EN 1714:1997/A2:2003

EN 1714:1997/A2:2003 is a amendment published by the European Committee for Standardization (CEN). Its full title is "Non-destructive testing of welds - Ultrasonic testing of welded joints". This standard covers: This European Standard specifies methods for the manual ultrasonic examination of fusion welded joints in metallic materials equal to and above 8 mm thick which exhibit low ultrasonic attenuation (especially that due to scatter). It is primarily intended for use on full penetration welded joints where both the welded and parent material are ferritic. Where specified and appropriate, techniques may also be used : - on materials other than those stated ; - on partial penetration welds ; - with automated equipment by agreement between the contracting parties. Where material dependent ultrasonic values are specified in this standard they are based on steels having an ultrasonic sound velocity of 5920 ñ 50 m/s for longitudinal waves, and 3255 ñ 30 m/s for transverse waves. This is to be taken into account when examining materials with a different velocity. The standard specifies four examination levels, each corresponding to a different probability of detection of imperfections. Guidance on the selection of examination levels A, B and C is given in annex A. The requirements of the fourth examination level, which is intended for special applications, are in accordance with the general requirements of this standard and as agreed between the contracting parties. This standard, by agreement between the contracting parties, permits assessment of indications, for acceptance purposes, by either of the following methods : 1) Evaluation based primarily on length and echo amplitude of the signal indication ; 2) Evaluation based on characterization and sizing of the indication by probe movement methods.

This European Standard specifies methods for the manual ultrasonic examination of fusion welded joints in metallic materials equal to and above 8 mm thick which exhibit low ultrasonic attenuation (especially that due to scatter). It is primarily intended for use on full penetration welded joints where both the welded and parent material are ferritic. Where specified and appropriate, techniques may also be used : - on materials other than those stated ; - on partial penetration welds ; - with automated equipment by agreement between the contracting parties. Where material dependent ultrasonic values are specified in this standard they are based on steels having an ultrasonic sound velocity of 5920 ñ 50 m/s for longitudinal waves, and 3255 ñ 30 m/s for transverse waves. This is to be taken into account when examining materials with a different velocity. The standard specifies four examination levels, each corresponding to a different probability of detection of imperfections. Guidance on the selection of examination levels A, B and C is given in annex A. The requirements of the fourth examination level, which is intended for special applications, are in accordance with the general requirements of this standard and as agreed between the contracting parties. This standard, by agreement between the contracting parties, permits assessment of indications, for acceptance purposes, by either of the following methods : 1) Evaluation based primarily on length and echo amplitude of the signal indication ; 2) Evaluation based on characterization and sizing of the indication by probe movement methods.

EN 1714:1997/A2:2003 is classified under the following ICS (International Classification for Standards) categories: 25.160.40 - Welded joints and welds. The ICS classification helps identify the subject area and facilitates finding related standards.

EN 1714:1997/A2:2003 has the following relationships with other standards: It is inter standard links to EN ISO 17640:2010, EN 1714:1997. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.

EN 1714:1997/A2:2003 is associated with the following European legislation: EU Directives/Regulations: 97/23/EC; Standardization Mandates: M/071. When a standard is cited in the Official Journal of the European Union, products manufactured in conformity with it benefit from a presumption of conformity with the essential requirements of the corresponding EU directive or regulation.

EN 1714:1997/A2:2003 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
