EN 60603-13:1998

SLOVENSKI STANDARD
01-september-2002
Connectors for frequencies below 3 MHz for use with printed boards - Part 13:
Detail specification for two-part connectors of assessed quality, for printed boards
for basic grid of 2,54 mm (0,1 in), with free connectors
Connectors for frequencies below 3 MHz for use with printed boards -- Part 13: Detail
specification for two-part connectors of assessed quality, for printed boards for basic grid
of 2,54 mm (0,1 in), with free connectors for non-accessible insulation displacement
terminations (ID)
Steckverbinder für gedruckte Schaltungen für Frequenzen unter 3 MHz -- Teil 13:
Bauartspezifikation für gütebestätigte indirekte Steckverbinder für gedruckte Schaltungen
mit Raster 2,54 mm (0,1 in), mit freiem Steckverbinder für Schneidklemmenanschluß (ID)
Connecteurs pour fréquences inférieures à 3 MHz pour utilisation avec cartes imprimées
-- Partie 13: Spécification particulière pour connecteurs en deux parties, sous assurance
de la qualité pour cartes imprimées pour grille de base de 2,54mm (0,1 in), avec fiches
pour bornes de sortie non-accessibles à déplacement (CAD)
Ta slovenski standard je istoveten z: EN 60603-13:1998
ICS:
31.220.10 9WLþLLQYWLþQLFHNRQHNWRUML Plug-and-socket devices.
Connectors
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

CEI
NORME
INTERNATIONALE IEC
603-13
INTERNATIONAL
STAN DARD
QC 010000XX0001
Première édition
First edition
1995-01
pour fréquences inférieures à 3 MHz
Connecteurs
imprimées —
pour utilisation avec cartes
13:
Partie
connecteurs en deux
Spécification particulière pour
parties sous assurance de la qualité pour cartes
pour grille de base de 2,54 mm (0,1 in),
imprimées
accessibles
avec fiches pour bornes de sortie non
(CAD)
à déplacement d'isolant
Connectors for frequencies below 3 MHz
—
for use with printed boards
Part 13:
Detail specification for two-part connectors of
assessed quality, for printed boards for basic grid
of 2,54 mm (0,1 in), with free connectors for
non-accessible insulation displacement
terminations (ID)
Droits de reproduction réservés — Copyright - all rights reserved
© CEI 1995
Aucune partie de cette publication ne peut être reproduite ni No part of this publication may be reproduced or utilized in
utilisée sous quelque forme que ce soit et par aucun pro- any form or by any means, electronic or mechanical,
cédé, électronique ou mécanique, y compris la photocopie et including photocopying and microfilm, without permission
les microfilms, sans l'accord écrit de l'éditeur. in writing from the publisher.
Genève, Suisse
Bureau Central de la Commission Electrotechnique Internationale 3, rue de Varembé
Commission Electrotechnique Internationale CODE PRIX
International Electrotechnical Commission
PRICE PRICE CODECODE
IEC MewayHaposHan 3neMTpoTeXHH4ecna q HOMHCCHN
Pour prix, voir catalogue en vigueur • •
For price, see current catalogue

-3-
603-13 ©IEC:1995
CONTENTS
Page
FOREWORD
Clause
1 Scope 7
2 Normative references 7
11 3 IEC type designation
4 Common features
13 4.1 Isometric view
4.2 Survey of styles
5 Dimensions
5.1 General
5.2 Fixed connectors
5.3 Free connectors 27
5.4 Mounting information for fixed connectors, styles A and B
6 Gauges
7 Characteristics 39
7.1 Climatic category
7.2 Electrical characteristics
7.3 Mechanical characteristics 43
8 Test schedule
47 8.1 General
9 Quality assessment procedures
9.1 Qualification approval testing
9.2 Quality conformance inspection
9.3 Delayed delivery, re-inspection
79 10 Ordering information
Annex A – Test phase BP 3.2: Corrosion, industrial atmosphere

603-13 ©IEC:1995 - 5 -
INTERNATIONAL ELECTROTECHNICAL COMMISSION
CONNECTORS FOR FREQUENCIES BELOW 3 MHz FOR USE
WITH PRINTED BOARDS -
Part 13: Detail specification for two-part connectors of assessed quality,
for printed boards for basic grid of 2,54 mm (0,1 in), with
free connectors for non-accessible insulation
displacement terminations (ID)
FOREWORD
1) The IEC (International Electrotechnical Commission) is a worldwide organization for standardization
comprising all national electrotechnical committees (IEC National Committees). The object of the IEC is to
promote international cooperation on all questions concerning standardization in the electrical and
electronic fields. To this end and in addition to other activities, the IEC publishes International Standards.
Their preparation is entrusted to technical committees; any IEC National Committee interested in
the subject dealt with may participate in this preparatory work. International, governmental and
non-governmental organizations liaising with the IEC also participate in this preparation. The IEC
collaborates closely with the International Organization for Standardization (ISO) in accordance with
conditions determined by agreement between the two organizations.
2) The formal decisions or agreements of the IEC on technical matters, prepared by technical committees on
which all the National Committees having a special interest therein are represented, express, as nearly as
possible, an international consensus of opinion on the subjects dealt with.
3) They have the form of recommendations for international use published in the form of standards, technical
reports or guides and they are accepted by the National Committees in that sense.
4) In order to promote international unification, IEC National Committees undertake to apply IEC International
Standards transparently to the maximum extent possible in their national and regional standards. Any
divergence between the IEC Standard and the corresponding national or regional standard shall be clearly
indicated in the latter.
5) The IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with one of its standards.
International Standard IEC 603-13 has been prepared by sub-committee 48B: Connectors,
of IEC technical committee 48: Electromechanical components and mechanical structures
for electronic equipment.
The text of this standard is based on the following documents:
DIS Report on voting
48B(CO)252 48 B/367/R V D
Full information on the voting for the approval of this standard can be found in the repo rt
on voting indicated in the above table.
The QC number that appears on the front cover of this publication is the specification
number in the IEC Quality Assessment System for Electronic Components (IECQ).
Annex A forms an integral pa rt of this standard.

603-13 © I EC:1995 - 7 -
CONNECTORS FOR FREQUENCIES BELOW 3 MHz FOR USE
WITH PRINTED BOARDS -
Part 13: Detail specification for two-part connectors of assessed quality,
for printed boards for basic grid of 2,54 mm (0,1 in), with
free connectors for non-accessible insulation
displacement terminations (ID)
1 Scope
covers a range of two-part connectors with contact arrangements
This part of IEC 603
having spacings of 2,54 mm (0,1 in) in both directions. The two-part connector range
comprises a fixed (board-mounted) connector containing male contacts and a free connector
containing female contacts. They are primarily intended to provide interconnection
between printed boards using a basic grid of 2,54 mm (0,1 in) as laid down in IEC 97
and round conductor ribbon cable on 1,27 mm (0,05 in) centreline spacing. The fixed
connectors are provided with posts either for solder, press-in or wrapped connections. The
free connectors are provided with non-accessible insulation displacement terminations.
2 Normative references
The following normative documents contain provisions which, through reference in this
text, constitute provisions of this pa rt of IEC 603. At the time of publication, the editions
indicated were valid. All normative documents are subject to revision, and parties to agree-
ments based on this part of IEC 603 are encouraged to investigate the possibility of apply-
ing the most recent editions of the normative documents indicated below. Members of IEC
and ISO maintain registers of currently valid International Standards.
IEC 68-1: 1988, Environmental testing - Part 1: General and guidance
Amendment No. 1 (1992)
Environmental testing - Part 2: Tests - Test Ke: Corrosion tests in
IEC 68-2-60: 1990,
artificial atmosphere at very low concentration of polluting gas(es)
97: 1991, Grid systems for printed circuits
IEC
rt 1: Solderless wrapped connections -
IEC 352-1: 1983, Solderless connections - Pa
General requirements, test methods and practical guidance
Solderless connections - Part 4: Solderless non-accessible insulation
IEC 352-4: 1994,
displacement connections - General requirements, test methods and practical guidance
5: Solderless press-in connections -
IEC 352-5: 1995, Solderless connections - Pa rt
General requirements, test methods and practical guidance

- 9 -
603-13 © I EC:1995
IEC 410: 1973, Sampling plans and procedures for inspection by attributes
Electromechanical components for electronic equipment; basic testing
IEC 512-1: 1984,
rt I: General
procedures and measuring methods - Pa
Amendment No. 1 (1988)
Electromechanical components for electronic equipment; basic testing
IEC 512-2: 1985,
procedures and measuring methods - Part 2: General examination, electrical continuity
and contact resistance tests, insulation tests and voltage stress tests
Electromechanical components for electronic equipment; basic testing
IEC 512-3: 1976,
3: Current-carrying capacity tests
procedures and measuring methods - Pa rt
Electromechanical components for electronic equipment; basic testing
IEC 512-4: 1976,
procedures and measuring methods - Part 4: Dynamic stress tests
Electromechanical components for electronic equipment; basic testing
IEC 512-5: 1992,
procedures and measuring methods - Part 5: Impact tests (free components), static load
tests (fixed components), endurance tests and overload tests
Electromechanical components for electronic equipment; basic testing
IEC 512-7: 1993,
7: Mechanical operating tests and sealing tests
procedures and measuring methods - Pa rt
Electromechanical components for electronic equipment; basic testing
IEC 512-8: 1993,
procedures and measuring methods - Pa rt 8: Connector tests (mechanical) and mech-
anical tests on contacts and terminations
Electromechanical components for electronic equipment; basic testing
IEC 512-9: 1992,
rt 9: Miscellaneous tests
procedures and measuring methods - Pa
Connectors for frequencies below 3 MHz for use with printed boards -
IEC 603-1: 1991,
Part is Generic specification - General requirements and guide for the preparation of
detail specifications, with assessed quality
Amendment No. 1 (1992)
Rules of procedure of the IEC quality assessment system for
IEC QC 001002: 1986,
electronic components (IECQ)
Amendment No. 1 (1992)
Fastener hexagon products - Width across flats
ISO 272: 1982,
Surface roughness - Parameters, their values and general rules for
ISO 468: 1982,
specifying requirements
- 11 -
603-13 ©IEC:1995
3 IEC type designation
Connectors, fixed (board-mounted) and free, with and without strain reliefs and latches
according to this standard shall be designated by the following system.
IEC 603-13 N L N L L
^
Letter denoting
Reference to this
assessment level
specification
B Assessment level B
G Assessment level G
Letter See 5.2.1 A
denoting See 5.2.2 B
the style See 5.3.1 C
Number denoting
performance level PL
1 Performance level PL1
2 Performance level PL2
010 3 Performance level PL3
rformance level PL4
4 Pe
Letter denoting strain relief
and latches
Number of contacts 026
Fixed connector without latches
A
030 (in combination with free connector
without and with strain relief)
Fixed connector with short
B (10,8 mm) latches (in combination
with free connector without strain relief)
Fixed connector with long
C (14,4 mm) latches (in combination with
free connector with strain relief)
Free connector without strain relief
D (in combination with fixed connector
rt latches)
without strain relief or with sho
Male M
Letter denoting Two-part
Free connector with strain relief
style of contact connector
Female F
E (in combination with fixed connector
without latches or with long latches)
Insulation displacement connectors D –
Press-in P –
Solder S – Number denoting contact finish
Wrapped connections W
1 Gold, gold alloy
Not applicable – 0
2 Silver, silver alloy
– 1
Fixed connector, board up to 1,6 mm,
3 Tin, ti n alloy
90° solder termination
Fixed connector, board up to 3,2 mm, _ 2
Letter denoting
90° solder termination
basic style and Letter denoting state of assembling
Fixed connector, mother board up to
number denoting
– 3
_
1.6 mm, straight solder termination
c Complete connector
application of
Fixed connector, mother board up to _
termination
3,2 mm, straight solder termination _
Fixed connector, straight termination – 5
for wrapped connections
_ 6
Fixed connector, 90° for termination
for wrapped connections
_ 7
Free connector, termination for
insulation displacement —
NOTE – "L" stands for letter
Fixed connector, board up to 2,4 mm, _ 8
"N" stands for number
straight press-in termination
Example - Connector style B, having 20 male contacts gold-finished with solder terminations.
Complete fixed connector for boards up to 3,2 mm (0,126 in), straight termination without
latches, with performance level 2 and assessment level G: IEC 603-13-B020MS-4C1A-2G.

- 13 -
603-13 © I EC:1995
4 Common features
Not applicable.
4.1 Isometric view
Strain relief
Printed board
IEC 519194
Figure 1 - Isometric view
603-13 © IEC:1995 - 15 -
4.2 Survey of styles
Table 1 - Survey of styles
Number of contacts
Style
16/20/24/26/30/34/36
4/6/8 10/12/14
40/44/50/52/56/60/64
A Fixed connector;
press-in/solder/wrap Without lateral polarization keys
post
With one lateral With two lateral
B Fixed connector; Without lateral
polarization keys
press-in/solder/wrap polarization keys polarization key
post
With two lateral
Free connector; Without lateral With one lateral
C
polarization slots
polarization slots polarization slot
insulation displacement
termination
NOTE – Style C (free connector) can be mated either with style A or style B (fixed connectors).
5 Dimensions
5.1 General
Dimensions in millimetres are the original dimensions.*
Drawings are shown in third-angle projection. The shape of the connectors may deviate
from those given in the following drawings as long as the specified dimensions are not
influenced.
5.2 Fixed connectors
5.2.1 Fixed connector, style A (central polarization slot only)
Same as style B, but without the lateral polarization keys.
* The inch dimensions of this detail specification are based on a German national standard and are
calculated by mathematic conversion. Differences of dimensions, if any, are caused by double mathematic
conversion.
603-13 © I EC:1995 -17 -
Marking first contact
i + i,
'^ I
♦ } } } ^} } ♦ .}
^
-413f
^ ♦ + ♦ ♦ ♦ ♦ ♦ ♦ t: 2
Marking of contact position
only for information
(1, 2, 3, 4.)
IEC 520/94
NOTE – Figure 2 applies also to fixed connectors, style B, with 4, 6 and 8 contacts.
Figure 2 - Fixed connector, marking
5.2.1.1 Dimensions
See figure 3.
5.2.1.2 Terminations
See table 3.
- 19 -
603-13 ©IEC:1995
5.2.2 Fixed connector, style B (two lateral polarization keys in the connector and
a central polarization slot)
5.2.2.1 Dimensions
first contact
Marking
D
— 0,1 mm
0,004 in
)i É
Style of termination
E^
S-1, S-2, W-6 (see table 3)
ç
EW
Eo
A, a ^ View A.
See detail
E °O
m o
E^
next page
o .-* r m
EE
E ô
+4ô'
E0-`o O.
^
É
i1 N ^ ^ ^-
7 p, O •
ô (.1
t t ^ 1,7e
T t ^ 7
*
^
0 •
0,15 mm
0,006 in
10,16 mm max.
(0,400 in max.
0,2 mm
Y
0,008 in
S yle of termination
2 x
S 3, S-4, W 5, P-8 (see table 3)
P
^
4,1 mm min.
0.1 mm
min.)
(0,15 in
— 0,004 In
2,54 mm
See note 1
0,1 in
See note 2
Marking first contact
13,81 mml
1,27 mm
See note 1
0,150 in
0,050 In
_ I 0,001 mm
I 0,1 mm
x Z-
0,000 04 in
0,004 In
E
E
w v-
oid
E Ç +0
I
2,6
mm E o
0,2 mm M
AI
See detail B, —j I 2 x
N °
10,008 InO I next page +0,004
^
co O
(0,102
in)
O ^ I _ 10,15 mm I Y(
0, 06 in
View A, only for termination
style S-1, S-2, W-6
+0,5
6,6 mm
Shall be suitable
-0,2
for nut M2,5 (ISO 272)
+0,02
(0,260 in)
-0,008
lEC 521194
NOTES
1 Two lateral polarization keys omitted on connectors with 4, 6 and 8 contacts.
2 One lateral polarization key omitted on connectors with 10, 12 and 14 contacts.
Figure 3 - Fixed connector, dimensions

-21 -
603-13 © IEC:1995
E
E
0,635 ± 0,025 mm
oN
O
r
(0,025 ± 0,001 in)
ô o
0,2 mm ^ ô o
• ►
+ +
0,008 in M
o
i* o
Rounded
See note
D tail A
0,06 mm M
fr
0,0024 inO
I^(
Section C-D
or
Detail B
I•IOrTn®I
IEC 522/94
NOTE – Male contact all-over plated to ensure interchangeability.
Figure 4 - Fixed connector, details A and B

- 23 -
603-13 © IEC:1995
Table 2 - Fixed connectors, dimensions
8 D .
Amax. C
Z
Number of
mm Z+ 11,68 mm Z+ 17,78 mm Z+ 7,37 mm
2 ,54 mm x (n/2-1) Z+ 22,14
contacts
(Z+ 0,460 in) (Z+ 0,700 in) (Z+ 0,290 in)
(0,100 in x (n/2-1)) (Z+ 0,872 in)
in mm in
n mm in mm in mm in mm
0,972 14,22 0,560 20,32 0,800 9,91 0,390
04 2,54 0,100 24,68
16,76 0,660 22,86 0,900 12,45 0,490
06 5,08 0,200 27,22 1,072
1,172 19,30 0,760 25,40 1,000 14,99 0,590
08 7,62 0,300 29,76
1,272 21,84 0,860 27,94 1,100 17,53 0,690
10 10,16 0,400 32,30
34,84 1,372 24,38 0,960 30,48 1,200 20,07 0,790
12 12,70 0,500
1,060 33,02 1,300 22,61 0,890
0,600 37,38 1,472 26,92
14 15,24
0,700 39,92 1,572 29,46 1,160 35,56 1,400 25,15 0,990
16 17,78
45,00 1,772 34,54 1,360 40,64 1,600 30,23 1,190
20 22,86 0,900
45,72 1,800 35,91 1,390
1,100 50,08 1,972 39,62 1,560
24 27,94
1,660 48,26 1,900 37,85 1,490
1,200 52,62 2,072 42,16
26 30,48
1,860 53,34 2,100 42,93 1,690
30 1,400 57,70 2,272 47,24
35,56
2,060 58,42 2,300 48,01 1,890
34 40,64 1,600 62,78 2,472 52,32
60,96 2,400 50,55 1,990
36 43,18 1,700 65,32 2,572 54,86 2,160
2,190
70,40 2,772 59,94 2,360 66,04 2,600 55,63
40 48,26 1,900
71,12 2,800 60,71 2,390
44 53,34 2,100 75,48 2,972 65,02 2,560
78,74 3,100 68,33 2,690
60,96 2,400 83,10 3,272 72,64 2,860
81,28 3,200 70,87 2,790
2,500 85,64 3,372 75,18 2,960
52 63,50
3,160 86,36 3,400 75,95 2,990
56 68,58 2,700 90,72 3,572 80,26
91,44 3,600 81,03 3,190
60 73,66 2,900 95,80 3,772 85,34 3,360
3,560 96,52 3,800 86,11 3,390
64 78,74 3,100 100,88 3,972 90,42
5.2.2.2 Terminations
Table 3 - Fixed connectors, terminations
Style of termination
Dimension
W-5* and W-6* P-8**
S-1 and S-3 S-2 and S-4
in mm in
mm in mm in mm
0,189 16 0,630 5,5 0,217
G 3,2 0,126 4,8
0,165 14,5 0,571 4,2 0,165
2,6 0,102 4,2
to IEC 352-1.
* Wrap post wi h diagonal 0,84 mm (0,033 in) to 0,91 mm (0,036 in) according
** Press-in post for hole 1 mm (0,039 in) diameter.

603-13 ©IEC:1995 - 25 -
5.2.3
Latches for fixed connectors, style A and B
Long latches for use with free connectors with strain relief.
Sho rt latches for use with free connectors without strain relief.
Short latches
10,8 mm
(0,425 in)
Detail Y
See note 2
10,5 mm max.
(0,413 in max.)
0,76 mm min.
f•
(0,030 in min.)
Long latches
14,4mm
1,96 mm max.
(0,567 in)
(0,077 in max.)
See note 2
10,5 mm max.
lEC 523194
(0,413 in max.)
NOTES
1 For long latches: 2,8 mm max. (0,110 in max.).
(A dimension of 5,9 mm max. will be permitted for a period of two years from publication of this specifi-
cation. This dimension may result in incompatibility with the corresponding part of the free connector.)
For short latches: 4,5 mm min. (0,177 in min.).
2 The design shall be such that the latches do not move inwards to touch the contacts.
Figure 5 - Fixed connectors, latches

603-13 © I EC:1995 -27-
5.3
Free connectors
5.3.1 Free connector, style C
5.3.1.1 Dimensions
3,8 mm max.
(0,150 in max.)
— 0,1 mm
- 0,004 ini
(1,27 mm'
See note 1 3,81 mm
0,050 in
See note 2 0,150 in
See note 1
c c_
0,001 mm
N I E
0,000 04 in x
o Eô
E
+  E ^
+ + + '''.-+‘.6-77—(5-N-7-4 m^
ô
4.
* il0 _
N
ro° ^p 1
f2,54 mm+
0,1 in
— 0,15 mm
— 0,006 In
Detail B Detail A
A 0,2mm ^
B
0,008 in
A— B
Detail A
A
0,3 mm min.
(0,012 In min.)
0, mm ^I06
Detail B
0,0024 in; 'M^
—1.I
0,8 mm min.
0,06 mm
(0,031 in min.)
0,0024 in
O I^I
1,6 mm min.
(0,063 in min.)
IEC 524/94
NOTES
1 Two lateral polarization slots omitted on connectors with 4, 6 and 8 contacts.
2 One lateral polarization slot omitted on connectors with 10, 12 and 14 contacts.
Figure 6 - Free connectors, dimensions

603-13 © IEC:1995 - 29 -
X
Q
X
E
Ec
Free connector without strain relief
E^
E^
'II
N o'
Marking first contact;
position of first wire
Different clamping
areas suitable for use
with short latches
according to 5.2.3
X
Em
Free connector with strain relief E E
EE
to
o 0
-n
/EC 525194
Figure 7 - Free connectors, strain relief information

-31 -
603-13 © IEC:1995
Table 4 - Free connectors, dimensions
max.
A
umber
Number
2,54 mm x (n/2-1) Z+ 7,32 mm
of contacts
(0,100 in x (n/2-1)) (Z+ 0,288 in)
mm in mm in
n
9,86
04 2,54 0,100 0,388
12,40 0,488
06 5,08 0,200
14,94 0,588
08 7,62 0,300
0,400 17,48 0,688
10 10,16
0,500 20,02 0,788
12 12,70
14 15,24 0,600 22,56 0,888
16 17,78 0,700 25,10 0,988
20 22,86 0,900 30,18 1,188
24 27,94 1,100 35,26 1,388
26 30,48 1,200 37,80 1,488
30 35,56 1,400 42,88 1,688
34 40,64 1,600 47,96 1,888
50,50 1,988
36 43,18 1,700
1,900 55,58 2,188
40 48,26
53,34 2,100 60,66 2,388
50 60,96 2,400 68,28 2,688
63,50 2,500 70,82 2,788
56 68,58 2,700 75,90 2,988
60 73,66 2,900 80,98 3,188
64 78,74 3,100 86,06 3,388
5.3.1.2 Terminations
Insulation displacement termination in accordance with IEC 352-4 (in preparation), appli-
cable to insulation displacement connections made with ribbon cables or single wires
having:
0,4 mm diameter (0,126 mm2) (AWG 26)
Solid conductors:
2) (AWG 28)
Solid conductors: 0,32 mm diameter (0,080 mm

0,25 mm diameter (0,051 mm2) (AWG 30)
Solid conductors:
Stranded conductors: (0,141 mm ) (AWG 26) 7 strands

(0,089 mm2) (AWG 28) 7 strands
Stranded conductors:
Stranded conductors: (0,056 mm ) (AWG 30) 7 strands
NOTE - The maximum permissible temperature of the ribbon cable also limits the maximum operating
temperature of the connector (see 7.1).

603-13 ©IEC:1995 - 33 -
5.4 Mounting information for fixed connectors, styles A and B
5.4.1 Terminations, styles S-1, S-2 and W-6
All holes
See note
0, 05 mm
I0,1
mm 2,8 mm min.
2x
131 0,002 in
0,004 in : (0,110 in min.)
E
Ec
N 0
E c
E W
er
N
4". o
2,54 mm
Position of first
ôô
0,1 in
contact
2,54 mm
n x
0,1 in
D
^
0,1 mm
— 0,004 in
!EC 526194
Figure 8 - Fixed connectors, mounting information
5.4.2 Terminations, styles S-3, S-4, P-8 and W-5
See notes
All holes
1 and 2
005mm
0,1 mm 2,8 mm min.
2x
0,004 in (0,110 in min.) 4, 0,002 in
/
++++
++++
E
E ^.
tD
N
W O
Position of first
rô
contact
2,54 mm
n x
0,1 in
^
0,1 mm
0,004 in
IEC 527194
NOTES
1 Holes for solder terminations 1 ± 0,1 mm (0,039 ± 0,004 in) diameter.
2 Holes for press-in terminations 1 mm (0,039 in) diameter according to IEC 352-5.
Figure 9 - Fixed connectors, mounting information

603-13 © IEC:1995 - 35 -
5.4.3 Termination, style W-5
d i 0,1 mm
2,8 mm min.
2 x
0,004 in
(0,110 in min.)
c
.
É ^
E ^
E c^
m m
^o
C
^
0,1 mm
.0,004 in
!EC 528(94
Figure 10 - Fixed connectors, mounting information
5.4.4 Termination, style W-6
0,1 mm M ( 2,8 mm min.
0,004 in
(0,110 in min.)
C
0.1 mm
0,004 in
/EC 4
Figure 11 - Fixed connectors, mounting information

603-13 © IEC:1995 - 37 -
Table 5 - Fixed connectors, mounting dimensions
B C.
A
Number Z
2 , 54 mm x (n/2-1) Z+ 11,68 mm Z+ 17,78 mm Z+ 6,25 mm
of contacts
(0,100 in x (n/2-1)) (Z+ 0,460 in) (Z+ 0,700 in) (Z+ 0,246 in)
in mm in
n mm in mm mm in
04 2,54 0,100 14,22 0,560 20,32 0,800 8,79 0,346
06 5,08 0,200 16,76 0,660 22,86 0,900 11,33 0,446
08 7,62 0,300 19,30 0,760 25,40 1,000 13,87 0,546
10 10,16 0,400 21,84 0,860 27,94 1,100 16,41 0,646
12 12,70 0,500 24,38 0,960 30,48 1,200 18,95 0,746
14 15,24 0,600 26,92 1,060 33,02 1,300 21,49 0,846
16 17,78 0,700 29,46 1,160 35,56 1,400 24,03 0,946
20 22,86 0,900 34,54 1,360 40,64 1,600 29,11 1,146
24 27,94 1,100 39,62 1,560 45,72 1,800 34,19 1,346
26 30,48 1,200 42,16 1,660 48,26 1,900 36,73 1,446
30 35,56 1,400 47,24 1,860 53,34 2,100 41,81 1,646
58,42
34 40,64 1,600 52,32 2,060 2,300 46,89 1,846
2,160 60,96 2,400
36 43,18 1,700 54,86 49,43 1,946
40 48,26 1,900 59
...
