EN 746-2:1997

(Main)

Industrial thermoprocessing equipment - Part 2: Safety requirements for combustion and fuel handling systems

Industrial thermoprocessing equipment - Part 2: Safety requirements for combustion and fuel handling systems

This Part of EN 746 applies to all combustion and fuel handling equipment used in industrial thermoprocessing equipment which meets the definition for machinery given in 3.1 of EN 292-1:1991, referred to hereafter as "equipment", e.g. furnaces, kilns, ovens, heating systems such as salt baths and melting tanks, and equipment such as integrated burners and torches used in casting machines, ladle heating etc.  It applies to the handling of fuel immediately adjacent to the equipment but downstream of and including the main plant manually operated fuel shut off valve. It specifies the list of hazards, the safety requirements and associated measures as well as the user instructions relating to fuel handling and combustion equipment.  It applies to all forms of gaseous, liquid and solid fuel and any combinations of them in combustion with air or other gas containing free oxygen.  This Part of EN 746 also applies to gas torches, work station burners, working flame burners and other burners not integral with the plant, even though they are not covered by the mandate.  This Part of EN 746 specifies the requirements to be met by the manufacturer to ensure the safety of persons and property during commissioning, start-up, operation, shut-down and maintenance, as well as in the event of foreseeable faults or malfunctions. It specifies the safety requirements at stages in the life of the equipment, and its design, ordering, construction and use.   The hazards covered by this Part of EN 746 are listed in clause 4.  This Part of EN 746 applies to equipment which is placed on the market after the date of issue of this standard.  This Part of EN 746 does not apply to but may be used as reference for:    - gas torches for welding, flame cutting and related processes; - boiler installations; - environmental space heating of any kind; - the storage of fuel; - industrial food processing.

Industrielle Thermoprozeßanlagen - Teil 2: Sicherheitsanforderungen an Feuerungen und Brennstofführungssysteme

Diese Norm ist anwendbar auf alle Feuerungen und Brennstofführungssysteme in allen industriellen Thermoprozessanlagen, die der Definition für Mascinen in 3.1 von EN 292-1:1991 entsprechen und auf die im folgenden als "Anlage" Bezug genommen wird, (wie Öfen und Erwärmungsanlagen - z.B. für Druckgiessmaschinen, Pannenfeuer usw.)rennstofführung und der Feuerung.

Equipements thermiques industriels - Partie 2: Prescriptions de sécurité concernant la combustion et la manutention des combustibles

La présente norme est applicable aux équipements de combustion et de manutention des combustibles utilisés dans les équipements thermiques industri elles qui suivent la définition de la machine donnée dans 3.1 de l'EN 292-1:1991ci-après désignés "équipement" tels   que: fours, fourneaux, arches, séchoirs, étuves, systèmes de chauffage, par exemple: bains de sel, réservoirs, bassins et équipements du genre brûleurs ou chalumeaux intégrés, par exemple: dans les machines de fonderie, poches, etc.).

Industrial thermoprocessing equipment - Part 2: Safety requirements for combustion and fuel handling systems

General Information

Status
Withdrawn
Publication Date
18-Mar-1997
Withdrawal Date
11-May-2010
ICS
25.180.01 - Industrial furnaces in general
Technical Committee
CEN/TC 186 - Industrial thermoprocessing - Safety
Drafting Committee
CEN/TC 186/WG 2 - Combustion and fuel handling systems - Safety requirements
Current Stage
9960 - Withdrawal effective - Withdrawal
Start Date
12-May-2010
Completion Date
12-May-2010
Directive
89/392/EEC - Machinery - Safety of machinery: general essential health and safety requirements
98/37/EC - Machinery
Mandate
M/BC/CEN/88/13 - Standardization request to CEN/CENELEC relating to machinery
Ref Project
SIST EN 746-2:2000 - Industrial thermoprocessing equipment - Part 2: Safety requirements for combustion and fuel handling systems

Relations

Replaced By
EN 746-2:2010 - Industrial thermoprocessing equipment - Part 2: Safety requirements for combustion and fuel handling systems
Effective Date
22-Dec-2008

Buy Standard

EN 746-2 2000EN 746-2 2000
PreviousNext
Standard
EN 746-2 2000
English language
73 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (Sample)

SLOVENSKI STANDARD
SIST EN 746-2:2000
01-april-2000
Industrial thermoprocessing equipment - Part 2: Safety requirements for
combustion and fuel handling systems
Industrial thermoprocessing equipment - Part 2: Safety requirements for combustion and
fuel handling systems
Industrielle Thermoprozeßanlagen - Teil 2: Sicherheitsanforderungen an Feuerungen
und Brennstofführungssysteme
Equipements thermiques industriels - Partie 2: Prescriptions de sécurité concernant la
combustion et la manutention des combustibles
Ta slovenski standard je istoveten z: EN 746-2:1997
