EUROPEAN STANDARD
EN 50411-2-5
NORME EUROPÉENNE
May 2009
EUROPÄISCHE NORM
ICS 33.180.20
English version
Fibre organisers and closures to be used
in optical fibre communication systems -
Product specifications -
Part 2-5: Sealed closures for air blown fibre microduct,
type 1, for category S & A
Organiseurs et boîtiers de fibres à utiliser LWL-Spleißkassetten und -Muffen
dans les systèmes de communication für die Anwendung in LWL-
par fibres optiques - Kommunikationssystemen -
Spécifications de produits - Produktnormen -
Partie 2-5: Boîtiers scellés Teil 2-5: Abgedichtete LWL-Muffen
pour microconduits de fibres soufflées für ABF-Mikrorohre, Bauart 1,
à l'air comprimé, pour les catégories S & A für die Kategorien S und A

This European Standard was approved by CENELEC on 2008-12-01. CENELEC members are bound to comply
with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard
the status of a national standard without any alteration.

Up-to-date lists and bibliographical references concerning such national standards may be obtained on
application to the Central Secretariat or to any CENELEC member.

This European Standard exists in three official versions (English, French, German). A version in any other
language made by translation under the responsibility of a CENELEC member into its own language and notified
to the Central Secretariat has the same status as the official versions.

CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Cyprus, the
Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia,
Lithuania, Luxembourg, Malta, the Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain,
Sweden, Switzerland and the United Kingdom.

CENELEC
European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung

Central Secretariat: Avenue Marnix 17, B - 1000 Brussels

© 2009 CENELEC - All rights of exploitation in any form and by any means reserved worldwide for CENELEC members.
Ref. No. EN 50411-2-5:2009 E
Foreword
This European Standard was prepared by the Technical Committee CENELEC TC 86BXA, Fibre optic
interconnect, passive and connectorised components.
The text of the draft was submitted to the formal vote and was approved by CENELEC as EN 50411-2-5 on
2008-12-01.
The following dates were fixed:
– latest date by which the EN has to be implemented
at national level by publication of an identical
national standard or by endorsement (dop) 2009-12-01
– latest date by which the national standards conflicting
with the EN have to be withdrawn (dow) 2011-12-01
__________
- 3 - EN 50411-2-5:2009
Fibre organisers and closures to be used in optical fibre communication systems –
Product specifications
Sealed closures for air blown fibre microduct, type 1, for category S & A
Description Performance
Construction: Applications:
Multiple ported closure
Cable management: Microduct , protected microduct, Blown optical fibre cable
ducts and/or sub-ducts. networks:
Cable seals: Heat activated and or cold applied for underground: EN 61753-1 Category S
for aerial: EN 61753-1 Category A
Related documents:
EN 60793-2-50 Optical fibres – Part 2-50: Product specifications – Sectional specification for class B single-
mode fibres (IEC 60793-2-50)
EN 60794-5 Optical fibre cables – Part 5: Sectional specification – Microduct cabling for installation by
blowing (IEC 60794-5)
EN 61300 series Fibre optic interconnecting devices and passive components – Basic test and measurement
procedures (IEC 61300 series)
EN 61753-1 Fibre optic interconnecting devices and passive components performance standard – Part 1:
General and guidance for performance standards (IEC 61753-1)
EN 61756-1 Fibre optic interconnecting devices and passive components – Interface standard for fibre
management systems – Part 1: General and guidance (IEC 61756-1)
EN 61758-1 Fibre optic interconnecting devices and passive components – Interface standard for closures –
Part 1: General and guidance (IEC 61758-1)
ETSI EN 300 019 series Environmental Engineering (EE) – Environmental conditions and environmental tests for
telecommunications equipment
Construction: Duct and cable port entries and dimensions
(Direct burial or jointing pit mounted)

Closure Max sizes of Closure Maximum
protected designs physical
microduct (Type and/or dimensions in mm
cables sub-group) Length L
mm Width W
Depth D
Inline closures
112 Type 1a 975 x 394 x 330
Inline
(multiple 35 Type 2a 648 x 274 x 152
ports)
26 Type 2b 828 x 274 x 401
Tee closures
Single port
32 300 x 200 x 100
Tee ends
(single and
double port) Double port
50 720 x 435 x 210
ends
30 Rectangular 710 x 515 x 148
Pan
(circular or 40 Circular 450 x 350 x 700
rectangular)
Pan closures 40 Elliptical 520 x 450 x 300

19 Type 1a 600 x 185 x 265
Dome
(single end 26 Type 1b 750 x 270 x 310
entry)
35 Type 1c 1 050 x 275 x 310
Dome closures
Single end entry Central split access

Contents
