International Standard ISO 25178-603:2025(en)
Geometrical product specifications (GPS) — Surface
texture: Areal —
Part 603:
Design and characteristics of non-contact (phase shifting
interferometry) instruments
1 Scope
This document specifies the design and metrological characteristics of phase shifting interferometry (PSI)
instruments for the areal measurement of surface topography. Because surface profiles can be extracted
from areal surface topography data, the methods described in this document are also applicable to profiling
measurements.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content constitutes
requirements of this document. For dated references, only the edition cited applies. For undated references,
the latest edition of the referenced document (including any amendments) applies.
ISO 25178-600:2019, Geometrical product specifications (GPS) — Surface texture: Areal — Part 600:
Metrological characteristics for areal topography measuring methods
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 25178-600 and the following apply.
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at https:// www .electropedia .org/
3.1
phase shifting interferometry
PSI
method for measuring areal surface topography from the surface height dependence of an interferometric
signal, whereby the interference phase is estimated from two or more digitized interference images acquired
over a sequence of controlled phase shifts
Note 1 to entry: In this document, PSI refers specifically to methods that employ time-dependent phase shifting
mechanisms (3.8). Other methods of acquiring and analysing interference patterns, including parallel or instantaneous
methods using polarization or carrier fringes, are outside the scope of this document.
Note 2 to entry: ISO/TR 14999-2:2019, 6.4.4, provides further information on synchronous detection and PSI.
Note 3 to entry: PSI instruments are most often employed for measurements of optically smooth surfaces, as defined
in ISO 25178-600:2019, 3.4.4.
ISO 25178-603:2025(en)
3.2
interference objective
microscope objective adapted with a reference path and reference surface for the generation of interference
patterns superimposed on the image of a sample surface
Note 1 to entry: Interference objectives are used in PSI (3.1) instruments that are configured as microscopes. Other
configurations of PSI instruments, particularly for fields of view larger than about 10 mm, can have interferometer
designs that are not based on microscope objectives.
Note 2 to entry: Annex A provides example types of interference objective in common usage.
3.3
linear phase shifting interferometry
linear PSI
PSI (3.1) method that relies on sampling an interference signal over a sequence of evenly spaced interference
phase shifts
3.4
sinusoidal phase shifting interferometry
sinusoidal PSI
PSI (3.1) method that relies on sampling an interference signal over a sequence of sinusoidally-varying
interference phase shifts
3.5
phase shifting interferometry algorithm
PSI algorithm
algorithm for the data processing procedure, including the mathematical equations, used to calculate the
topography from two or more digitized interference images acquired over a sequence of controlled phase shifts
3.6
equivalent wavelength
λ
eq
constant value equal to twice the change in surface topography height that produces one full cycle of
interference phase change (equivalent to one interference fringe)
Note 1 to entry: The equivalent wavelength is a definition in the context of PSI (3.1) for the measurement
optical wavelength, defined as the “effective value of the wavelength of the light used to measure a surface” in
ISO 25178-600:2019, 3.3.3.
Note 2 to entry: This definition corresponds to the measurement configuration described in Annex A. There can be
different definitions for other measurement configurations.
Note 3 to entry: The equivalent wavelength can be calculated from contributions such as the light source wavelength
together with other factors related to the instrument design, or can be calibrated using a procedure corresponding to
the definition of the equivalent wavelength.
3.7
phase change on reflection
PCOR
change in interference phase attributable to the optical properties of a sample surface independent of
surface height
Note 1 to entry: The PCOR is most relevant to non-dielectric materials such as metals and surfaces that have thin
layers of differing materials producing thin-film effects.
Note 2 to entry: The PCOR can vary over the sample surface comprised of an optically non-uniform material (see
ISO 25178-600:2019, 3.4.6).
ISO 25178-603:2025(en)
3.8
phase shifting mechanism
device that imparts controlled phase shifts to an interference signal
Note 1 to entry: The phase shift mechanism can generate phase shifts by an axial scan motion of the part or of the
interference objective (see ISO 25178-607:2019, 3.5), or other methods, such as displacement of the reference surface.
3.9
phase unwrapping algorithm
algorithm used to extend the surface topography measurement range beyond a single cycle of interference
phase (equivalent to one interference fringe), by removing excess multiples of 2π between the phase values
of neighbouring image points
Note 1 to entry: ISO/TR 14999-2:2019, 6.6, provides further details regarding phase unwrapping.
3.10
fringe-order error
2π error
error in the identification of the correct fringe when calculating relative
heights using interference phase for surface topography calculations
Note 1 to entry: Fringe-order errors are integer multiples of one-half the equivalent wavelength (3.6) in height.
4 Instrument requirements
An instrument according to this document shall perform areal surface topography measurements of a sample
surface using PSI. The instrument can comprise an interference objective or alternative interferometer
assembly and a phase shifting mechanism. The instrument shall acquire data using linear PSI, sinusoidal PSI
or other phase shifting patterns consistent with the definition of PSI. The instrument shall convert acquired
data to an areal topography using a PSI algorithm and a calculated or assumed equivalent wavelength. A
phase unwrapping algorithm shall be employed as needed to reduce fringe-order error.
Figure 1 shows the information flow between these elements for a PSI microscope, from the real surface to
a scale-limited surface. Example PSI hardware, techniques and error sources are given in Annexes A and B.

ISO 25178-603:2025(en)
Key
measurand
operator with intended modification
operator without intended modification
Figure 1 — Information flow concept diagram for PSI
5 Metrological characteristics
The standard metrological characteristics for areal surface texture measuring instruments specified in
ISO 25178-600 shall be considered when designing and calibrating the instrument.
Annex B describes sources of measurement error that can influence the calibration result.
6 Design features
Standard design features described in ISO 25178-600 shall be considered in the design.
Annex A provides examples of specific design features of PSI instruments.
7 General information
The relationship between this document and the GPS matrix model is given in Annex C.

ISO 25178-603:2025(en)
Annex A
(informative)
Principles of PSI instruments for areal surface topography
measurement
A.1 General
PSI is a mature technology and there are substantial resources in existing ISO documents listed in the
[9][10][11]
bibliography and in the published literature regarding instrument design and theory of operation.
[12][13]
This annex provides a summary with the goal of clarifying terms and definitions as well as some of
the influence quantities that contribute to the metrological characteristics of PSI.
A.2 Instrument design
PSI instruments for areal surface topography measurement comprise a variety of designs. The testing of
optical components such as lenses, mirrors and prisms often relies on the laser Fizeau geometry, used for
[14][15]
polished surfaces from a few millimetres to over a metre in size. This annex describes the use of PSI
together with light microscopy for areal surface topography using a mechanical phase shifting mechanism.
Refer to ISO/TR 14999-1 for general terms and definitions related to light interferometry and to ISO 10934
for general terms and definitions related to light microscopy.
Figure A.1 shows an interference microscope with imaging optics. The phase shifting mechanism imparts a
controlled phase shift by means of an axial scan ζ of the interference objective towards the sample surface
along the z-axis direction (see ISO 25178-607:2019, 3.5). The sample surface lies nominally within the plane,
consistent with the coordinate system defined in ISO 25178-600:2019, 3.1.2, and is imaged to the electronic
camera. The measurement principle is to determine the surface height at each point on the sample surface
by analysis of multiple interference patterns acquired during a sequence of controlled phase shifts.

ISO 25178-603:2025(en)
Key
A workpiece E phase shifting mechanism
B light source F electronic camera
C beam splitter G data acquisition and control
D interference objective H interference pattern
ζ scanning motion
Figure A.1 — Interference microscope for PSI measurements of the areal surface topography
Light sources for interference microscopy are usually spatially incoherent, exemplified by incandescent lamps
or white-light-emitting diodes (see ISO 10934:2020, 3.1.73). The light source can include interchangeable
filters for adjusting the illumination spectrum (see ISO 10934:2020, 3.1.55). In Figure A.1, the light source is
shown imaged into the objective pupil in the epi-illumination Köhler geometry (see ISO 10934:2020, 3.1.73.2
and 3.1.73.3). Many instruments have adjustable light stops for controlling the size of the illumination field
[9]
as well as the illumination aperture (see ISO 10934:2020, 3.1.38.6).
PSI instruments use interference objectives in place of conventional microscope objectives defined in
ISO 10934:2020, 3.1.106. Typically these objectives are compatible with extended, incoherent light sources.
[9] [16][17]
Figure A.2 shows two common types of interference objective, the Michelson and Mirau type. Other
[18][19]
designs in common use for PSI include the Linnik objective, and the Zygo Wide Field (ZWF) objective.
[20]
Table A.1 provides example specifications, including the lateral resolution according to the Sparrow
criterion for a wavelength of 570 nm (see ISO 25178-600:2019, 3.3.9).
Cameras for the visible wavelengths can be of the charge-coupled device (CCD) or complementary metal-
oxide semiconductor (CMOS type), with a format ranging from 300 000 pixels to over 4 million pixels.
Camera selection involves not only field size and number of pixels, but also the acquisition speed, response
linearity, quantum well depth, digitization resolution and the ability to shutter electronically. The net effect
of the camera, optics and data processing on the topographic lateral resolution is often summarized in the
instrument transfer function (ITF), defined in ISO 25178-600:2019, 3.1.19. See also References [21], [22],
[23] and [24].
Adjustments upwards or downwards of the position of the objective or a sample stage (not shown in
Figure A.1) bring the test surface into focus (see ISO 10934:2020, 3.1.65). Part setup usually requires a
nominal adjustment of both focus and tip/tilt, although automation can complete some or all these steps
(see, for example, autofocus, defined in ISO 10934:2020, 3.2.4).

ISO 25178-603:2025(en)
a) Michelson objective b) Mirau objective
Key
A lens
B reference surface
C beam splitter
D workpiece
Figure A.2 — Example types of interference microscope objectives for PSI measurements
Table A.1 — Example characteristics of interference objectives for PSI
Optical lateral reso-
Numerical aperture
lution
Magnification Type
A µm
N
1,4× ZWF 0,04 7,13
2,75× Michelson 0,08 3,56
5,5× Michelson 0,15 1,90
10× Mirau 0,30 0,86
50× Mirau 0,55 0,47
100× Mirau 0,85 0,34
ISO 25178-603:2025(en)
A.3 PSI theory of operation
[9][25][26]
Following a two-beam interference analysis, the interference signal at the camera for an individual
surface point of height z at a position x, y is as shown in Formula (A.1):
II=+ I cos θϕ−+γ (A.1)
()
DC AC
Where I and I are fixed coefficients, the surface-height dependent phase θ for an equivalent wavelength
DC AC
λ is as shown in Formula (A.2):
eq
z
θ =4π (A.2)
λ
eq
The phase shift imparted by a movement of the reference mirror is as shown in Formula (A.3):
ζ
ϕ=4π (A.3)
λ
eq
γ is a phase offset that is independent of z and ζ . The height is calculated from the detected phase as shown
in Formula (A.4):
λ
eq
z= (A.4)
4π
The interference fringes correspond to lines of equal intensity and follow the surface topography as
contours of equal surface height z. These fringes appear at intervals of 2π, which is equivalent in height to
one-half the equivalent wavelength λ , which for low numerical aperture systems is approximately equal to
eq
the mean value of the source emission wavelength. The phase offset γ in Formula (A.1) relates among other
factors to the reflection and transmission properties of the in
...
