EN 28430-1:1992

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Widerstandspunktschweißen - Elektrodenhalter - Teil 1: Kegelige Befestigung 1:10 (ISO 8430-1:1988)Soudage par points par résistance - Porte-électrodes - Partie 1: Cône de fixation 1:10 (ISO 8430-1:1988)Resistance spot welding - Electrode holders - Part 1: Taper fixing 1:10 (ISO 8430-1:1988)25.160.30Varilna opremaWelding equipmentICS:Ta slovenski standard je istoveten z:EN 28430-1:1992SIST EN 28430-1:1999en01-december-1999SIST EN 28430-1:1999SLOVENSKI
STANDARD
INTERNATIONAL STANDARD - = - - = = 1 -- =m Z Z I I Si 1s = = X 2 Z z INTERNATIONAL ORGANIZATION FOR STANDARDIZATION ORGANISATION INTERNATIONALE DE NORMALISATION MEXP(YHAPOAHAF1 OPTAHM3A~Mfl l-l0 CTAH,QAPTM3A~MM Resistance spot welding - Electrode holders - Part 1 : Taper fixing 1 : 10 Soudage par points par rbsistance - Porte-blectrodes - Partie 7 : C6ne de fixation 7 : 70 ISO 84304 First edition 1988-12-01 Reference number ISO 8430-1 : 1988 (E) SIST EN 28430-1:1999

ISO 8430-1 :1988 EI Foreword ISO (the International Organization for Standardization) is a worldwide federation of national Standards bodies (ISO member bedies). The work of preparing International Standards is normally carried out through ISO technical committees. Esch member body interested in a subject for which a technical committee has been established has the right to be represented on that committee. International organizations, govern- mental and non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization. Draft International Standards adopted by the technical committees are circulated to the member bodies for approval before their acceptance as International Standards by the ISO Council. They are approved in accordance with ISO procedures requiring at least 75 % approval by the member bodies voting. International Standard ISO 8430-1 was prepared by Technical Committee ISO/TC 44, Welding and allied processes. ISO 8430 consists of the following Parts, welding - Electrode holders : under the general title Resistance - Part 1: Taper fixing I : 10 Part 2: Morse taper fixing - Part 3: Parallel shank fixing for end thrust International Organkation for Standardkation, 1988 spot Printed in Switzerland SIST EN 28430-1:1999

INTERNATIONAL STANDARD ISO 8430-1 : 1988 (E) Resistance spot welding - Electrode holders - Part 1 : Taper fixing 1 : 10 1 Scope This part of ISO 8430 specifies the dimensions and tolerantes of resistance spot welding electrode holders (type AI without offset and with the facility for cable clamping, and where a male taper 1 : 10 is used to fix the holder directly to the welding cylinder in multiple spot welding equipment. 2 Normative references The following Standards contain provisions which, through reference in this text, constitute provisions of this part of ISO 8430. At the time of publication, the editions indicated were valid. All Standards are subject to revision, and Parties to agreements based on this patt of ISO 8430 are encouraged to in- vestigate the possibility of applying the most recent
...
