EN 3372-002:2007 is a CEN aerospace standard that specifies the performance and contact arrangements for circular electrical connectors with scoop‑proof inserts and bayonet coupling, intended for medium and high contact density applications. The family covers connectors with continuous operating temperatures from −65 °C up to 175 °C or 200 °C, and is described as similar to MIL‑DTL‑38999 series I (but not intermateable). The standard defines class codification, compatibility, electrical, climatic and mechanical requirements, and allowable cable/contact sizes.
Key topics and technical requirements
- Scope & classes: Connector classes (W, F, Y) identify materials, finish and max operating temperature:
- W - cadmium‑plated aluminium (olive drab), max 175 °C
- F - nickel‑plated aluminium, max 200 °C
- Y - hermetic stainless steel receptacle, max 200 °C
- Mechanical design: bayonet ring coupling, scoop‑proof inserts, defined housing sizes and a broad set of contact arrangements (detailed front‑view patterns for dozens of configurations).
- Electrical requirements:
- Defined withstand voltages for Ratings M, N, I, II at sea level and specified reduced values at altitude.
- Insulation resistance: ≥ 5 000 MΩ at ambient temperature.
- Housing continuity limits and shielding effectiveness (100 MHz–1 GHz attenuation specified).
- Maximum permissible current set per contact and cable size; testing/derating referenced to EN 2591‑209 and EN 3155 series.
- Climatic and environmental: operating temperatures (−65 °C to specified maxima); corrosion/fluid resistance referenced to EN 3372‑001.
- Durability: mechanical endurance specified as 500 mating cycles.
- Compatibility rules: plug/receptacle and protective cover combinations, permissible cable outer diameters per contact size, and polarization options.
Applications and users
EN 3372‑002 is intended for use in aerospace electrical interconnections where reliable, rugged circular connectors are required:
- Aerospace OEMs and integrators selecting connectors for airframe, avionics and power systems
- Connector and harness designers specifying contact arrangements, current ratings and environmental performance
- Procurement and quality engineers ensuring component compliance
- Test laboratories performing electrical, climatic and mechanical qualification
- Maintenance and installation teams using the defined cable/outlet accessories and assembly tooling
Related standards
- EN 3372‑001, EN 3372‑003 … EN 3372‑011 (product standards in the same series)
- EN 3155 (electrical contact product standards)
- EN 2591‑209 (current/temperature derating)
- EN 3197 (installation of aircraft interconnection systems)
- EN 4529‑002 (sealing plugs)
Keywords: EN 3372‑002:2007, aerospace connectors, circular connectors, bayonet coupling, scoop‑proof, contact arrangements, operating temperature, hermetic connectors, connector performance.
