IEC 61094-3 ®
Edition 2.0 2016-06
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
colour
inside
Electroacoustics – Measurement microphones –

Part 3: Primary method for free-field calibration of laboratory standard

microphones by the reciprocity technique

Électroacoustique – Microphones de mesure –

Partie 3: Méthode primaire pour l’étalonnage en champ libre des microphones

étalons de laboratoire par la méthode de réciprocité

INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
INTERNATIONALE
ICS 17.140.50; 33.160.50 ISBN 978-2-8322-3478-5

– 2 – IEC 61094-3:2016 © IEC 2016
CONTENTS
FOREWORD . 4
1 Scope . 6
2 Normative references. 6
3 Terms and definitions . 6
4 Reference environmental conditions . 7
5 Principles of free-field calibration by reciprocity . 7
5.1 General principles . 7
5.1.1 General . 7
5.1.2 General principles using three microphones . 7
5.1.3 General principles using two microphones and an auxiliary sound
source . 8
5.2 Basic expressions . 8
5.3 Insert voltage technique . 9
5.4 Free-field receiving characteristics of a microphone . 9
5.5 Free-field transmitting characteristics of a microphone . 10
5.6 Reciprocity procedure . 11
5.7 Final expressions for the free-field sensitivity . 11
5.7.1 Method using three microphones . 11
5.7.2 Method using two microphones and an auxiliary sound source . 12
6 Factors influencing the free-field sensitivity . 12
6.1 General . 12
6.2 Polarizing voltage . 12
6.3 Shield configuration . 12
6.4 Acoustic conditions . 13
6.5 Position of the acoustic centre of a microphone . 13
6.6 Dependence on environmental conditions . 14
6.6.1 General . 14
6.6.2 Static pressure . 14
6.6.3 Temperature . 14
6.6.4 Humidity . 14
6.6.5 Transformation to reference environmental conditions. 14
6.7 Considerations concerning measurement space . 15
7 Calibration uncertainty components . 15
7.1 General . 15
7.2 Electrical transfer impedance . 15
7.3 Deviations from ideal free-field conditions . 15
7.4 Attenuation of sound in air . 16
7.5 Polarizing voltage . 16
7.6 Physical properties of air . 16
7.7 Imperfection of theory . 16
7.8 Uncertainty on free-field sensitivity level . 17
Annex A (informative) Values for the position of the acoustic centre . 19
Annex B (normative) Values of the air attenuation coefficient . 20
B.1 General . 20
B.2 Calculation procedure . 20

IEC 61094-3:2016 © IEC 2016 – 3 –
Annex C (informative) Environmental influence on the sensitivity of microphones . 23
C.1 General . 23
C.2 Dependence on static pressure . 23
C.3 Dependence on temperature . 23
Annex D (informative) Application of time selective techniques for removal of
unwanted reflections and acoustic interference between microphones . 25
D.1 General . 25
D.2 Practical considerations . 25
D.2.1 Signal-to-noise ratio . 25
D.2.2 Reflections from walls and measurement rig . 25
D.3 Frequency limitations . 26
D.3.1 General . 26
D.3.2 Measurements based on frequency sweeps . 26
D.3.3 Measurements based on pure tones . 26
D.4 Generating missing portions of the frequency response previous to
transforming to the time-domain. . 27
D.4.1 General . 27
D.4.2 Missing frequencies below the minimum measurement frequency . 27
D.4.3 Missing frequencies above the maximum measured frequency . 27
D.4.4 Filtering the extended frequency response . 28
Bibliography .
...
