EN 4057-401:2006

Overview

EN 4057-401:2006 is a European Standard developed by CEN that specifies the test methods for assessing the loop tensile strength of cable ties used in aerospace harnesses. This standard is a crucial part of the aerospace series of standards concerning cable ties for harness applications, ensuring reliability and safety in aerospace electrical systems. It is intended to be used in conjunction with EN 4057-100, which covers general test methods for aerospace cable ties.

The standard defines the procedure to determine the force required to cause failure in cable tie loops designed for securing harnesses in aerospace environments. Accurate measurement of loop tensile strength is essential to guarantee that cable ties withstand mechanical stresses during aircraft operation.

Key Topics

• Scope of EN 4057-401: Specifies test procedures to determine the force at failure of cable ties used for aerospace harnesses.
• Applicability: Designed for aerospace industry applications where the integrity of cable harnesses is critical.
• Test Apparatus:
  • Tensile tester with constant jaw separation speed (25 ± 2.5 mm/min).
  • Split mandrel fixtures of specific diameters based on cable tie lengths (<127 mm and >127 mm).
  • Steel mandrels ensuring a smooth, burr-free surface.
• Test Procedure:
  • Specimens are applied to the mandrel using qualified application tools.
  • Cable tie heads must be positioned on the mandrel split line.
  • Tensile testing is performed by separating the jaws at the specified rate until the tie breaks or the locking mechanism releases.
• Requirements:
  • The minimum force to failure must comply with thresholds defined in the associated product standard.
• Relation to EN 4057-100: EN 4057-401 is part of an integrated testing framework and should be used alongside the general methods outlined in EN 4057-100.

Applications

EN 4057-401 is vital for manufacturers, quality assurance professionals, and design engineers working within the aerospace industry. Its practical applications include:

• Quality Control: Ensuring cable ties used in aerospace harnesses meet strict mechanical strength requirements to avoid failure during service.
• Product Development: Validating the design and material selection of cable ties for enhanced durability and reliability.
• Compliance and Certification: Meeting regulatory and customer demands for aerospace component qualification.
• Safety Assurance: Preventing harness failures that could compromise electrical and system integrity on aircraft.
• Maintenance and Inspection Protocols: Providing baseline data to assess in-service cable tie performance and replacement needs.

Related Standards

• EN 4057-100: Aerospace series - Cable ties for harnesses - Test methods - Part 100: General test methods for aerospace cable ties, forming the foundational procedures combined with EN 4057-401.
• Additional regional aerospace and electrical harness standards may complement EN 4057-401 to ensure holistic system integrity.
• Relevant internal aerospace industry quality standards and process documents that reference EN 4057-401 for testing requirements.

Keywords: EN 4057-401, aerospace cable ties, loop tensile strength, cable harness test methods, aerospace standards, cable tie tensile testing, CEN aerospace standards, aerospace electrical systems, cable tie failure force, harness safety testing.
