EN 15288-1:2008+A1:2010

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.$Schwimmbäder - Teil 1: Sicherheitstechnische Anforderungen an Planung und BauPiscines - Partie 1 : Exigences de sécurité pour la conceptionSwimming pools - Part 1: Safety requirements for design97.220.10Športni objektiSports facilitiesICS:Ta slovenski standard je istoveten z:EN 15288-1:2008+A1:2010SIST EN 15288-1:2008+A1:2010en,fr,de01-december-2010SIST EN 15288-1:2008+A1:2010SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 15288-1:2008+A1
September 2010 ICS 97.220.10 Supersedes EN 15288-1:2008English Version
Swimming pools - Part 1: Safety requirements for design
Piscines - Partie 1 : Exigences de sécurité pour la conception
Schwimmbäder - Teil 1: Sicherheitstechnische Anforderungen an Planung und Bau This European Standard was approved by CEN on 25 July 2008 and includes Amendment 1 approved by CEN on 9 August 2010.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2010 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 15288-1:2008+A1:2010: ESIST EN 15288-1:2008+A1:2010

March 2011. Attention is drawn to the possibility that some of the elements of this document may be the subject of patent rights. CEN [and/or CENELEC] shall not be held responsible for identifying any or all such patent rights. This document includes Amendment 1, approved by CEN on 2010-08-09. This document supersedes EN 15288-1:2008. The start and finish of text introduced or altered by amendment is indicated in the text by tags !". This standard EN 15288 "Swimming pools" consists of the following parts:  Part 1: Safety requirements for design  Part 2: Safety requirements for operation According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom. SIST EN 15288-1:2008+A1:2010

This European Standard has limited application to classified pools which consist of segregated areas of rivers, lakes or the sea but should be followed where relevant. 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 1838, Lighting applications — Emergency lighting EN 13451-1:2001, Swimming pool equipment — Part 1: General safety requirements and test methods EN 13451-2, Swimming pool equipment — Part 2: Additional specific safety requirements and test methods for ladders, stepladders and handle bends EN 13451-8:2001, Swimming pool equipment — Part 8: Additional specific safety requirements and test methods for leisure water features ISO 7010, Graphical symbols — Safety colours and safety signs — Safety signs used in workplaces and public areas
HD 384.7.702 S2, Electrical installations of buildings — Part 7: Requirements for special installations or locations; Section 702: Swimming pools and other basins (IEC 60364-7-702:1997, modified) 3 Terms and definitions For the purposes of this document, the following terms and definitions apply. 3.1 pool/swimming pool facility, with one or more water areas, intended for swimming, leisure or other water based physical activities 3.2 indoor swimming pool one or more constructed water areas for bathing enclosed in a building, covered by a roof (fixed or moveable) 3.3 outdoor swimming pool one or more constructed open-air water areas for bathing 3.4 private use use of an installation designated solely for the owner's/proprietor's/operator's family and guests including the use connected with renting houses for family use SIST EN 15288-1:2008+A1:2010

 pools Type 2;  pools of private use according to 3.4. 5 Safety related design factors and requirements 5.1 General
The requirements of clause 5 refer to pools which are intended for public use within a defined classification. Optional application of requirements to specific types is explained in the related paragraphs. The requirements apply as far as the selected items are present in the swimming pool. As safe operation is influenced by safe design, the design shall take into account the facility’s use, the activity, planned occupancy and its control. Where minimum requirements are given for different types, the designer shall consider the kind of activity foreseen and, should it be more similar to those of another type, refer to the most severe requirements. The occupancy ratio shall be defined at the design stage as the sum of the number of users: a) generated by the water related areas/activities; b) plus the number of users generated by other areas/activities. NOTE 1 A typical occupancy ratio according to a) for swimming pools Type 1, mainly used for swimming and teaching swimming, would be a minimum of 3 m² of water area per bather. As swimming and water-related activities carry an inherent risk (e.g. users have bare feet and wear only bathing costumes), the need for specific design requirements shall always be considered. Facilities designed to meet specific needs or programmes (e.g. competitions, special activities, events) require special consideration. Also at the design stage, the needs of the following shall be considered: c) special users (see Bibliography, e.g. with disabilities); d) special installations (e.g. technologies to detect users in a potential risk of drowning video supervision of pool surrounds and/or other areas). Design construction and operation risk assessment shall be conducted for any refurbishment or alteration work. The assessments have to be developed, updated and implemented as and when required to suit the work stages and any relevant occurrences. NOTE 2 A review at fixed intervals has proved to be effective. Requirements and advice of the following chapters should be tested for relevance during the analysis. 5.2 Layout The layout of a facility shall be considered in terms of interaction between its components and between components and users. Particular attention shall be paid to the intended circulation routes and to the likely behaviour of users. SIST EN 15288-1:2008+A1:2010

Wherever possible, abrupt changes in floor level shall be avoided, particularly in barefoot areas. Single steps on the circulation routes shall: a) have a height ≤ 250 mm, with the riser not open; a height ≤ 180 mm is recommended; b) have the edge marked by contrasting colour; c) have a slip-resistant finish complying with relevant standards/regulations. Staircases shall comply with relevant standards. Where ramps on the circulation routes are used, they shall: d) have an inclination ≤ 8 %; an inclination 5 % to 6 % is recommended; e) have a slip-resistant finish complying with relevant standards/regulations; f) be obviously marked at the beginning and end. Circulation routes shall be designed to ensure a free flow of users, avoiding congestion points, constrictions and obstructions. Service accesses should be provided separately to general circulation routes (e.g. direct access from the outside). To prevent ponding in the barefoot areas, floors shall have a suitable and effective draining system. The inclination in direction of the drains shall be between 2 % and 5 %. With an inclination > 3 % particular attention shall be paid to the slip-resistance and to the opportunity to foresee handrails especially for long ramps. 5.5.3 Emergency routes Design of emergency routes shall comply with relevant regulations, but taking into account also the presence of barefoot users. SIST EN 15288-1:2008+A1:2010
...
