EN 3372-005:2007
(Main)Aerospace series - Connectors, electrical, circular, medium and high contact density, scoop-proof with bayonet coupling, operating temperatures - 65 °C to 175 °C or 200 °C continuous - Part 005: Receptacle, hermetic, round flange, solder mounting - Product standard
Aerospace series - Connectors, electrical, circular, medium and high contact density, scoop-proof with bayonet coupling, operating temperatures - 65 °C to 175 °C or 200 °C continuous - Part 005: Receptacle, hermetic, round flange, solder mounting - Product standard
This standard specifies the characteristics of hermetic receptacles with round flange attached by soldering in the family of circular electrical connectors coupled by bayonet ring.
It applies to class defined in Table 3.
For plugs and protective covers, see EN 3372 008 and EN 3372 006 respectively.
