteurs
blindés à boîtiers trapézoïdaux, deux rangées au pas
de 1,27 mm et contacts à lame, non démontables
Connectors for use in d.c., low-frequency analogue
and digital high speed data applications –
Part 3-100:
Rectangular connectors with assessed quality –
Detail specification for a range of shielded connectors
with trapezoidal-shaped shells and non-removable ribbon
contacts on a 1,27 mm double row
 IEC 1999 Droits de reproduction réservés  Copyright - all rights reserved
Aucune partie de cette publication ne peut être reproduite ni No part of this publication may be reproduced or utilized in
utilisée sous quelque forme que ce soit et par aucun procédé, any form or by any means, electronic or mechanical,
électronique ou mécanique, y compris la photo-copie et les including photocopying and microfilm, without permission in
microfilms, sans l'accord écrit de l'éditeur. writing from the publisher.
International Electrotechnical Commission 3, rue de Varembé Geneva, Switzerland
Telefax: +41 22 919 0300 e-mail: inmail@iec.ch IEC web site http://www.iec.ch
CODE PRIX
Commission Electrotechnique Internationale
X
PRICE CODE
International Electrotechnical Commission
Pour prix, voir catalogue en vigueur
For price, see current catalogue

61076-3-100  IEC:1999 – 3 –
CONTENTS
Page
FOREWORD . 7
Clause
1 General data . 11
1.1 Recommended method of mounting . 11
1.1.1 Minimum and maximum number of contacts . 11
1.2 Rating and characteristics . 11
1.3 Normative references. 13
1.4 Marking. 15
1.5 IEC type designation . 15
1.6 Ordering information . 19
2 Technical data. 19
2.1 General. 19
2.2 Survey of styles and variants. 19
2.3 Information on application . 19
3 Dimensional information . 19
3.1 General. 19
3.2 Isometric view and common features (with locking devices). 21
3.3 Mating information . 21
3.3.1 Contact arrangements . 21
3.3.2 Mating face dimensions. 25
3.3.3 Contact mating dimensions. 29
3.4 Fixed connectors. 29
3.4.1 Dimensions . 31
3.4.2 Terminations . 41
3.5 Free connectors . 43
3.5.1 Dimensions . 43
3.5.2 Termination. 49
3.6 Accessories . 49
3.7 Mounting information. 49
3.7.1 Hole pattern on printed boards . 49
3.7.2 Panel cutout dimensions. 57
4 Characteristics . 59
4.1 Climatic category . 59
4.2 Electrical. 59
4.2.1 Creepage and clearance distance. 59
4.2.2 Voltage proof. 59
4.2.3 Current-carrying capacity. 59
4.2.4 Initial contact resistance . 59
4.2.5 Initial insulation resistance . 61
4.3 Mechanical. 61
4.3.1 Mechanical operation . 61
4.3.2 Insertion and withdrawal forces . 61

61076-3-100  IEC:1999 – 5 –
Clause Page
5 Test schedule . 63
5.1 General. 63
5.2 Test schedules. 65
5.2.1 Basic (minimum) test schedule . 65
5.2.2 Full test schedule . 65
6 Quality assessment procedures. 77
6.1 Qualification approval testing . 77
6.1.1 Method 1. 77
6.1.2 Method 2. 79
6.2 Quality conformance inspection. 79
6.2.1 Lot-by-lot tests . 79
6.2.2 Periodic tests . 79
6.3 Delayed delivery, re-inspection. 81

61076-3-100  IEC:1999 – 7 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
___________
CONNECTORS FOR USE IN DC, LOW-FREQUENCY ANALOGUE
AND DIGITAL HIGH SPEED DATA APPLICATIONS –
Part 3-100: Rectangular connectors with assessed quality –
Detail specification for a range of shielded connectors with
trapezoidal-shaped shells and non-removable ribbon contacts
on a 1,27 mm double row
FOREWORD
1) The IEC (International Electrotechnical Commission) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of the IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, the IEC publishes International Standards. Their preparation is
entrusted to technical committees; any IEC National Committee interested in the subject dealt with may
participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. The IEC collaborates closely with the International Organization
for Standardization (ISO) in accordance with conditions determined by agreement between the two
organizations.
2) The formal decisions or agreements of the IEC on technical matters express, as nearly as possible, an
international consensus of opinion on the relevant subjects since each technical committee has representation
from all interested National Committees.
3) The documents produced have the form of recommendations for international use and are published in the form
of standards, technical reports or guides and they are accepted by the National Committees in that sense.
4) In order to promote international unification, IEC National Committees undertake to apply IEC International
Standards transparently to the maximum extent possible in their national and regional standards. Any
divergence between the IEC Standard and the corresponding national or regional standard shall be clearly
indicated in the latter.
5) The IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with one of its standards.
6) Attention is drawn to the possibility that some of the elements of this International Standard may be the subject
of patent rights. The IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 61076-3-100 has been prepared by subcommittee 48B: Connectors,
of IEC technical committee 48: Electromechanical components and mechanical structures for
electronic equipment.
The text of this standard is based on the following documents:
FDIS Report on voting
48B/787/FDIS 48B/817/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 3.

61076-3-100  IEC:1999 – 9 –
The QC number that appears on the front cover of this publication is the specification number
in the IEC Quality Assessment System for Electronic Components (IECQ).
The committee has decided that this publication remains valid until 2003. At this date, in
accordance with the committee’s decision, the publication will be
• reconfirmed;
• withdrawn;
• replaced by a revised edition, or
• amended.
61076-3-100  IEC:1999 – 11 –
CONNECTORS FOR USE IN DC, LOW-FREQUENCY ANALOGUE
AND DIGITAL HIGH SPEED DATA APPLICATIONS –
Part 3-100: Rectangular connectors with assessed quality –
Detail specification for a range of shielded connectors with
trapezoidal-shaped shells and non-removable ribbon contacts
on a 1,27 mm double row
1 General data
1.1 Recommended method of mounting
A complete connector consists of a fixed connector mounted vertically or at a right angle to the
printed circuit board or panel mounted. The free connector is terminated to a cable consisting
of 14 to 110 conductors.
1.1.1 Minimum and maximum number of contacts
The fixed and free connectors have a range of 14 to 110 contacts. The shape of the shell
prevents mismating.
Examples of contact arrangements are shown in figure 2.
1.2 Rating and characteristics
Working voltage: 250 V a.c.
Current rating: 0,5 A (0,005 mm), 1 A (0,09 mm)
Insulation resistance: 500 MΩ minimum (initial)
Climatic category: PL1: 55/085/21
PL2:55/085/0
Printed board thickness: 0,8 mm
1,0 mm
1,2 mm
1,6 mm
2,4 mm
Contact spacing:
Mating side: 1,27 mm pitch (double rows)
Printed board side: 2,54 mm pitch × 1,905 mm (four rows)

61076-3-100  IEC:1999 – 13 –
1.3 Normative references
The following normative documents contain provisions which, through reference in this text,
constitute provisions of this International Standard. For dated references, subsequent
amendments to, or revisions of, any of these publications do not apply. However, parties to
agreements based on this International Standard are encouraged to investigate the possibility
of applying the most recent editions of the normative documents indicated below. For undated
references, the latest edition of the normative document referred to applies. Members of IEC
and ISO maintain registers of currently valid International Standards.
IEC 60050(581):1978, International Electrotechnical Vocabulary (IEV) – Chapter 581: Electro-
mechanical components for electronic equipment
IEC 60068-1:1988, Environmental testing – Part 1: General and guidance
Amendment 1 (1992)
IEC 60352-4:1994, Solderless connections – Part 4: Solderless non-accessible insulation
displacement connections – General requirements, test methods and practical guidance
IEC 60410:1973, Sampling plans and procedures for inspection by attributes
IEC 60512-1:1994, Electromechanical components for electronic equipment – Basic testing
procedures and measuring methods – Part 1: General
IEC 60512-2:1985, Electromechanical components for electronic equipment – Basic testing
procedures and measuring methods – Part 2: General examination, electrical continuity and
contact resistance tests, insulation tests and voltage stress tests
Amendment 1 (1994)
IEC 60512-3:1976, Electromechanical components for electronic equipment – Basic testing
procedures and measuring methods – Part 3: Current-carrying capacity tests
IEC 60512-4:1976, Electromechanical components for electronic equipment – Basic testing
procedures and measuring methods – Part 4: Dynamic stress tests
IEC 60512-5:1992, Electromechanical components for electronic equipment – Basic testing
procedures and measuring methods – Part 5: Impact tests (free components), static load tests
(fixed components), endurance tests and overload tests
IEC 60512-6:1984, Electromechanical components for electronic equipment – Basic testing
procedures and measuring methods – Part 6: Climatic tests and soldering tests
IEC 60512-7:1993, Electromechanical components for electronic equipment – Basic testing
procedures and measuring methods – Part 7: Mechanical operating tests and sealing tests
IEC 60512-8:1993, Electromechanical components for electronic equipment – Basic testing
procedures and measuring methods – Part 8: Connector tests (mechanical) and mechanical
tests on contacts and terminations

61076-3-100  IEC:1999 – 15 –
IEC 60512-9:1992, Electromechanical components for electronic equipment – Basic testing
procedures and measuring methods – Part 9: Miscellaneous tests
IEC 60512-11-1:1995, Electromechanical components for electronic equipment – Basic testing
procedures and measuring methods – Part 11: Climatic tests – Section 1: Test 11a – Climatic
sequence
IEC 61076-1:1995, Connectors with assessed quality, for use in d.c., low frequency analogue
applications and in digital high speed data applications – Part 1: Generic specification
IEC 61076-3, — Connectors with assessed quality, for use in d.c., low frequency analogue and
1)
digital high speed data applications – Part 3: Rectangular connectors
1.4 Marking
The marking of the connector and the package shall be in accordance with the requirements of
the sectional specification IEC 61076-3.
1.5 IEC type designation
Each connector and its associated package shall be marked in accordance with the
requirements specified in 2.5 of IEC 61076-1.
________
1)
To be published.
61076-3-100  IEC:1999 – 17 –
L NN N L L L L N L
IEC 61076-3-100
Assessment level
Reference to
standard
G
Assessment level 1
Performance level
Style of connector
Fixed connectors
Performance level 1
Performance level 2
Shielded right-angle with
A
locking latch
Board retention
Shielded right-angle with
B A Screw
screw lock
B Retention leg
Shielded vertical with
C
screw latch C Clip
Shielded vertical with
D Other
D
screw lock
Shielded with locking Board thickness
E
latch, cable type
A 0,8 mm
Free connectors
B 1,0 mm
Shielded with locking
K C 1,2 mm
latch
D 1,6 mm
Shielded with screw
L
lock
E 2,4 mm
Number of contacts Type of termination
014,   020,   026, I Insulation displacement
036,   040,   050,
S Solder
068,   080,   096,
100,  110
"L" stands for letter
Type of contact
"N" stands for number
Ribbon R
Example
IEC 61076-3 -100 A020RSDB-1G: Fixed connector, shielded right angle with locking latch,
20 contacts, ribbon contact, solder termination, board
thickness 1,6 mm, board retention is retention leg, meeting
performance level 1, assessment level G.

61076-3-100  IEC:1999 – 19 –
1.6 Ordering information
For ordering connectors according to this detail specification, the type designation described
in 1.5 shall be used.
2 Technical data
2.1 General
This International Standard applies to a range of shielded two-part connectors with trapezoidal-
shaped shells and non-removable ribbon contacts on 1,27 mm double rows.
The fixed connectors are provided with a post either for dip solder (type A, B, C, D) or non-
accessible insulation displacement terminations (type E). The free connectors are provided
with non-accessible insulation displacement terminations.
Insulation displacement terminations are applicable to insulation displacement connection
made with ribbon cable (type E) or single wires (type K, L) having:
– solid conductors: 0,25 mm diameter (0,05 mm ) (AWG 30);
– stranded conductors: 0,09 mm (AWG 28) 7 strands.
2.2 Survey of styles and variants
Table 1 – Style survey
Type of Reference letter
Style of connectors
connector of the style
Shielded right-angle with locking latch A
Shielded right-angle with screw lock B
Fixed Shielded vertical with locking latch C
Shielded vertical with screw lock D
Shielded with locking latch, cable type E
Free Shielded with locking latch K
Shielded with screw lock L
2.3 Information on application
See clause 3.
3 Dimensional information
3.1 General
Original dimensions are in millimetres. Drawings are shown in third-angle projection. The
shape of the connectors may deviate from those given in the following figures as long as the
specified dimensions are not influenced.

61076-3-100  IEC:1999 – 21 –
In cases where the tolerance is unspecified, ±0,3 mm is the tolerance required for millimetre
dimensions stated to one decimal place, ±0,13 mm is the tolerance required for millimetre
dimensions stated to two decimal places and ±0,10 mm is the tolerance required for millimetre
dimensions stated to three decimal places.
Dimensions in parentheses are only for reference on design, but not for inspection.
3.2 Isometric view and common features (with locking devices)
IEC  1218/99 IEC  1219/99
Figure 1a – Shielded right-angle fixed connector with Figure 1b – Shielded vertical fixed connector
latch locking device (style A) and free connector with latch locking (style C)
with latch locking device (style K) and cover case
Figure 1 – Connectors with latch locking devices
3.3 Mating information
3.3.1 Contact arrangements
Contact arrangements, mating face view of fixed connectors. Mating face of free connectors is
mirror image.
The trapezoidal-shaped shell prevents mismating.

61076-3-100  IEC:1999 – 23 –
IEC  1220/99
Figure 2 – Fixed connectors
IEC  1221/99
Figure 3 – Free connectors
Table 2 – Contact number and position
Dimension A
Contact number
Number
mm
of contacts
ab c
14 7 8 14 7,62
20 10 11 20 11,43
26 13 14 26 15,24
36 18 19 36 21,59
40 20 21 40 24,13
50 25 26 50 30,48
68 34 35 68 41,91
80 40 41 80 49,53
96 48 49 96 59,69
100 50 51 100 62,23
110 55 56 110 68,58
61076-3-100  IEC:1999 – 25 –
3.3.2 Mating face dimensions
3.3.2.1 Fixed connectors
IEC  1222/99
Figure 4 – Fixed connectors
Table 3 – Dimensions of fixed connectors
Dimensions
Number
mm
of contacts
BC
14 9,62 12,62
20 13,43 16,43
26 17,24 20,24
36 23,59 26,59
40 26,13 29,13
50 32,48 35,48
68 43,91 46,91
80 51,53 54,53
96 61,69 64,69
100 64,23 67,23
110 70,58 73,58
---------------------- Pa
...
